16i/18i/21i-B maintenance manual for SD7 Maintenance manual Page 149

Maintenance manual
Manual operation
Function
KEY
SW
PWE
=1
Mode
Func-
tion key
Operation
Manual refer-
ence point
return
JOG
Turn on Reference point return switch ³ Turn on +X, –X, +Z, or –Z ³
Reference point return switch LED lit.
Jog feed JOG
Turn on +X, –X, +Z, or –Z ³ Use JOG FEEDRATE to set jog feedrate
³ Press Rapid traverse button, if required.
Incremental
feed
INC
Use Move distance selection switch to select move distance ³ Turn on
+X, –X, +Z, or –Z ³ Press Rapid traverse button, if required.
Manual
handle feed
HND
Use Axis selection switch to select axis to be operated ³ Use Handle
magnification selection to select magnification ³ Turn manual pulse
generator.
Display
Function KEY
SW
PWE
=1
Mode
Func-
tion key
Operation
Amount of
program
memory in
use
EDIT
PROG
[ DIR ]
Command
Command value being executed, and previously specified modal value
value display
[CURRNT]
Command value being executed, and next command value to be
executed
[ NEXT ]
MEM
or
PROG
Command value entered from MDI, and previously specified modal
value
MDI
[ MDI ]
Program in memory being executed
[PRGRM]
Executable blocks in memory and current position
[CHECK]
Current–
Representation of the position in the workpiece coordinate system
position
display
[ ABS ]
Representation of the position in the relative coordinate system
POS
[ REL ]
General position indication
[ ALL ]
Alarm display
—
MESSAGE
[ALARM ] when an alarm condition has occurred.
GFKE-0222-EN
1. DISPLAY AND OPERATION
119
