16i/18i/21i-B maintenance manual for SD7 Maintenance manual Page 711

Maintenance manual
CAUTION
1 For the parameters to be specified on the FSSB setting
screen, do not attempt to enter values on the parameter
screen using the MDI or a G10 command. Use only the
FSSB screen to enter values for these parameters.
2 If pressing soft key [SET] results in a warning message
being displayed, retry data entry, or press soft key [READ]
to clear the warning message. Note that pressing the reset
key does not clear the warning message.
1) Amplifier setting screen
AMPLIFIER SETTING O1000 N00001
NO. AMP SERIES UNIT CUR. AXIS NAME
1A1–L α SVM–HV 40AL 1 X
2A1–M α SVM 12A 2 Y
3A2–L β SVM 40A 3 Z
4A3–L α SVM 20A 4 A
5A3–M α SVM 40A 5 B
7A4–L α SVU 240A 6 C
NO. EXTRA TYPE PCB ID
6 M1 A 0000 DETECTOR(8AXES)
8 M2 B 12AB
>_
MDI **** *** *** 13:11:56
[SETTING][ ][ READ ][ ][ INPUT ]
The amplifier setting screen displays the following items:
D NO. (controlled axis number)
For this item, enter a value of between 1 and the maximum number of
controlled axes. If a number that falls outside this range is entered, the
warning message “INVALID FORMAT” appears. If the entered
controlled axis number is duplicate or 0, the warning message
“SPECIFIED DATA IS OUT OF RANGE” appears when soft key
[SET] is pressed to assert the entered value. In this case, no value can
be entered for the parameter.
NOTE
When the servo of another system is controlled, FSSB
cannot be set automatically.
Be careful when controlling two or three systems.
To control the servo of another system, make manual
settings as described in Appendix G.
GFKE-0222-EN
9. DIGITAL SERVO
681
