16i/18i/21i-B maintenance manual for SD7 Maintenance manual Page 15

Maintenance manual

Page of 1042

/ 1042

NOTE

Some function described in this manual may not be applied

to some products.

For details, refer to the DESCRIPTIONS manual

(B–63522EN)

The following table lists the manuals related to Series 16i, Series 18i,

Series 21i, Series 160i, Series 180i, Series 210i, Series 160is, Series

180is, Series 210is–MODEL B. This manual is indicated by an

asterisk(*).

Related manuals of Series 16i/18i/21i/160i/180i/210i/

160is/180is/210is MODEL B

Manual name

Specification

number

DESCRIPTIONS B–63522EN *

CONNECTION MANUAL (HARDWARE) B–63523EN

CONNECTION MANUAL (FUNCTION) B–63523EN–1

Series 16i/18i/160i/180i/160is/180is–TB

OPERATOR’S MANUAL

B–63524EN

Series 16i/160i/160is–MB, Series 18i/180i/180is–MB5,

Series 18i/180i/180is–MB OPERATOR’S MANUAL

B–63534EN

Series 21i/210i/210is–TB OPERATOR’S MANUAL B–63604EN

Series 21i/210i/210is–MB OPERATOR’S MANUAL B–63614EN

MAINTENANCE MANUAL B–63525EN

Series 16i/18i/160i/180i/160is/180is–MODEL B

PARAMETER MANUAL

B–63530EN

Series 21i/210i/210is–MODEL B PARAMETER MANUAL B–63610EN

PROGRAMMING MANUAL

Macro Compiler/Macro Executor

PROGRAMMING MANUAL

B–61803E–1

C Language Executor PROGRAMMING MANUAL B–62443EN–3

FAPT MACRO COMPILER (For Personal Computer)

PROGRAMMING MANUAL

B–66102E

CAP (T series)

FANUC Super CAPi T OPERATOR’S MANUAL B–63284EN

FANUC Symbol CAPi T OPERATOR’S MANUAL B–63304EN

MANUAL GUIDE For Lathe PROGRAMMING MANUAL B–63343EN

MANUAL GUIDE For Lathe OPERATOR’S MANUAL B–63344EN

CAP (M series)

FANUC Super CAPi M OPERATOR’S MANUAL B–63294EN

MANUAL GUIDE For Milling PROGRAMMING MANUAL B–63423EN

MANUAL GUIDE For Milling OPERATOR’S MANUAL B–63424EN

Related manuals of

Series 16i/18i/21i/160i/

180i/210i/160is/180is/

210is–MODEL B

GFKE-0222-EN

PREFACE

p–3

Contents Summary of 16i/18i/21i-B maintenance manual for SD7 Maintenance manual

Page 1 MAINTENANCE MANUAL FOR SD7 GFKE-0222-EN
Page 2
Page 3SAFETY PRECAUTIONS This section describes the safety precautions related to the use of CNC units. It is essential that these precautions be observed by users to ensure the safe operation of machines equipped with a CNC unit (all descriptions in this section assume this configuration). CNC maintenanc
Page 4SAFETY PRECAUTIONS GFKE-0222-EN 1 DEFINITION OF WARNING, CAUTION, AND NOTE This manual includes safety precautions for protecting the maintenance personnel (herein referred to as the user) and preventing damage to the machine. Precautions are classified into Warnings and Cautions according to their
Page 5GFKE-0222-EN SAFETY PRECAUTIONS 2 WARNINGS RELATED TO CHECK OPERATION WARNING 1. When checking the operation of the machine with the cover removed (1) The user’s clothing could become caught in the spindle or other components, thus presenting a danger of injury. When checking the operation, stand aw
Page 6SAFETY PRECAUTIONS GFKE-0222-EN WARNING 5. Ensure that the specified feedrate is appropriate for the intended operation. Generally, for each machine, there is a maximum allowable feedrate. The appropriate feedrate varies with the intended operation. Refer to the manual provided with the machine to d
Page 7GFKE-0222-EN SAFETY PRECAUTIONS 3 WARNINGS RELATED TO REPLACEMENT WARNING 1. Always turn off the power to the CNC and the main power to the power magnetics cabinet. If only the power to the CNC is turned off, power may continue to be supplied to the serve section. In such a case, replacing a unit ma
Page 8SAFETY PRECAUTIONS GFKE-0222-EN 4 WARNINGS RELATED TO PARAMETERS WARNING 1. When machining a workpiece for the first time after modifying a parameter, close the machine cover. Never use the automatic operation function immediately after such a modification. Instead, confirm normal machine operation
Page 9GFKE-0222-EN SAFETY PRECAUTIONS 5 WARNINGS AND NOTES RELATED TO DAILY MAINTENANCE WARNING 1. Memory backup battery replacement When replacing the memory backup batteries, keep the power to the machine (CNC) turned on, and apply an emergency stop to the machine. Because this work is performed with th
Page 10SAFETY PRECAUTIONS GFKE-0222-EN WARNING 2. Absolute pulse coder battery replacement When replacing the memory backup batteries, keep the power to the machine (CNC) turned on, and apply an emergency stop to the machine. Because this work is performed with the power on and the cabinet open, only those
Page 11GFKE-0222-EN SAFETY PRECAUTIONS WARNING 3. Fuse replacement Before replacing a blown fuse, however, it is necessary to locate and remove the cause of the blown fuse. For this reason, only those personnel who have received approved safety and maintenance training may perform this work. When replacing
Page 12
Page 13GFKE-0222-EN PREFACE PREFACE Description of 1.Display and operation this manual This chapter covers those items, displayed on the screen, that are related to maintenance. A list of all supported operations is also provided at the end of this chapter. 2.LCD–mounted type i series hardware 3.LCD–mounte
Page 14PREFACE GFKE-0222-EN Appendix A. Alarm list B. List of maintenance parts C. Boot system D. Memory card slot E. LED display and maintenance of stand–alone type unit F. Maintenance of open CNC (boot–up and IPL) G. FSSB start–up procedure/materials H. Notation of MDI keys This manual does not provide a
Page 15GFKE-0222-EN PREFACE NOTE Some function described in this manual may not be applied to some products. For details, refer to the DESCRIPTIONS manual (B–63522EN) Related manuals of The following table lists the manuals related to Series 16i, Series 18i, Series 16i/18i/21i/160i/ Series 21i, Series 160i
Page 16PREFACE GFKE-0222-EN Specification Manual name number PMC PMC Ladder Language PROGRAMMING MANUAL B–61863E PMC C Language PROGRAMMING MANUAL B–61863E–1 Network I/O Link–II OPERATOR’S MANUAL B–62924EN Profibus–DP Board OPERATOR’S MANUAL B–62924EN Ethernet Board/DATA SERVER Board B–63354EN OPERATOR’S M
Page 17GFKE-0222-EN PREFACE D FANUC SERVO MOTOR a series This manual mainly assumes that the FANUC SERVO MOTOR ai series of servo motor is used. For servo motor and spindle information, refer to the manuals for the servo motor and spindle that are actually connected. p–5
Page 18NOTE The IEC61131-3 adresses from PMC SD7 used in this manual have been shortened by the '%' as follows: '%I1234' => 'I1234' '%Q1234' => 'Q1234' '%IF1234' => 'IF1234' '%QG1234' => 'QG1234' '%M1234' => 'M1234' '%R1234' => 'RI1234'h
Page 19GFKE-0222-EN Table of Contents SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . s–1 PREFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 20TABLE OF CONTENTS GFKE-0222-EN 1.10 WAVEFORM DIAGNOSTIC FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 1.10.1 Setting Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 21GFKE-0222-EN TABLE OF CONTENTS 2.4.4 Sub–CPU Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193 2.4.5 RISC Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 22TABLE OF CONTENTS GFKE-0222-EN 4.4 CONNECTOR AND CARD CONFIGURATIONS OF PRINTED CIRCUIT BOARDS . . . . . . . . 280 4.4.1 Main CPU Board of Series 16i/18i/21i/160i/180i/210i/160is/180is/210is . . . . . . . . . . . . . . . . 280 4.4.2 Sub–CPU Board . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 23GFKE-0222-EN TABLE OF CONTENTS 5.1.2 Mounting a Card PCB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 356 5.2 MOUNTING AND DEMOUNTING DIMM MODULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 357 5.2.1 Demounting a
Page 24TABLE OF CONTENTS GFKE-0222-EN 6.2.12 Inputting Tool Compensation Amount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 409 6.2.13 Inputting Part Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 25GFKE-0222-EN TABLE OF CONTENTS 7.5 LIST OF INPUT/OUTPUT SIGNALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 499 7.6 LIST OF ADDRESSES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 26TABLE OF CONTENTS GFKE-0222-EN 8.8.2 Check Items Related to Connection with a Backbone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 660 8.8.3 Checking the Setting of Each Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 661 8.8.4 Checking C
Page 27GFKE-0222-EN TABLE OF CONTENTS 11.1.1 Investigating the Conditions Under which Failure Occurred . . . . . . . . . . . . . . . . . . . . . . . . . . 725 11.2 NO MANUAL OPERATION NOR AUTOMATIC OPERATION CAN BE EXECUTED . . . . . . . 727 11.3 JOG OPERATION CANNOT BE DONE . . . . . . . . . . . . . . . .
Page 28TABLE OF CONTENTS GFKE-0222-EN APPENDIX A. ALARM LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 835 A.1 LIST OF ALARM CODES (CNC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 29GFKE-0222-EN TABLE OF CONTENTS F.2 CHANGING START SEQUENCES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 952 F.3 EXPLANATION OF SCREENS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 954 F.3
Page 30
Page 31GFKE-0222-EN 1. DISPLAY AND OPERATION 1 DISPLAY AND OPERATION This chapter describes how to display various screens by the function keys. The screens used for maintenance are respectively displayed. 1.1 FUNCTION KEYS AND SOFT KEYS . . . . . . . . . . . . 2 1.2 SCREEN DISPLAYED IMMEDIATELY AFTER POWE
Page 321. DISPLAY AND OPERATION GFKE-0222-EN 1.1 Operations and soft key display staturs for each function key are described below: FUNCTION KEYS AND SOFT KEYS 1.1.1 To display a more detailed screen, press a function key followed by a soft key. Soft keys are also used for actual operations. Soft Keys The
Page 33GFKE-0222-EN 1. DISPLAY AND OPERATION POSITION SCREEN Soft key transition triggered by the function key POS POS Absolute coordinate display [ABS] [(OPRT)] [PTSPRE] [EXEC] [RUNPRE] [EXEC] Relative coordinate display [REL] [(OPRT)] (Axis or numeral) [PRESET] [ORIGIN] [ALLEXE] [Axis name] [EXEC] [PTSPR
Page 341. DISPLAY AND OPERATION GFKE-0222-EN PROGRAM SCREEN Soft key transition triggered by the function key PROG in the MEM mode 1/2 PROG Program display screen [PRGRM] [(OPRT)] [BG–EDT] See “When the soft key [BG–EDT] is pressed” [O number] [O SRH] (1) [N number] [N SRH] [REWIND] [P TYPE] [Q TYPE] [F SR
Page 35GFKE-0222-EN 1. DISPLAY AND OPERATION 2/2 (2) [FL.SDL] [PRGRM] Return to (1) (Program display) File directory display screen [DIR] [(OPRT)] [SELECT] (File No. ) [F SET] [EXEC] Schedule operation display screen [SCHDUL] [(OPRT)] [CLEAR] [CAN] [EXEC] (Schedule data) [INPUT] 5
Page 361. DISPLAY AND OPERATION GFKE-0222-EN PROGRAM SCREEN Soft key transition triggered by the function key PROG in the EDIT mode 1/2 PROG Program display [PRGRM] [(OPRT)] [BG–EDT] See “When the soft key [BG–EDT] is pressed” (O number) [O SRH] (Address) [SRH↓] (Address) [SRH↑] [REWIND] [F SRH] [CAN] (N n
Page 37GFKE-0222-EN 1. DISPLAY AND OPERATION 2/2 (1) Program directory display [LIB] [(OPRT)] [BG–EDT] See “When the soft key [BG–EDT] is pressed” (O number) [O SRH] Return to the program [READ] [CHAIN] [STOP] [CAN] (O number) [EXEC] [PUNCH] [STOP] [CAN] (O number) [EXEC] Graphic Conversational Programming
Page 381. DISPLAY AND OPERATION GFKE-0222-EN PROGRAM SCREEN Soft key transition triggered by the function key PROG in the MDI mode PROG Program display [PRGRM] [(OPRT)] [BG–EDT] See “When the soft key [BG–EDT] is pressed” Program input screen [MDI] [(OPRT)] [BG–EDT] See “When the soft key [BG–EDT] is press
Page 39GFKE-0222-EN 1. DISPLAY AND OPERATION PROGRAM SCREEN Soft key transition triggered by the function key PROG in the HNDL, JOG, or REF mode PROG Program display [PRGRM] [(OPRT)] [BG–EDT] See “When the soft key [BG–EDT] is pressed” Current block display screen [CURRNT] [(OPRT)] [BG–EDT] See “When the s
Page 401. DISPLAY AND OPERATION GFKE-0222-EN PROGRAM SCREEN Soft key transition triggered by the function key PROG in the TJOG or THDL mode PROG Program input screen [PRGRM] [(OPRT)] [BG–EDT] See “When the soft key [BG–EDT] is pressed” (O number) [O SRH] Return to the program (Address) [SRH↓] (Address) [SR
Page 41GFKE-0222-EN 1. DISPLAY AND OPERATION PROG PROGRAM SCREEN Soft key transition triggered by the function key (When the soft key [BG–EDT] is pressed in all modes) 1/2 PROG Program display [PRGRM] [(OPRT)] [BG–END] (O number) [O SRH] (Address) [SRH↓] (Address) [SRH↑] [REWIND] [F SRH] [CAN] (N number) [
Page 421. DISPLAY AND OPERATION GFKE-0222-EN 2/2 (1) Program directory display [LIB] [(OPRT)] [BG–EDT] (O number) [O SRH] Return to the program [READ] [CHAIN] [STOP] [CAN] (O number) [EXEC] [PUNCH] [STOP] [CAN] (O number) [EXEC] Graphic Conversational Programming [C.A.P.] [PRGRM] Return to the program [G.M
Page 43GFKE-0222-EN 1. DISPLAY AND OPERATION Soft key transition triggered by the OFFSET/SETTING SCREEN (T series) function key OFFSET SETTING 1/2 OFFSET SETTING Tool offset screen [OFFSET] [WEAR] [(OPRT)] (Number) [NO SRH] [GEOM] (Axis name and numeral) [MEASUR] (Axis name) [INP.C.] (Numeral) [+INPUT] (Nu
Page 441. DISPLAY AND OPERATION GFKE-0222-EN 2/2 (1) Pattern data input screen [MENU] [(OPRT)] (Number) [SELECT] Software operator’s panel screen [OPR] Tool life management setting screen [TOOLLF] [(OPRT)] (Number) [NO SRH] [CLEAR] [CAN] [EXEC] (Numeral) [INPUT] Y–axis tool offset screen [OFST.2] [WEAR] [(
Page 45GFKE-0222-EN 1. DISPLAY AND OPERATION Soft key transition triggered by the OFFSET/SETTING SCREEN (M series) function key OFFSET SETTING 1/2 OFFSET SETTING Tool offset screen [OFFSET] [(OPRT)] (Number) [NO SRH] (Axis name) [INP.C.] (Numeral) [+INPUT] (Numeral) [INPUT] [CLEAR] [ALL] [WEAR] [GEOM] [REA
Page 461. DISPLAY AND OPERATION GFKE-0222-EN 2/2 (1) Patten data input screen [MENU] [(OPRT)] (Number) [SELECT] Software operator’s panel screen [OPR] Tool life management setting screen [TOOLLF] [(OPRT)] (Number) [NO SRH] [CLEAR] [CAN] [EXEC] (Numeral) [INPUT] 16
Page 47GFKE-0222-EN 1. DISPLAY AND OPERATION SYSTEM SCREEN Soft key transition triggered by the function key SYSTEM 1/3 SYSTEM Parameter screen [PARAM] [(OPRT)] (Number) [NO SRH] [ON:1] [OFF:0] (Numeral) [+INPUT] (Numeral) [INPUT] [READ] [CAN] [EXEC] [PUNCH] [CAN] [EXEC] Diagnosis screen [DGNOS] [(OPRT)] (
Page 481. DISPLAY AND OPERATION GFKE-0222-EN (1) (2) (3) 2/3 [DUMP] [SEARCH] [BYTE] [WORD] [D.WORD] [DRARA]/[NDPARA] [PMCDGN] [TITLE] [STATUS] [SEARCH] [ALARM] [TRACE] [T.DISP]/[TRCPRM] [EXEC] [M.SRCH] [SEARCH] [INPUT] [ANALYS] [SCOPE] [SGNPRM] With [DELETE] [START]/[STOP] PMC–RC [INIT] [T–SRCH] only [ADRE
Page 49GFKE-0222-EN 1. DISPLAY AND OPERATION (4) 3/3 Pitch error compensation screen [PITCH] [(OPRT)] (No.) [NO SRH] [ON:1] [OFF:0] (Numeral) [+INPUT] (Numeral) [INPUT] [READ] [CAN] [EXEC] [PUNCH] [CAN] [EXEC] Servo parameter screen [SV.PRM] [SV.SET] [ON:1] [(OPRT)] [SV.TUN] [OFF:0] (Numeral) [INPUT] [TRAC
Page 501. DISPLAY AND OPERATION GFKE-0222-EN MESSAGE SCREEN Soft key transition triggered by the function key MESSAGE MESSAGE Alarm display screen [ALARM] Message display screen [MSG] Alarm history screen [HISTRY] [(OPRT)] [CLEAR] HELP SCREEN Soft key transition triggered by the function key HELP HELP Alar
Page 51GFKE-0222-EN 1. DISPLAY AND OPERATION GRAPHIC SCREEN (T series) Soft key transition triggered by the function key GRAPH Tool path graphics Mode 0 GRAPH Tool path graphics [G.PRM] [(OPRT)] [NORMAL] [GRAPH] [(OPRT)] [ZOOM] [HEAD] [ERASE] [ZOOM] [(OPRT)] [ACT] [PROCES] [HI/LO] [EXEC] [STOP] A.ST/Path g
Page 521. DISPLAY AND OPERATION GFKE-0222-EN GRAPHIC SCREEN (M series) Soft key transition triggered by the function key GRAPH Tool path graphics GRAPH Tool path graphics [PARAM] [EXEC] [(OPRT)] [AUTO] [STSRT] [STOP] [REWIND] [CLEAR] [ZOOM] [(OPRT)] [EXEC] [←] [→] [POS] [↑] [↓] Solid graphics GRAPH Solid g
Page 53GFKE-0222-EN 1. DISPLAY AND OPERATION 1.2 SCREEN DISPLAYED IMMEDIATELY AFTER POWER IS TURNED ON 1.2.1 Types of PCBs mounted on the slots are displayed. If a hardware trouble or an incorrect mounting is found, this screen is Slot Status Display displayed. D Slot state screen SLOT CONFIGURATION DISPLA
Page 541. DISPLAY AND OPERATION GFKE-0222-EN D Software ID 40 : Main CPU 41 : C language 43 : Sub CPU 49 : CAP II 4A : Remote buffer 4F : PMC–RE 53 : Loader control 59 : RISC board for high–precision contour control 5E : HSSB interface (with PC) 1.2.2 Setting Module Screen END : Setting B0H1–01 completed C
Page 55GFKE-0222-EN 1. DISPLAY AND OPERATION 1.3 After the system has been installed correctly, you can find the PCBs installed and the softwares integrated on the system configuration screen. SYSTEM CONFIGURATION SCREEN 1.3.1 (1) Press SYSTEM key. Display Method (2) Press soft key [SYSTEM], then the syste
Page 561. DISPLAY AND OPERATION GFKE-0222-EN D Module ID ID Name D5 Series 16i motherboard C5 Series 18i motherboard CC Series 160i motherboard EC Series 180i motherboard CD Serial communication board: remote buffer/DNC2 Serial communication board: DNC1 C language board CAP–II board CE Sub–CPU board CF RIS
Page 57GFKE-0222-EN 1. DISPLAY AND OPERATION 1.3.3 Kind of software Software Configuration Software series Screen SYSTEM CONFIG (SOFTWARE) 01234 N12345 PAGE:02 SYSTEM B0H0 0001 Software version BASIC+OPTION–A1 Software SERVO 90B0 0001 configuration PMC(SYS) 406G 0001 406G 0001 PMC(LAD) FS16 0001 Character
Page 581. DISPLAY AND OPERATION GFKE-0222-EN 1.3.5 D αi series servo and αi series spindle ID Information Screen When the αi servo/αi spindle system is connected, ID information owned by connected units (motor, amplifier, module, etc.) for αi (αi Servo Information servo/αi spindle can be displayed on the C
Page 59GFKE-0222-EN 1. DISPLAY AND OPERATION 1.4 ALARM HISTORY SCREEN 1.4.1 Alarm History Screen 1.4.1.1 Alarms generated in the NC are recorded. The latest 25 alarms generated General are recorded. The 26th and former alarms are deleted. 1.4.1.2 (1) Press MESSAGE key . Screen Display (2) Press soft key [H
Page 601. DISPLAY AND OPERATION GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 3112 EAH [Data type] Bit #3 (EAH) The alarm history function: 0 : Does not record the messages output with external alarms or macro alarms. 1 : Records the messages output with external alarms or macro alarms. 1.4.2 System Alarm History 1
Page 61GFKE-0222-EN 1. DISPLAY AND OPERATION SYSTEM ALARM HISTORY O1234 N12345 1 2001–03–13 12:13:19 930 CPU INTERRUPT 2 2001–03–11 07:23:07 900 ROM PARITY 3 2001–02–27 973 NON MASK INTERRUPT EDIT **** *** *** 08:20:52 [ ][ ][ NMIHIS ][ ][ ] [ SELECT ][ RETURN ][ CLEAR ][ ][ ] [SELECT] soft key This soft k
Page 621. DISPLAY AND OPERATION GFKE-0222-EN 1.4.2.3 The system alarm history screen (detail screen) displays information System alarm history items such as registers and stacks involved when a system alarm is issued. screen (detail screen) The following items are displayed: 1. System alarm occurrence date
Page 63GFKE-0222-EN 1. DISPLAY AND OPERATION SYSTEM ALARM HISTORY O1234 N12345 2 2001–03–11 07:23:07 BDH1–01(2/4) 973 NON MASK INTERRUPT STACK (PL0) 3646 0338 7CBA 0001 0958 FFF8 0068 0063 0346 0000 0000 02BC 08F8 52F1 2438 0338 0580 0440 0580 001F 03C0 0214 0780 0FFF 0000 0000 0000 0000 0000 0000 0000 000
Page 641. DISPLAY AND OPERATION GFKE-0222-EN CAUTION 1 In the case of an NMI on other than the main board, the registers of detail display screen 1, and the contents of detail display screen 2 and detail display screen 3 are displayed. SYSTEM ALARM HISTORY O1234 N12345 2 2001–03–11 07:23:07 BDH1–01(1/1) 97
Page 65GFKE-0222-EN 1. DISPLAY AND OPERATION 1.4.2.4 Parameter #7 #6 #5 #4 #3 #2 #1 #0 3103 NMH [Data type] Bit NMH The system alarm history screen is: 0 : Not displayed. 1 : Displayed. #7 #6 #5 #4 #3 #2 #1 #0 3110 OPC [Data type] Bit OPC On the operation history screen, the [CLEAR] soft key is: 0 : Not en
Page 661. DISPLAY AND OPERATION GFKE-0222-EN 1.5 This function enables the saving of external operator messages as a record. EXTERNAL The record can be viewed on the external operator message history screen. OPERATOR MESSAGES RECORD 1.5.1 (1) Press the MESSAGE function key. Screen Display (2) Press the rig
Page 67GFKE-0222-EN 1. DISPLAY AND OPERATION 1.5.3 Parameter #7 #6 #5 #4 #3 #2 #1 #0 3113 MS1 MS0 MHC #0 (MHC) The records of an external operator message: 0 : Cannot be erased. 1 : Can be erased. #6, #7 (MS0,MS1) These bits set the number of characters to be retained in each record of an external operator
Page 681. DISPLAY AND OPERATION GFKE-0222-EN 1.6 This function displays the key and signal operations performed by the operator upon the occurrence of a fault or the output of an alarm, together OPERATION with the corresponding alarms. HISTORY This function records the following data: (1) MDI key operation
Page 69GFKE-0222-EN 1. DISPLAY AND OPERATION 12801 Number of a signal symbol table for selecting an operation history signal (01) 12802 Number of a signal symbol table for selecting an operation history signal (02) 12803 Number of a signal symbol table for selecting an operation history signal (03) 12804 N
Page 701. DISPLAY AND OPERATION GFKE-0222-EN 12841 Number of a signal selected as an operation history signal (01) 12842 Number of a signal selected as an operation history signal (02) 12843 Number of a signal selected as an operation history signal (03) 12844 Number of a signal selected as an operation hi
Page 71GFKE-0222-EN 1. DISPLAY AND OPERATION #7 #6 #5 #4 #3 #2 #1 #0 12881 RB7 RB6 RB5 RB4 RB3 RB2 RB1 RB0 History record bit settings for an operation history signal (01) #7 #6 #5 #4 #3 #2 #1 #0 12882 RB7 RB6 RB5 RB4 RB3 RB2 RB1 RB0 History record bit settings for an operation history signal (02) #7 #6 #5
Page 721. DISPLAY AND OPERATION GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 12896 RB7 RB6 RB5 RB4 RB3 RB2 RB1 RB0 History record bit settings for an operation history signal (16) #7 #6 #5 #4 #3 #2 #1 #0 12897 RB7 RB6 RB5 RB4 RB3 RB2 RB1 RB0 History record bit settings for an operation history signal (17) #7 #6 #5
Page 73GFKE-0222-EN 1. DISPLAY AND OPERATION 1.6.2 Screen Display D Displaying the operation (1) Press the SYSTEM function key. history (2) Press the continue menu key [ ]. The [OPEHIS] (OPERATION HISTORY) soft key are displayed. (3) Press the [OPEHIS] soft key twice. The operation history screen is displa
Page 741. DISPLAY AND OPERATION GFKE-0222-EN Data displayed on the operation history screen (1) MDI keys Address and numeric keys are displayed after a single space. Soft keys are displayed in square brackets ([]). Other keys (RESET/INPUT, for example) are displayed in angle brackets (<>). A key pressed at
Page 75GFKE-0222-EN 1. DISPLAY AND OPERATION Mode selection signals and rapid traverse override signals are displayed as indicated below: Input signal Name displayed MD1 ND2 MD4 REF DNC1 0 0 0 0 0 MDI 1 0 0 0 0 MEM 1 0 0 0 1 RMT 0 1 0 0 0 NOMODE 1 1 0 0 0 EDT 0 0 1 0 0 H/INC 1 0 1 0 0 JOG 1 0 1 1 0 REF 0 1
Page 761. DISPLAY AND OPERATION GFKE-0222-EN 1) The power–on time is displayed as shown below: 01/01/20 ==== Year/Month/Day 09:15:30 ==== Hour:Minute:Second 2) The power–off time and the time when an NC alarm occurred are displayed in reverse video. 01/01/20 ==== Year/Month/Day 09:15:30 ==== Hour:Minute:Se
Page 77GFKE-0222-EN 1. DISPLAY AND OPERATION 1.6.3 (1) On the operation history signal selection screen, press the [(OPE)] soft Setting The Input key. Signal or Output Signal OP_HIS SIGNAL SELECT O1000 N02000 to Be Recorded in The Operation History No. ADDRES SIGNAL No. ADDRES SIGNAL 01 G0004 00000010 11 *
Page 781. DISPLAY AND OPERATION GFKE-0222-EN D Parameter–based setting By setting bit 4 (PHS) of parameter No. 3206, setting and display on the operation history signal selection screen can be linked with parameter No. 12801 through No. 12900. By this linking, setting information related to input and outpu
Page 79GFKE-0222-EN 1. DISPLAY AND OPERATION #7 #6 #5 #4 #3 #2 #1 #0 G020 f f f f f f f f to G042 f f f f f f f f G043 f × f × × f f f G044 f f f f f f MLK BDT1 G045 BDT9 BDT8 BDT7 BDT6 BDT5 BDT4 BDT3 BDT2 G046 DRN KEY4 KEY3 KEY2 KEY1 f SBK f G047 f f f f f f f f to G060 f f f f f f f f G061 f f f f f f f
Page 801. DISPLAY AND OPERATION GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 G115 f f f f f f f f G116 *–L8 *–L7 *–L6 *–L5 *–L4 *–L3 *–L2 *–L1 G117 f f f f f f f f G118 *+ED8 *+ED7 *+ED6 *+ED5 *+ED4 *+ED3 *+ED2 *+ED1 G119 f f f f f f f f G120 *–ED8 *–ED7 *–ED6 *–ED5 *–ED4 *–ED3 *–ED2 *–ED1 G121 f f f f f f f f to
Page 81GFKE-0222-EN 1. DISPLAY AND OPERATION 2. List of Address for 2–path control MT→PMC #7 #6 #5 #4 #3 #2 #1 #0 X000 f f f f f f f f to X127 f f f f f f f f PMC→CNC (Signals for tool post 1) #7 #6 #5 #4 #3 #2 #1 #0 G000 f f f f f f f f to G003 f f f f f f f f G004 f f f f FIN f f f G005 f f f f TFIN SFIN
Page 821. DISPLAY AND OPERATION GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 G061 f f f f f f f RGTA G062 f f f f f f f f to G099 f f f f f f f f G100 +J8 +J7 +J6 +J5 +J4 +J3 +J2 +J1 G101 f f f f f f f f G102 –J8 –J7 –J6 –J5 –J4 –J3 –J2 –J1 G103 f f f f f f f f to G105 f f f f f f f f G106 MI8 MI7 MI6 MI5 MI4 MI3
Page 83GFKE-0222-EN 1. DISPLAY AND OPERATION #7 #6 #5 #4 #3 #2 #1 #0 G126 SVF8 SVF7 SVF6 SVF5 SVF4 SVF3 SVF2 SVF1 G127 f f f f f f f f to G129 f f f f f f f f G130 *IT8 *IT7 *IT6 *IT5 *IT4 *IT3 *IT2 *IT1 G131 f f f f f f f f G132 f f f f +MIT4 +MIT3 +MIT2 +MIT1 G133 f f f f f f f f G134 f f f f –MIT4 –MIT3
Page 841. DISPLAY AND OPERATION GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 G1020 f f f f f f f f to G1042 f f f f f f f f G1043 f × f × × f f f G1044 f f f f f f MLK BDT1 G1045 BDT9 BDT8 BDT7 BDT6 BDT5 BDT4 BDT3 BDT2 G1046 DRN KEY4 KEY3 KEY2 KEY1 f SBK f G1047 f f f f f f f f to G1060 f f f f f f f f G1061 f f f
Page 85GFKE-0222-EN 1. DISPLAY AND OPERATION #7 #6 #5 #4 #3 #2 #1 #0 G1116 *–L8 *–L7 *–L6 *–L5 *–L4 *–L3 *–L2 *–L1 G1117 f f f f f f f f G1118 *+ED8 *+ED7 *+ED6 *+ED5 *+ED4 *+ED3 *+ED2 *+ED1 G1119 f f f f f f f f G1120 *–ED8 *–ED7 *–ED6 *–ED5 *–ED4 *–ED3 *–ED2 *–ED1 G1121 f f f f f f f f to G1125 f f f f f
Page 861. DISPLAY AND OPERATION GFKE-0222-EN 1.6.4 Recorded data can be output to an input/output unit connected via a Inputting and reader/punch interface. An output record can be input from the input/output unit. Outputting the Set the input/output unit to be used in setting parameters No. 0020 and Opera
Page 87GFKE-0222-EN 1. DISPLAY AND OPERATION 1) Header T 0 C O P E R A T I O N H I S T O R Y ; C: Data word 2) MDI/soft key T 5 0 P 0 to 1 H * * ; P0: Usually P1: At power–on H **: Key code (See the following table.) 3) Signal T 5 1 P 0 to 6 N 0 to 255 H * * , * * ; New data Old data P0: X0000 and above P2
Page 881. DISPLAY AND OPERATION GFKE-0222-EN 4) Alarm T 5 2 P 0 to 10 N * * * * ; P0: P/S No. 100 P1: P/S No. 000 P2: P/S No. 101 P3: P/S No. 0001 to 254 P4: Overtravel alarm P5: Overheat alarm P6: Servo alarm P7: System alarm P8: APC alarm P9: Spindle alarm P10: P/S alarm No. 5000 to 5999 P15: External al
Page 89GFKE-0222-EN 1. DISPLAY AND OPERATION 6) MDI/soft key of path 2 T 5 4 P 0 to 1 H * * ; P0: Usually P1: At power–on H **: KCB code (See the following table.) 7) Signal of path 2 T 5 5 P 2, 6 N 1000 to 1255 H * * , * * ; New data Old data P2: G1000 and above P6: F1000 and above N***: DI/DO number H **
Page 901. DISPLAY AND OPERATION GFKE-0222-EN Key codes (MDI/soft key) (00H to 7FH) 0 1 2 3 4 5 6 7 0 Space 0 @ P 1 ! 1 A Q 2 ” 2 B R 3 # 3 C S 4 $ 4 D T 5 % 5 E U 6 & 6 F V 7 ’ 7 G W 8 ( 8 H X 9 ) 9 I Y A ; * : J Z (EOB) B + K [ C ’ < L ¥ D – = M ] E . > N F / ? O – 60
Page 91GFKE-0222-EN 1. DISPLAY AND OPERATION (80H to FFH) 8 9 A B C D E F 0 Reset F0 * * 1 MMC F1 * * 2 CNC F2 * * 3 F3 * 4 Shift Insert F4 * * 5 Delete F5 * * 6 CAN Alter F6 * * 7 F7 * 8 Cur→ Input POS F8 * * * * 9 Cur← PROG F9 * * * A Cur↓ Help OFFSET * * SETTING * B Cur↑ SYSTEM * * C MESSAGE * D CUSTOM
Page 921. DISPLAY AND OPERATION GFKE-0222-EN 1.6.5 (1) While the operation history screen is displayed, no information can be Notes recorded to the history. (2) An input signal having an on/off width of up to 16 msec is not recorded in the history. Some signals are not recorded in the history. (3) Once the
Page 93GFKE-0222-EN 1. DISPLAY AND OPERATION 1.7 HELP FUNCTION 1.7.1 The help function displays alarm information, operation method and a table of contents for parameters. This function is used as a handbook. General 1.7.2 Press HELP key on any screen other than PMC screen, then a help screen Display Metho
Page 941. DISPLAY AND OPERATION GFKE-0222-EN D Help for operation (1) Press [2 OPR], then a menu for operation method is displayed. HELP (OPERATION METHOD) O1234 N12345 1. PROGRAM EDIT 2. SEARCH 3. RESET 4. DATA INPUT WITH MDI 5. DATA INPUT WITH TAPE 6. OUTPUT 7. INPUT WITH FANUC CASSETTE 8. OUTPUT WITH FA
Page 95GFKE-0222-EN 1. DISPLAY AND OPERATION D Parameter table Press soft key [PARAM], then a parameter table is displayed. HELP (PARAMETER TABLE) O1234 N12345 1/4 Current page/ Total ·SETTING (NO.0000~ ) page ·READER/PUNCHER INTERFACE (NO.0100~ ) ·AXIS CONTROL/SETTING UNIT (NO.1000~ ) ·COORDINATE SYSTEM (
Page 961. DISPLAY AND OPERATION GFKE-0222-EN 1.8 DISPLAYING DIAGNOSTIC PAGE 1.8.1 (1) Press SYSTEM key. Displaying Diagnostic (2) Press soft key [DGNOS], then a diagnostic screen is displayed. Page 1.8.2 Contents Displayed D Causes when the 000 WAITING FOR FIN SIGNAL An auxiliary function is being machine
Page 97GFKE-0222-EN 1. DISPLAY AND OPERATION D Cause of the cycle start LED turned off 020 CUT SPEED UP/DOWN 1 0 0 0 1 0 0 021 RESET BUTTON ON 0 0 1 0 0 0 0 022 RESET AND REWIND ON 0 0 0 1 0 0 0 023 EMERGENCY STOP ON 1 0 0 0 0 0 0 024 RESET ON 1 1 1 1 0 0 0 025 STOP MOTION OR DWELL 1 1 1 1 1 1 0 Input of e
Page 981. DISPLAY AND OPERATION GFKE-0222-EN D C executor status DGN 045 C executor status [Data type] Byte [Valid data range] 0 to 255 C executor status 0: Normal. 2: Inoperable because of an incorrect FROM content. 3: Inoperable because the power was switched on with the M and 0 keys held down. 5: Inoper
Page 99GFKE-0222-EN 1. DISPLAY AND OPERATION #7 #6 #5 #4 #3 #2 #1 #0 DGN 201 ALD EXP Overload 0 – – – Motor overheat alarm 1 – – – Amplifier overheat Disconnec- 1 – – 0 Built–in pulse coder (hand) tion alarm 1 – – 1 Disconnection of separated type pulse coder (hard) 0 – – 0 Disconnection of pulse coder (so
Page 1001. DISPLAY AND OPERATION GFKE-0222-EN D Details of separate serial pulse coder alarms #7 #6 #5 #4 #3 #2 #1 #0 DGN 205 OHA LDA BLA PHA CMA BZA PMA SPH #7(OHA): Overheat occurred in the separate pulse coder. #6(LDA): An LED error occurred in the separate pulse coder. #5(BLA): A low battery voltage occ
Page 101GFKE-0222-EN 1. DISPLAY AND OPERATION D Reference position shift function DGN 302 Distance from the end of the deceleration dog to the first grid point [Data type] Two–word axis [Units of data] 0.001 mm (metric output), 0.0001 inch (inch output) [Valid data range] –99999999 to 99999999 D Position de
Page 1021. DISPLAY AND OPERATION GFKE-0222-EN D Machine coordinates of angular axis/orthogonal axis DGN 306 Machine coordinates of a slant axis in the Cartesian coordinate system DGN 307 Machine coordinates of an orthogonal axis in the Cartesian coordinate system [Data type] Two–word [Unit of data] Incremen
Page 103GFKE-0222-EN 1. DISPLAY AND OPERATION NOTE 1 The temperature data must fall within the following ranges. 50_C to 160_C "5_C 160_C to 180_C "10_C 2 The temperature at which an overheat alarm is issued has a maximum error of 5_C. 3 Information on axes other than the αi servo axis is not indicated. (In
Page 1041. DISPLAY AND OPERATION GFKE-0222-EN D FSSB status #7 #6 #5 #4 #3 #2 #1 #0 DGN 320 CFE ERR ERP OPN RDY OPP CLS Indicates the internal status of the FSSBC. #0(CLS): Closed. #1(OPP): Running OPEN protocol. #2(RDY): Open and ready. #3(OPN): Open. #4(ERP): Running ERROR protocol. #5(ERR): #7(CFE): Enco
Page 105GFKE-0222-EN 1. DISPLAY AND OPERATION #2(DUA): 0 : The slave of interest is not on the first axis of the two–axis amplifier. 1 : The slave of interest is on the first axis of the two–axis amplifier. #3(EXT): 0 : The slave of interest does not exist. 1 : The slave of interest exists. #7 #6 #5 #4 #3 #
Page 1061. DISPLAY AND OPERATION GFKE-0222-EN D Details of invalid servo parameter setting alarms (on the servo side) DGN 352 Detail number for invalid servo parameter setting alarm Indicates information that can be used to identify the location (parameter) and cause of an invalid servo parameter setting al
Page 107GFKE-0222-EN 1. DISPLAY AND OPERATION Detail Parameter Cause Measure number number 0754 2075 The setting of the parameter listed at the This parameter is presently not in use. 0755 left has overflowed. Specify 0 in it. 0764 2076 The setting of the parameter listed at the This parameter is presently
Page 1081. DISPLAY AND OPERATION GFKE-0222-EN Detail Parameter Cause Measure number number 1393 2139 The setting of the linear motor AMR offset Decrease the setting of the parameter has exceeded ±45. listed at the left to within ±45. 1446 2144 The cutting feedforward coefficient for the Use the position gai
Page 109GFKE-0222-EN 1. DISPLAY AND OPERATION DGN 362 Cumulative command pulse count (SV) [Data type] Two–word axis [Unit of data] Detection unit [Valid data range] –99999999 to 99999999 Indicates the cumulative count of movement command and compensation pulses received at the servo section since the power
Page 1101. DISPLAY AND OPERATION GFKE-0222-EN D Flexible synchronization error DGN 390 Flexible synchronization error (A) DGN 391 Flexible synchronization error (B) DGN 392 Flexible synchronization error (C) DGN 393 Flexible synchronization error (D) [Data type] Two–word [Units of data] Detection units [Val
Page 111GFKE-0222-EN 1. DISPLAY AND OPERATION DGN 401 Serial spindle alarm state of First spindle DGN 402 Serial spindle alarm state of Second spindle DGN 403 First spindle motor temperature DGN 404 Second spindle motor temperature [Data type] Byte [Unit of data] _C [Valid data range] 0 to 255 The αi spindl
Page 1121. DISPLAY AND OPERATION GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 DGN 409 SPE S2E S1E SHE Refer to this diagnosis when alarm 750 has generated. #3 (SPE) In spindle serial control serial spindle parameters 0 : Satisfy start condition of spindle unit 1 : Do not satisfy start condition of spindle unit #2 (
Page 113GFKE-0222-EN 1. DISPLAY AND OPERATION #7 #6 #5 #4 #3 #2 #1 #0 DGN 430 SS4 SS3 SSR SIC #4(SS4) 0 : Specifies not to use the fourth spindle under spindle serial control. 1 : Specifies to use the fourth spindle under spindle serial control. #3(SS3) 0 : Specifies not to use the third spindle under spind
Page 1141. DISPLAY AND OPERATION GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 DGN 439 SPE S4E S3E SHE #3(SPE): Indicates the state of the serial spindle parameter (third and fourth spindles) for spindle serial control, as follows: 0 : The start condition for the spindle unit is satisfied. 1 : The start condition fo
Page 115GFKE-0222-EN 1. DISPLAY AND OPERATION DGN 451 Spindle distribution during rigid tapping [Data type] Word [Unit of data] Detection units DGN 454 Accumulated spindle distribution during rigid tapping [Data type] Two–word [Unit of data] Detection units DGN 455 Instantaneous difference for the move comm
Page 1161. DISPLAY AND OPERATION GFKE-0222-EN CAUTION 1 If SPL and SCF are set to 1 and #1, #2, and #3 are set to 0 in polygon synchronization mode, the operation is normal. 2 If the status does not change, even though PST is set to 1 and the program is stopped in a block including G51.2, one of the spindle
Page 117GFKE-0222-EN 1. DISPLAY AND OPERATION This data indicates the cause of P/S alarm 5018 or 218. #7 #6 #5 #4 #3 #2 #1 #0 DGN 471 NPQ PQE NSP SUO QCL PCL #0 to #3 Cause of P/S alarm No. 5018 P/S alarm No. 5018 can be cleared by issuing a reset. The cause indication is retained until the cause is removed
Page 1181. DISPLAY AND OPERATION GFKE-0222-EN The specified synchronization mode status is displayed. DGN 474 Rotation ratio of the master axis in spindle polygon synchronization (specified P value) In spindle polygon synchronization mode, the rotation ratio (specified P value) of the current master axis (f
Page 119GFKE-0222-EN 1. DISPLAY AND OPERATION D State of remote buffer (protocol A) DGN 500 Send command 1: SYN 2: RDY 3: RST 4: ALM 5: SAT 6: GTD 7: RTY 8: SDI DGN 501 Receive command 1: SYN 2: RDY 3: ARS 4: AAL 5: CLB 6: SET 7: DAT 8: EOD 9: WAT 10: RTY 11:RDI 12: SDO DGN 502 State of remote buffer 0: Not
Page 1201. DISPLAY AND OPERATION GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 DGN 513 Indicates the internal information about the HSSB (open CNC). (Hidden function) #7 #6 #5 #4 #3 #2 #1 #0 DGN 515 Indicates the internal information about the HSSB (channel 2). (Hidden function) #7 #6 #5 #4 #3 #2 #1 #0 DGN 516 Indic
Page 121GFKE-0222-EN 1. DISPLAY AND OPERATION D Diagnostic data related to a small–diameter peck drilling cycle (M series only) DGN 520 Total number of retractions during cutting after G83 is specified Executing the G83 command clears the value to zero. DGN 521 Total number of retractions made by receiving
Page 1221. DISPLAY AND OPERATION GFKE-0222-EN D Diagnostic data related to simple synchronous control DGN 540 Difference in the position error between the master and slave axes in simple synchro- nas control DGN 541 Difference in the position error between the master and slave axes in simple synchro- nas co
Page 123GFKE-0222-EN 1. DISPLAY AND OPERATION The data items displayed on the diagnosis screen are obtained at the following positions: Semi–closed loop error (No. 551) Motor Command + + + S Kp Speed Machine - + control - Servo amplifier Ps Conversion coefficients Closed loop error (Parameters No. 2078 and
Page 1241. DISPLAY AND OPERATION GFKE-0222-EN D FSSB2 status #7 #6 #5 #4 #3 #2 #1 #0 DGN 620 CFE ERR ERP OPN RDY OPP CLS Indicates the internal status of the FSSBC2. #0(CLS): Closed. #1(OPP): Running OPEN protocol. #2(RDY): Open and ready. #3(OPN): Open. #4(ERP): Running ERROR protocol. #7(CFE): Encountered
Page 125GFKE-0222-EN 1. DISPLAY AND OPERATION #7 #6 #5 #4 #3 #2 #1 #0 DGN 630 EXT DUA ST1 ST0 #7 #6 #5 #4 #3 #2 #1 #0 DGN 632 EXT DUA ST1 ST0 to #7 #6 #5 #4 #3 #2 #1 #0 DGN 648 EXT DUA ST1 ST0 #0, #1(ST0, ST1): Indicates the type code for an actually connected slave. ST1 ST0 Type Address 0 0 A Servo amplifi
Page 1261. DISPLAY AND OPERATION GFKE-0222-EN Slave units and the associated diagnosis numbers Slave unit 00 ³ Diagnosis No. 630, No. 631 Slave unit 01 ³ Diagnosis No. 632, No. 633 Slave unit 02 ³ Diagnosis No. 634, No. 635 Slave unit 03 ³ Diagnosis No. 636, No. 637 Slave unit 04 ³ Diagnosis No. 638, No. 63
Page 127GFKE-0222-EN 1. DISPLAY AND OPERATION DGN 732 Warning status of third spindle DGN 733 Warning status of fourth spindle [Data type] Word If an error (the yellow LED flashes and the error number appears) or warning occurred in the αi spindle amplifier module (SPM), the number is displayed on the diagn
Page 1281. DISPLAY AND OPERATION GFKE-0222-EN 1.9 CNC STATE DISPLAY ACTUAL POSITION (ABSOLUTE) O1000 N00010 X 217.940 Y 363.233 Z 0.000 PART COUNT 5 RUN TIME 0H15M CYCLE TIME 0H 0M38S ACT.F 3000MM/M S 0 T0000 MEM STRT MTN *** 09:06:35 [ ABS ] [ REL ] [ ALL ] [ HNDL ] [ OPRT ] · Indicates the current status
Page 129GFKE-0222-EN 1. DISPLAY AND OPERATION (3) Automatic operation status MTN: Program–specified axis movement is under way. DWL: Program–specified dwell command (G04) is being executed. ***: Other status (4) Auxiliary function status FIN: The completion signal FIN for an auxiliary function is being awai
Page 1301. DISPLAY AND OPERATION GFKE-0222-EN 1.10 Tuning becomes easier by graphically displaying servo error amount and torque command, etc. (Graphic option is required). WAVEFORM DIAGNOSTIC The following two types of waveform diagnosis functions are supported: FUNCTION (1) One–shot type The one–shot type
Page 131GFKE-0222-EN 1. DISPLAY AND OPERATION DGN 3121 Selection of data of waveform diagnosis storage type [Data type] Byte The sixth–type sampling data of storage type of the waveform diagnosis function is: 0 : Thermal simulation data 1 : Spindle load meter data of the first spindle 1.10.2 1.Press the SYS
Page 1321. DISPLAY AND OPERATION GFKE-0222-EN (2) Sampling period: Set the period during which data will be sampled. Valid data range: 10 to 32760 Units: ms (3) Trigger: Set the PMC address and bit for the signal used to trigger the start of data sampling, when 1 or 2 is set for the start condition. Example
Page 133GFKE-0222-EN 1. DISPLAY AND OPERATION D Waveform diagnosis (1) Display start condition parameters (storage 100 : Draws a waveform for the stored data. type) (2) Sampling period: Invalid (3) Trigger: Invalid (4) Data number: The table below lists the numbers of the data items for which a waveform can
Page 1341. DISPLAY AND OPERATION GFKE-0222-EN 1.10.3 1. Press soft key [W.GRPH], then graph of waveform diagnosis is Graphic of Wave displayed. Diagnosis data WAVE DIAGNOSE (GRAPHIC) CH1 CH2 1.0 1.0 0.5 0.5 0 0 –0. –0. 5 5 –1. –1. 0 0 [START] [TIME³] [²TIME] [H–DOBL] [H–HALF] 2. Press soft key [(OPRT)], the
Page 135GFKE-0222-EN 1. DISPLAY AND OPERATION Pressing the [SATART] soft key starts data sampling. While sampling is being performed, SAMPLING blinks at the top of the screen. Once data sampling has been completed, a waveform is automatically displayed. WAVE DIAGNOS. (GRAPHIC) O1234 N12345 CH1 CH2 EDIT ****
Page 1361. DISPLAY AND OPERATION GFKE-0222-EN 1.10.4 (1) Press the SYSTEM function key. Pressing the menu continuation key [ ] Data Sampling for displays the [W.DGNS] soft key. Press this soft key to display the Storage Type WAVE DIAGNOS. (PARAMETER) screen. Waveform Diagnosis (2) Press the [W.MEM] soft key
Page 137GFKE-0222-EN 1. DISPLAY AND OPERATION CAUTION 1 Data items for which ***** is displayed cannot be set. 2 To change the sampling axes, enter new axis names then press the [SELECT] soft key. Pressing the [SLELCT] soft key without entering an axis name results in no sampling axis being set. 3 If the sa
Page 1381. DISPLAY AND OPERATION GFKE-0222-EN NOTE With parameter No. 3121, choose whether the sixth–type sampling data is thermal simulation data or spindle load meter data. When spindle load meter is selected, the spindle data of the first axis is stored with each path. (4) Sampling axis: The axes along w
Page 139GFKE-0222-EN 1. DISPLAY AND OPERATION D Output to FANUC Floppy 1) Select EDIT mode. Cassette or FA Card 2) Press the SYSTEM key, then display the WAVE DIAGNOS. (MEMORY) screen. 3) Open the write protect tab on the floppy disk or card. 4) Press the [W.MEM], , [PUNCH], and [EXEC] soft keys, in this or
Page 1401. DISPLAY AND OPERATION GFKE-0222-EN D Output format In the servo alarm format, the header, date and time, selected axes, and waveform diagnosis data are output in this order. Data items are identified by ten identifier words. Output data other than the identifier words varies with the data type. T
Page 141GFKE-0222-EN 1. DISPLAY AND OPERATION 4) Waveform diagnosis data T 6 0 D * * , * * , * * , to * * , T 6 1 D * * , * * , * * , to * * , T 6 2 D * * , * * , * * , to * * , T 6 3 D * * , * * , * * , to * * , T 6 4 D * * , * * , * * , to * * , T 6 5 D * * , * * , * * , to * * , T 6 6 D * * , * * , * * ,
Page 1421. DISPLAY AND OPERATION GFKE-0222-EN 1.11 Load meter of the servo axis and the serial spindle and the speed meter can be displayed. OPERATING MONITOR 1.11.1 1. Set a parameter to display operating monitor. (Bit 5 (OPM) of Display Method parameter No.3111) 2. Press the POS key to display the positio
Page 143GFKE-0222-EN 1. DISPLAY AND OPERATION 1.11.2 Parameters #7 #6 #5 #4 #3 #2 #1 #0 DGN 3111 OPS OPM [Data type] Bit OPM Operating monitor display is: 0 : Disabled 1 : Enabled OPS The speed meter on the operating monitor screen displays: 0 : Spindle motor speed 1 : Spindle speed DGN 3151 Axis number for
Page 1441. DISPLAY AND OPERATION GFKE-0222-EN 1.12 LIST OF OPERATIONS Reset Data Param- Func- protec- Function eter Mode tion Operation tion write=1 button key Resetting run hour [(OPRT)] [RUNPRE]→[EXEC] – POS Resetting no. of [(OPRT)] [PTSPRE]→[EXEC] machined parts – POS Resetting OT alarm At Pow- er ON –
Page 145GFKE-0222-EN 1. DISPLAY AND OPERATION Input/Output with FANUC Cassette Data Param- Func- protec- Function eter Mode tion Operation tion write=1 button key Heading a file EDIT PROG N →File no.→[ " ]→[F SRH]→[EXEC] Deleting a file OFF EDIT PROG N →File no.→[ " ]→[DELETE→[EXEC] Collating a program EDIT
Page 1461. DISPLAY AND OPERATION GFKE-0222-EN Output to FANUC Cassette Data Param- Func- protec- Function eter Mode tion Operation tion write=1 button key EDIT [(OPRT)]→[ " ]→[PUNCH]→[EXEC] or SYSTEM Output of Emer- parameter (PA- gency Stop RAM) [ " ]→[I/O]→(CANNEL NO) 1 INPUT →(DEVICE Output of PMC SYSTEM
Page 147GFKE-0222-EN 1. DISPLAY AND OPERATION Edit Data Param- Func- protec- Function eter Mode tion Operation tion write=1 button key Display of memory [LIB] EDIT PROG capacity used Deleting all OFF EDIT PROG O →–9999→ DELETE programs OFF Deleting a program EDIT PROG O →Program no.→ DELETE Deleting several
Page 1481. DISPLAY AND OPERATION GFKE-0222-EN Clear Data Param- Func- prote- Function eter Mode tion Operation ction write=1 key key Memory all clear RESET M/T : AND DELETE On 2path are controlled On 2path are controlled At power Path1 : CAN AND 1 ON Path2 : CAN AND 2 Loader is controlled : CAN AND 5 Parame
Page 149GFKE-0222-EN 1. DISPLAY AND OPERATION Manual operation KEY PWE Func- Function Mode Operation SW =1 tion key Manual refer- Turn on Reference point return switch ³ Turn on +X, –X, +Z, or –Z ³ ence point JOG Reference point return switch LED lit. return Turn on +X, –X, +Z, or –Z ³ Use JOG FEEDRATE to s
Page 1501. DISPLAY AND OPERATION GFKE-0222-EN Function KEY PWE Func- Mode Operation SW =1 tion key Alarm history display MESSAGE [HISTRY] Screen erase Press the CAN and function keys simultaneously. The function key — — causes re–display. Screen switching between NC SHIFT and HELP and loader Graphics functi
Page 151GFKE-0222-EN 1. DISPLAY AND OPERATION Function KEY PWE Func- Mode Operation SW =1 tion key Tool path dia- gram data Press the GRAPH key several times ³ Display “PATH GRAPHIC setting GRAPH (PARAMETER)” screen ³ [PARAM ] ³ Enter numerals using numeric keys ³ INPUT Tool path drawing Press the GRAPH key
Page 1521. DISPLAY AND OPERATION GFKE-0222-EN Function KEY PWE Func- Mode Operation SW =1 tion key Re–drawing of “SOLID GRAPHIC Press the GRAPH key several times ³ “SOLID GRAPHIC (PARAME- GRAPH (PARAMETER)” screen ³ [REVIEW] ³ [(OPRT)] ³ [ ANEW ] ³ TER)” in a different [+ ROT ][– ROT ][+TILT ][–TILT ] orien
Page 153GFKE-0222-EN 1. DISPLAY AND OPERATION Boot KEY PWE Func- Function Mode Operation SW =1 tion key System mon- Pow- itor screen er–on — and a soft key at its left display time Reading file Place the cursor at 1. SYSTEM DATA LOADING on the system monitor from memory screen ³ [SELECT] ³ Place the cursor
Page 1541. DISPLAY AND OPERATION GFKE-0222-EN 1.13 WARNING SCREEN DISPLAYED WHEN AN OPTION IS CHANGED D Warning screen This CNC displays a warning screen when the configuration of the options using the SRAM area is changed. The data for the function indicated on the screen is cleared the next time the syste
Page 155GFKE-0222-EN 1. DISPLAY AND OPERATION D Allocation error screen When an option which uses the SRAM area is added, the system software may require more SRAM than is currently installed in the system. In this case, an allocation error screen appears the first time the system is turned on after the add
Page 1561. DISPLAY AND OPERATION GFKE-0222-EN 1.14 When an attempt is made to turn on the power to the CNC after replacing the system software, the screen shown below is displayed, and the system WARNING SCREEN is not started if the replacing new system software is not compatible with DISPLAYED WHEN the rep
Page 157GFKE-0222-EN 1. DISPLAY AND OPERATION 1.15 The maintenance information screen is provided to record the history of maintenance performed by a service person of FANUC or machine tool MAINTENANCE builder. INFORMATION The screen has the following features: SCREEN D MDI alphabetical input is allowed. D
Page 1581. DISPLAY AND OPERATION GFKE-0222-EN Status display ⋅ OVER/INSERT : OVER : Overwrite mode ; INSERT: Insert mode ⋅ EDIT/VIEW : EDIT : Editing allowed ; VIEW : Editing inhi bited ⋅ Number of empty character spaces ⋅ Current cursor line ⋅ Current cursor column D Screen operation The maintenance inform
Page 159GFKE-0222-EN 1. DISPLAY AND OPERATION Operation of the soft keys (1) View mode Edit Jump (2) (5) (2) Edit mode END I/O ALLDEL Jump (3) (4) (6) (5) (3) Edit saving MAINTE- NANCE IGNORE CANCEL (1) (1) (2) (4) I/O READ PUNCH CANCEL (6) (6) (2) (5) Jump BEGIN- END CANCEL ING (1) (2) (1) (2) (1) (2) (6)
Page 1601. DISPLAY AND OPERATION GFKE-0222-EN 1.15.2 The maintenance information can be read and punched. Maintenance When the maintenance information is input from or output to a memory card, a file name MAINTINF.DAT is used. Information (1) Format Input/Output %% Data (2) Reading When a MAINTINF.DAT file
Page 161GFKE-0222-EN 1. DISPLAY AND OPERATION 1.16 When VGA screen display is selected (NVG bit (bit 7 of parameter 3119) is set to 0), the color scheme of the VGA screen can be set on the color COLOR SETTING setting screen. SCREEN 1.16.1 1. Press the SYSTEM function key. Screen Display 2. Press the continu
Page 1621. DISPLAY AND OPERATION GFKE-0222-EN 4. Press the [LIGHT] or [DARK] operation soft key to change the luminance of the selected color element. D Storing colors A specified color palette value can be stored. (color palette values) STORE CALL COLOR1 COLOR2 COLOR3 + 1. Select a desired storage area by
Page 163GFKE-0222-EN 1. DISPLAY AND OPERATION 1.16.3 Parameters #7 #6 #5 #4 #3 #2 #1 #0 3119 NVG [Data type] Bit NVG When a color display unit is used, the VGA screen display is: 0 : Selected. 1 : Not selected. (Conventional display) 6561 Standard color data of graphic color 1 6562 Standard color data of gr
Page 1641. DISPLAY AND OPERATION GFKE-0222-EN 6590 Standard color data of text color 10 6591 Standard color data of text color 11 6592 Standard color data of text color 12 6593 Standard color data of text color 13 6594 Standard color data of text color 14 6595 Standard color data of text color 15 [Data type
Page 165GFKE-0222-EN 1. DISPLAY AND OPERATION 1.17 Depending on the eye level and the viewing angle of the operator, the LCD may be hard to read. This problem can be solved by adjusting the contrast. CONTRAST The contrast of a monochrome LCD can be adjusted. ADJUSTMENT 1. Press the OFFSET SETTING function k
Page 1661. DISPLAY AND OPERATION GFKE-0222-EN Adjustment procedure (1) Contrast adjustment Potentiometer VRP1 This adjustment is made to compensate for variations between, individual LCD adapters and LCD panels. When an LCD adapter or panel is replaced, the following adjustment must be made. If the entire L
Page 167GFKE-0222-EN 1. DISPLAY AND OPERATION NOTE If the ambient temperature is low, the brightness of the LCD decreases (immediately after the power is turned on, in particular). This is due to the characteristics of the LCD, and does not indicate a fault. As the ambient temperature rises, the LCD becomes
Page 1681. DISPLAY AND OPERATION GFKE-0222-EN 1.18 When the Power Motion series is used as an additional axis (slave) of the CNC, the power motion manager allows the slave data to be displayed and POWER MOTION set by the CNC. MANAGER The power motion manager enables the following display and setting: (1) Cu
Page 169GFKE-0222-EN 1. DISPLAY AND OPERATION NOTE 1 The parameters are valid only when I/O link count extension is supported (two channels are supported). 2 Even when 0 is set, Power Mate CNC Manager communicates with channel 1 if the β amplifier with I/O links is not connected to channel 2. 3 When 1 is se
Page 1701. DISPLAY AND OPERATION GFKE-0222-EN D System configuration This screen displays the system software information of the slave. The screen screen is displayed first when the power motion manager function is selected. This screen is automatically displayed also at the termination of the function. 1.
Page 171GFKE-0222-EN 1. DISPLAY AND OPERATION 2. Press the [PARAM] soft key. The parameter screen appears. POWER MOTION MANAGER PARAMETER 1.GROUP0 / β 0000 00001000 0010 11110000 0001 00010101 0011 01010000 0002 11111011 0012 00000000 0003 00000000 0013 00000000 0004 00000000 0014 10110001 0005 10100001 001
Page 1721. DISPLAY AND OPERATION GFKE-0222-EN D Diagnosis screen This screen shows the current status of the slave. 1. Press the [SYSTEM] function selection soft key. The following soft keys appear: [ PARAM ][ DGNOS ][ ][SYSTEM][ ] 2. Press the [DGNOS] soft key. The diagnosis screen appears. The displayed d
Page 173GFKE-0222-EN 1. DISPLAY AND OPERATION D Alarm screen If an alarm is issued during operation, the group number of the slave causing the alarm is indicated at the right end of the message field on the screen. Check the details on the alarm screen. For example, (13) means that the first and third power
Page 1741. DISPLAY AND OPERATION GFKE-0222-EN When five or more slaves are connected, the four–slave display has two or more pages. To see the slave data that is not displayed on the current page, press soft key [±NEXT]. POWER MOTION MANAGER/ SYSTEM CONFIGURATION O12345678 N12345 1.GROUP0 / β O12345678 N123
Page 175GFKE-0222-EN 1. DISPLAY AND OPERATION D Guidance message While the following soft keys are being displayed, a guidance message is displayed in the message field. [ POS ][ ][ ][SYSTEM][ MSG ] [ WORK ][ ][MACHIN ][ ][ ] [ PARAM ][ DGNOS ][ ][SYSTEM][(OPRT) ] When the soft keys are displayed as shown a
Page 1761. DISPLAY AND OPERATION GFKE-0222-EN Specify a desired input device in the MD1 and MD2 bits (bits 1 and 2 of parameter 960). Connect a memory card. Alternatively, check the free area of CNC memory. Then, follow the steps given below: 1. Select the active slave. 2. Press the [(OPRT)] soft key. The f
Page 177GFKE-0222-EN 1. DISPLAY AND OPERATION 1.18.4 Notes D Connecting an I/O Link When the Power Motion series is used as a slave of an I/O Link, the CNC assigns I/O addresses. The salve data is input and output in units of 16 bytes. Therefore, 128 input/output points are necessary. Up to eight slaves can
Page 1781. DISPLAY AND OPERATION GFKE-0222-EN 1.19 Using the periodic maintenance screens makes it easy to manage consumables (such as LCD unit backlight and backup battery) that are to PERIODIC be replaced periodically. MAINTENANCE SCREENS Setting the name and service life of consumables, and the countdown
Page 179GFKE-0222-EN 1. DISPLAY AND OPERATION 1.19.3 Up to 10 consumable items can be registered for management. Their Status Screen Display remaining service time and count status are displayed on the status screen. and Setting PERIODICAL MAINTENANCE O0001 N12345 (STATUS) ITEM NAME REMAIN *01 BATTERY FOR C
Page 1801. DISPLAY AND OPERATION GFKE-0222-EN Format G10 L61 Px [n] x… Registration number n… Item name [Alphanumeric characters*two–byte characters*alphanumeric characters] (b) MDI keypad–based registration An item name can be registered on the machine system menu screen by first entering it in the followi
Page 181GFKE-0222-EN 1. DISPLAY AND OPERATION To erase the registered data for an item, place the cursor on the target item name, and press soft key [CLEAR], then soft key [EXEC]. [Machine system] menu screen PERIODICAL MAINTENANCE O0001 N12345 (MACHINE) ITEM NAME 01 02 03 04 05 06 07 08 09 10 >_ EDIT *** *
Page 1821. DISPLAY AND OPERATION GFKE-0222-EN [NC system] menu screen PERIODICAL MAINTENANCE O0001 N12345 (NC) ITEM NAME 01 BATTERY FOR CONTROLLER 02 BATTERY FOR PULSECODER 03 FAN MOTOR 04 LCD BACK LIGHT 05 06 07 08 09 10 >_ EDIT *** ***** *** **** 19:27:05 [ ][ STATUS ][ MACHIN ][ NC ][ (OPRT) ] [ SELECT ]
Page 183GFKE-0222-EN 1. DISPLAY AND OPERATION NOTE 1 “*” cannot be used in item names, because it is used as control code. “[”, “]”, “(“, or “)” also cannot be used in item names. 2 When both alphanumeric and two–byte characters are used in an item name to be registered, the warning message “DATA IS OUT OF
Page 1841. DISPLAY AND OPERATION GFKE-0222-EN 1.19.4 The setting screen lets you specify the service life, the remaining service Setting Screen Display time, and count type for a registered item name. It also displays the same count status information as displayed on the and Setting status screen. PERIODICA
Page 185GFKE-0222-EN 1. DISPLAY AND OPERATION (2) Remaining service time The remaining service time of an item (the time allowed before the item is replaced) is determined by count–down and displayed under “Remaining service time.” When the remaining service time decreases to a specified percentage (specifi
Page 1861. DISPLAY AND OPERATION GFKE-0222-EN NOTE 1 An attempt to set up the count type for a non–registered item or an item for which the service life has not been set up results in the warning message “EDIT REJECTED”. 2 Soft keys [INPUT] and [+INPUT] are ignored. 3 In leap years, an error of 24 hours occ
Page 187GFKE-0222-EN 1. DISPLAY AND OPERATION a : Service life r : Remaining service time n : Item name [Alphanumeric characters*two–byte characters * alphanumeric characters q : count type 0 = not to count 1 = count at all times 2 = count during power–on time 3 = count during operation 4 = count during cut
Page 1881. DISPLAY AND OPERATION GFKE-0222-EN 1.19.6 FANUC Two–Byte Character Code Table 158
Page 189GFKE-0222-EN 1. DISPLAY AND OPERATION 159
Page 1901. DISPLAY AND OPERATION GFKE-0222-EN 160
Page 191GFKE-0222-EN 1. DISPLAY AND OPERATION 161
Page 1921. DISPLAY AND OPERATION GFKE-0222-EN 162
Page 193GFKE-0222-EN 1. DISPLAY AND OPERATION 163
Page 1942. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN 2 LCD–MOUNTED TYPE i SERIES HARDWARE This chapter describes the printed–circuit board in the i series CNC control unit of LCD–mounted type and the functions of the card PCBs mounted on the printed–circuit board. It also explains how to replace consu
Page 1952. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.1 STRUCTURE Control/LCD unit MDI unit Optical cable Servo motor Servo amplifier I/O Link I/O module, I/O unit MODEL–A Machine operator’s panel/ Power magnetic circuit etc. 165
Page 1962. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN 2.2 OVERVIEW OF HARDWARE 2.2.1 Series 16i/160is 166
Page 1972. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE Serial communication board Motherboard Remote buffer/DNC1/DNC2 CPU for CNC control ⋅ Power supply Sub–CPU board ⋅ 2–axis to 8–axis control ⋅ Spindle control Sub–CPU for 2–path control ⋅ LCD/MDI interface ⋅ 2–axis to 8–axis control ⋅ I/O Link ⋅ Spind
Page 1982. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN 2.2.2 Series 18i/180is Serial communication board Motherboard Remote buffer/DNC1/DNC2 CPU for CNC control ⋅ Power supply Sub–CPU board ⋅ 2–axis to 6–axis control ⋅ Spindle control Sub–CPU for 2–path control ⋅ LCD/MDI interface ⋅ 2–axis to 6–axis con
Page 1992. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.2.3 Series 21i/210is Motherboard CPU for controlling CNC ⋅ Power supply ⋅ 2–axis to 4–axis control ⋅ Spindle interface ⋅ LCD/MDI interface ⋅ I/O Link ⋅ PMC–SB7 ⋅ Analog output (option) ⋅ High–speed DI ⋅ RS–232C × 2 Serial communication board ⋅ Mem
Page 2002. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN 2.3 TOTAL CONNECTION DIAGRAMS 170
Page 2012. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE Common to 16i/18i/21i/160is/180is/210is Motherboard LCD display unit 24V–IN(CP1A) 24 VDC power Soft key cable MDI UNIT CK2 MDI(CA55) CK1 R232(JD36A) RS–232C I/O unit R232(JD36B) RS–232C I/O unit { Touch panel Analog output for tool drive A–OUT&HDI(J
Page 2022. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN When option boards are provided Serial communication Option slot board Remote buffer board DNC1 board DNC2 board R232-3(JD28A) RS–232C I/O unit (when remote buffer board or DNC2 board is used) R422-1(JD6A) RS–422 I/O unit (when remote buffer board o
Page 2032. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE When option boards are provided Circuit breaker Option slot Loader control board 200VAC AC reactor 200VAC MCC Circuit breaker CX1A TB2 CX3 PSM CX4 CX1B TB1 CX2B JX1B TB2 CX2A JX1A COP10B Loader axis 1 FSSB(COP10A) TB2 SVM servo motor COP10A JF1 TB1
Page 2042. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN When option boards are provided Option slot I/O link II board (TB1) To other equipment DeviceNet board (TB1) To other equipment PROFIBUS board PROFIBUS adapter unit Master(JN1) JN2 CN1 To other equipment PROFIBUS adapter unit Slave(JN2) JN2 CN1 To o
Page 2052. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.4 CONFIGURATION OF PRINTED CIRCUIT BOARD CONNECTORS AND CARDS 2.4.1 FS16i/18i/21i Motherboard D Specification Name Specification Series 16i A20B–8100–0660 Series 18i A20B–8100–0661 Series 21i (without Ethernet function, PMC–SA1) A20B–8100–0662 Ser
Page 2062. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D Connector mounting location Connector unit Fan motor Fan motor Battery Rear of unit COP10A–1 COP10A–2 (COP10A is a connector installed on the servo card.) CA69 JD36A JA40 JA41 CP1 CA55 CD38 CN2 JD36B JD44A Motherboard CN3 CN8 JNA CNM1A Motherboard
Page 2072. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE Connector number Application COP10A–1, COP10A–2 Servo amplifier (FSSB) CA55 MDI CA69 Servo check JD36A RS–232C serial port JD36B RS–232C serial port JA40 Analog output/high–speed DI JD44A I/O link JA41 Serial spindle/position coder CP1 24VDC–IN JNA
Page 2082. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D Card and power supply mounting location Connector Connector Connector (1) Axis control (2) Display (3) CPU card card control card Connector (4) Power supply unit No. Name Specification Function Remarks (1) Axis control card A20B–3300–0033 Axis con
Page 2092. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE No. Name Specification Function Remarks (2) Display control A20B–3300–0280 10.4″ color LCD with Graphic software 60V6 series, embedded card graphic function and Ethernet control software series 656A embedded ethernet A20B–3300–0281 8.4″ color LCD wi
Page 2102. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D DIMM module mounting location DIMM module socket (1) FROM/SRAM (2) Analog spindle module module DIMM module socket No. Name Specification Function Remarks (1) FROM/SRAM A20B–3900–0160 FROM 16MB Various control software programs are module SRAM 1MB
Page 211Axis control card Display control card CPU card GFKE-0222-EN SRAM DSP CPU CPU Axis 1/2 D Block diagram G/A DSP control DRAM Axis 3/4 DRAM Axis 5/6 G/A VGA G/A CPU Axis 7/8 Boot peripherals control graphic control ethernet control software FSSBC Local BUS 181 G/A F–BUS PMC control F–BUS control I/O S
Page 2122. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D LED display Rear of unit SRAMP SEMG SVALM SFAIL Alarm (red) LEDG0 LEDG1 LEDG2 LEDG3 Status (green) 182
Page 2132. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE (1) Changes in status LED (green) indication at power–on time No. Status LED Status 1 jjjj Power is not supplied. 2 JJJJ Initial status immediately after power is switched on; boot is running. 3 jJJJ System activation started. 4 JjJJ Waiting for eac
Page 2142. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN 2.4.2 Inverter PCBs and Connector Units Name Specification Inverter For monochrome LCD A20B–8100–0710 P.C.B For 10.4″ color LCD A20B–8001–0920 For 8.4″ color LCD A20B–8001–0922 Connector For unit with no option slot A15L–0001–0060#B unit For unit wi
Page 2152. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE D Connector mounting (1) With 3 or 4 slots location Connector unit Fan motor Fan motor Rear of unit (2) With 2 slots Connector unit Fan motor Fan motor Rear of unit (3) With no slot Connector unit Fan motor Fan motor Battery Rear of unit 185
Page 2162. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D Connector location (1) Inverter PCB (printed–circuit board) (2) Connector unit for no slot type (3) Connector unit for 2–slot type (4) Connector unit for 3–slot and 4–slot types 186
Page 2172. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE Connector number Application CN39A Power supply for fans CN39B CN39C CN39D CP8 Battery CP1 Power supply for LCD backlight CN3 Power supply for inverter PCB 2.4.3 C Board, Serial Communication Board, Symbol CAPi T Board, and PMC–RE Board D Specificat
Page 2182. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D Connector location (1) PMC–RE board JNA F–BUS backplane connector CP8B JD1A2 JD38B JD38A JD6A (2) C board JNA F–BUS backplane connector (3) Serial communication board A remote buffer/DNC2 JNA F–BUS backplane connector JD28A JD6A 188
Page 2192. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE (4) Serial communication board B DNC1 JNA F–BUS backplane connector JD28A JD6A (5) CAP–II board/Symbol CAPi T board JNA F–BUS backplane connector CP8B Connector number Application JD1A2 I/O link JD38B RS–232C serial port JD38A RS–232C serial port JD
Page 2202. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D Card and DIMM module PMC–RE board locations (1) (2) CPU card DRAM module Connector DIMM module socket Note) The DRAM module is mounted on the CPU card. C language board, serial communication board, Symbol CAPi T board (2) DRAM module DIMM module s
Page 221GFKE-0222-EN For the A20B–8100–0026x, the functions equivalent CPU card to the CPU card and mounted on an option board. D Block diagram From lithium battery For PMC–RE DIMM module For symbol CAPi T DRAM and PMC–RE G/A CPU G/A G/A peripheral I/O link control PMC control 191 G/A BUS conversion F–BUS L
Page 2222. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D LED indication Status (green) Alarm (red) Alarm LED (red) indication at system alarm occurrence Alarm: 1 2 3 Cause jjj Usual operation under way Jjj Bus error (L–bus alarm) jJj Bus error or DRAM parity (L–bus EMG) JJj Reset under way jjJ I/O link
Page 2232. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.4.4 Sub–CPU Board D Specification Name7 Specification Sub–CPU board A20B–8002–0190 NOTE The sub–CPU board cannot fit into any of the following slots. · Center slot of a unit with 3 option slots · Option slot farthest from the LCD in a unit with 4
Page 2242. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D Card and DIMM module locations Connector (2) CPU card (1) Axis control Connector card The DRAM module is mounted on the CPU card. No. Name Specification Function Remarks (1) Axis control card A20B–3300–0243 Axis control 2 axes Applicable servo sof
Page 225GFKE-0222-EN Servo card CPU card D Block diagram Axis 1/2 G/A DSP control DRAM Axis 3/4 Axis 5/6 G/A CPU Axis 7/8 peripheral 195 Local BUS G/A G/A F–BUS BUS conversion peripheral (To back panel) control Sub–CPU board 2. LCD–MOUNTED TYPE i SERIES FSSB Serial spindle (to servo amplifier) Analog output
Page 2262. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D LED indication Status (green) Alarm (red) (1) Changes in status LED (green) indication at power–on time Status LED No. Status (LED1, 2) 1 jj Power is not supplied. 2 JJ Initial status immediately after power is switched on; the sub–CPU has not sta
Page 2272. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.4.5 RISC Board D Specification Name Specification RISC board A20B–8100–0170 NOTE The RISC board cannot fit into any of the following slots. · Center slot of a unit with 3 option slots · Option slot farthest from the LCD in a unit with 4 option slo
Page 2282. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D LED indication Alarm (red) Status (green) ALM7 ALM6 ALM5 LED4 LED3 LED2 LED1 (1) Status LED (green) indication (LED lighting) Alarm LED Status (LED4 to LED1) jjjj Power is not supplied. Jjjj CNC wait (1) (Check the CNC for the cause.) Module ID er
Page 2292. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE (2) Status LED (green) indication (LED blinking) Alarm LED Status (LED4 to LED1) Ljjj Command execution in progress (reset) jLLj Command execution in progress (pre–processing, distribution) jjjL Command wait jLjL NC statement input wait LLjL Command
Page 2302. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN 2.4.6 Data Server Board D Specification Name Specification Data server board A20B–8100–0271 (ATA card version) Add–on board A20B–2002–0960 NOTE The data server board (ATA card version) cannot fit into any of the following slots. · Option slot neares
Page 2312. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE D LED indication JNA F–BUS backplane connector LED detail diagram 201
Page 2322. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN LED indication transition at power–on time LED indication No. Ethernet board status 1234 1 STATUS jjjj Power off. 2 STATUS JJJJ Initial status immediately after power is switched on. 3 STATUS jJJJ MPU initialization completed. 4 STATUS jjJJ Firmware
Page 2332. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE LED indication (STATUS) at error occurrence The STATUS LEDs repeat LONG and SHORT patterns. The LONG and SHORT patterns correspond to long and short lighting intervals, respectively. STATUS LED indication No. Ethernet/data server board state LONG SH
Page 2342. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN 2.4.7 Loader Control Board D Specification Name Specification Loader control board A20B–8100–0830 NOTE The loader control board cannot fit into any of the following slots. · Center slot of a unit with 3 option slots · Option slot farthest from the L
Page 2352. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE D Card mounting location (1) (2) Axis control card CPU card JNA Connector Connector JD1A No. Name Specification Function Remarks (1) Axis control card A20B–3300–0033 Axis control 2 axes Applicable servo software: Series 9090 A20B–3300–0032 Axis cont
Page 236Servo card CPU card 2. LCD–MOUNTED TYPE i SERIES Axis 1/2 G/A D Block diagram DSP control DRAM Axis 3/4 HARDWARE G/A CPU peripheral 206 Local BUS G/A PMC control F–BUS F–BUS (To back panel) conversion G/A peripheral control Loader control board From lithium battery FSSB (to servo amplifier) I/O Link
Page 2372. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE D LED indication Alarm (red) Status (green) (1) Changes in status LED (green) indication at power–on time Status LED No. Status (LED1 to 4) 1 jjjj Power is not supplied. 2 JJJJ Initial status immediately after power is switched on; the loader CPU ha
Page 2382. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN (2) Alarm LED (red) indication at system alarm occurrence When any of these alarm LEDs lights, it is likely that the hardware is defective. Alarm LED Meaning ALM1 SRAM parity alarm. ALM2 Servo alarm. ALM3 Lights when a system alarm occurs. Used by t
Page 2392. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE D LED indication Status (green) Alarm (red) (1) Changes in status LED (green) indication at power–on time Status LED No. Status (ST4 to 1) 1 jjjj Power is not supplied. 2 JJJJ Initial status immediately after power is switched on. 3 JJJj HSSB board
Page 2402. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN (3) Alarm LED (red) indication at error occurrence Alarm LED Meaning AL1 HSSB communication was discontinued. AL2 Parity alarm in NC/PC common RAM. D Rotary switch (SW1) setting SW1 Rotary switch setting when the PC or PANEL i is connected By changi
Page 2412. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.4.9 I/O Link–II Board Name Specification FANUC I/O Link–II board A20B–8100–0250 D Connector location JNA F–BUS backplane connector Connector number Application TB1 Terminal board for FANUC I/O Link–II interface D Card location No card is mounted o
Page 2422. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN (1) Hardware control LEDs LED No. Meaning LED5 Lights when the CPU on the FANUC I/O Link–II board is run- ning. When the LED is off, it means that the CPU has been reset. LED6 Lights when a DRAM parity error is detected. It is likely that the hardwa
Page 2432. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.4.10 PROFIBUS Board Name Specification PROFIBUS board (master function) A20B–8100–0430 Add–on board (slave function) A20B–2100–0430 NOTE The PROFIBUS board cannot fit into any of the following slots. · Center slot of a unit with 3 option slots · O
Page 2442. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D LED indication JNA F–BUS backplane connector ADD–ON board LEDs for slave function LEDs for master function LED1 (green) LEDB (red) LEDB (red) LED2 (green) LED2 (green) LED3 (green) LED1 (green) (1) LEDs for master function LED No. Meaning (abbrevi
Page 2452. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.4.11 Ethernet Board Name Specification Ethernet board A20B–8100–0271 NOTE The Ethernet board cannot fit into the option slot nearest to the LCD. D Connector location JNA F–BUS backplane connector Connector number Application CD38 10BASE–T Ethernet
Page 2462. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D LED indication JNA F–BUS backplane connector Detailed LED diagram 216
Page 2472. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE LED indication transition at power–on time LED indication No. Ethernet board status 1234 1 STATUS jjjj Power off 2 STATUS JJJJ Initial status immediately after power is switched on. 3 STATUS jJJJ MPU initialization completed. 4 STATUS jjJJ Firmware
Page 2482. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN LED indication (STATUS) at error occurrence The STATUS LEDs repeat LONG and SHORT patterns. The LONG and SHORT patterns correspond to long and short lighting intervals, respectively. STATUS LED indication No. Ethernet/data server board state LONG SH
Page 2492. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.4.12 DeviceNet Interface Board Name Specification DeviceNet interface board A20B–8001–0880 NOTE The DeviceNet board cannot fit into the center option slot of a unit with 3 option slots D Connector mounting location JNA F–BUS backplane connector Co
Page 2502. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D LED display Daughter board HEALTH NS LEDA LED3 LED2 LED1 LED0 NS and HEALTH are mounted on the back of the daughter board. LED indication Name Color Description LED0 to 3 Green No special meaning LEDA Red This LED glows when something unusual occu
Page 2512. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.5 LIST OF UNITS AND PRINTED CIRCUIT BOARDS 2.5.1 Basic Unit Model Name Drawing number Remarks 16i Basic Unit (No slot) A02B–0281–B500 Basic Unit (2 slots) A02B–0281–B502 Basic Unit (3 slots) A02B–0281–B503 Basic Unit (4 slots) A02B–0281–B504 18i B
Page 2522. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN 2.5.3 MDI Unit Model Name Drawing number Remarks All models T series/English/Small keyboard A02B–0281–C120#TBR Horizontal type, 200 140mm T series/English/Standard keyboard A02B–0281–C121#TBR Vertical/horizontal type, 200 260mm T series/English/Stan
Page 2532. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.5.4 Printed Circuit Boards Name Drawing number ID Remarks Motherboard for 16i A20B–8100–0660 3x08 Motherboard for 18i A20B–8100–0661 3x09 Motherboard for 21i A20B–8100–0662 0x0A (without Ethernet function, PMC–SA1) Motherboard for 21i A20B–8100–06
Page 2542. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN Name Drawing number ID Remarks Display control card A20B–3300–0283 00 (7.2″ monochrome LCD, graphic function, embedded Ethernet function) Display control card A20B–3300–0300 07 (9.5″ monochrome LCD, embedded Ethernet function) Display control card A
Page 2552. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE Name Drawing number ID Remarks FROM/SRAM module A20B–3900–0163 FROM: C2 (FROM 32MB, SRAM 1MB) SRAM: 03 FROM/SRAM module A20B–3900–0164 FROM: C2 (FROM 32MB, SRAM 2MB) SRAM: 04 FROM/SRAM module A20B–3900–0165 FROM: C2 (FROM 32MB, SRAM 3MB) SRAM: 05 FR
Page 2562. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN Name Drawing number ID Remarks Inverter A20B–8100–0710 – (for 9.5″ /7.2″ monochrome LCD) Inverter A20B–8001–0920 – (for 10.4″ color LCD) Inverter A20B–8001–0922 – (for 8.4″ color LCD) PC–side HSSB interface board A20B–8001–0582 – (2CH, applicable to
Page 2572. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.5.5 I/O Name Drawing number Remarks Distributed I/O connector panel I/O module A1 A20B–2002–0470 DI/DO= 72/56 DI=general 16, matrix 56, with MPG interface Distributed I/O connector panel I/O module B1 A20B–2002–0520 DI/DO=48/32, with MPG interface
Page 2582. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN 2.5.6 Other Units Name Drawing number Remarks Separate detector interface unit (basic 4 axes) A02B–0236–C205 Separate detector interface unit (additional 4 axes) A02B–0236–C204 Spindle distributed adapter A13B–0180–B001 I/O Link distributed adapter
Page 2592. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.6 REPLACING THE WARNING MOTHERBOARD Only those personnel who have received approved safety and maintenance training may perform this replacement work. When opening the cabinet and replacing the board, be careful not to touch the high–voltage circu
Page 2602. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN 2) Remove the cables from connectors CNM1A (PCMCIA interface connector), CN8 (video signal interface connector) and CN2 (soft key connector) on the motherboard. Then, unscrew the screws fastening the motherboard. The connector CN3 (inverter connecto
Page 2612. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.7 REPLACING FUSE WARNING ON CONTROL UNIT Before replacing a blown fuse, locate and remove the cause of the blown fuse. For this reason, only those personnel who have received approved safety and maintenance training may perform this replacement wo
Page 2622. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN 2.8 Part programs, offset data, and system parameters are stored in CMOS memory in the control unit. The power to the CMOS memory is backed REPLACING up by a lithium battery mounted on the front panel of the control unit. The BATTERY above data is n
Page 2632. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE Battery case Connector Lithium battery A02B–0200–K102 WARNING Using other than the recommended battery may result in the battery exploding. Replace the battery only with the specified battery (A02B–0200–K102). CAUTION Steps 1) to 3) should be comple
Page 2642. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN When using commercial alkaline dry cells (size D) D Method of connection Power from the external batteries is supplied through the connector to which the lithium battery is connected. The lithium battery, provided as standard, can be replaced with e
Page 2652. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE Replacing 1) Prepare two alkaline dry cells (size D) commercially available. commercial alkaline dry 2) Turn on the power to the control unit. cells (size D) 3) Remove the battery case cover. 4) Replace the cells, paying careful attention to their o
Page 2662. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN 2.9 REPLACING FAN WARNING MOTORS When opening the cabinet and replacing a fan motor, be careful not to touch the high–voltage circuits (marked and fitted with an insulating cover). Touching the uncovered high–voltage circuits presents an extremely d
Page 2672. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE Replacement procedure D For units with no 1. Before replacing a fan motor, turn off the power to the CNC. expansion slots and units with 2 expansion 2. Unplug the connector of a fan motor to be replaced ( (1) of Fig. a). slots The connector is latch
Page 2682. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D For units with 3 or 4 1. Before replacing a fan motor, turn off the power to the CNC. expansion slots 2. Unplug the connector of a fan motor to be replaced ( (1) of Fig. b). The connector is latched. So, when unplugging the connector, hold down th
Page 2692. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.10 REPLACING LCD WARNING BACKLIGHT Only those personnel who have received approved safety and maintenance training may perform this replacement work. When opening the cabinet and replacing a unit, be careful not to touch the high–voltage circuits
Page 2702. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN D Replacement procedure 1) Detach the flat cable for soft keys, then detach the escutcheon from the CNC. Escutcheon Flat cable for soft keys 2) As shown below, unplug the connectors CP1 and CN8 to detach the LCD unit from the CNC unit. LCD unit CP1
Page 2712. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 3)–1 For the 7.2″ LCD units (monochrome) manufactured by Hitachi Remove the three brackets from the left part on the front of the LCD unit, and remove the cover. Then, the backlight is exposed. Replace the backlight with a new one. Connector Bracket
Page 2722. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN 3)–3 For the 8.4″ LCD (color) As shown below, remove two bolts, remove the backlight case by pulling it down and sliding it slightly to the left, then replace the backlight. LCD unit rear view Bolt Backlight 3)–4 For the 9.5″ LCD units (monochrome)
Page 2732. LCD–MOUNTED TYPE i SERIES GFKE-0222-EN HARDWARE 2.11 HEAT GENERATED IN Amount of Unit generated Remarks EACH UNIT heat Control unit No option slot 33W (NOTE 1) 2 option slots 37W 3 option slots 39W 4 option slots 40W Option boards HSSB board 3W Sub–CPU board 13W Loader control board 10W PMC C boa
Page 2742. LCD–MOUNTED TYPE i SERIES HARDWARE GFKE-0222-EN NOTE 1 The amount of heat generated in the LCD and MDI units is included, but that in each option board is not. 2 The amount of heat generated in the ISA expansion board varies from one model to another. Add the amount of heat generated in the ISA b
Page 275GFKE-0222-EN 3. LCD–MOUNTED TYPE is SERIES HARDWARE 3 LCD–MOUNTED TYPE is SERIES HARDWARE This chapter describes the LCD–mounted type FS160is/180is/210is hardware. See Chapter 4 ”STAND–ALONE TYPE i SERIES HARDWARE,” for stand–alone type 160is/180is/210is hardware. 3.1 HARDWARE CONFIGURATION . . . .
Page 2763. LCD–MOUNTED TYPE is SERIES HARDWARE GFKE-0222-EN 3.1 See section 2.1 for hardware configuration of 160is/180is/210is. HARDWARE CONFIGURATION 3.2 See section 2.2 for hardware overview of 160is/180is/210is. HARDWARE OVERVIEW 3.3 TOTAL CONNECTION DIAGRAMS For the 160is/180is/210is, the following con
Page 277GFKE-0222-EN 3. LCD–MOUNTED TYPE is SERIES HARDWARE 3.4 FS160is/180is/210is MOTHERBOARD D Specifications Item Code Series 160is motherboard A20B–8100–0790 Series 180is motherboard A20B–8100–0791 Series 210is motherboard (PMC–SA1) A20B–8100–0794 Series 210is motherboard (PMC–SB7) A20B–8100–0795 247
Page 2783. LCD–MOUNTED TYPE is SERIES HARDWARE GFKE-0222-EN D Mounting positions of connectors Connector unit Fan motor Fan motor Battery Rear of unit COP10A–1 COP10A–2 (COP10A is a connector installed on the servo card.) JD36A JA40 JA41 JD36B JD44A CP1 CA69 CN2 CD38S CA55 CD38A CA75 Motherboard CN8 CN3 JNA
Page 279GFKE-0222-EN 3. LCD–MOUNTED TYPE is SERIES HARDWARE Connector number Use JD48 PC side RS232C, USB COP10A–1, COP10A–2 Servo motor (FSSB) CA55 MDI CA69 Servo check JD36A RS232C serial port JD36B RS232C serial port JA40 Analog output/High–speed DI JD44A I/O Link JA41 Serial spindle/Position coder CP1 D
Page 2803. LCD–MOUNTED TYPE is SERIES HARDWARE GFKE-0222-EN D Mounting positions of cards (1) (2) (3) Axis control card CE card CPU card Connector Connector Connector DIMM module DIMM module Connector (4) Power supply unit No. Name Code Function Remarks (1) Axis control card A20B–3300–0033 Axis control 2–ax
Page 281GFKE-0222-EN 3. LCD–MOUNTED TYPE is SERIES HARDWARE No. Name Code Function Remarks (3) CPU card A20B–3300–0310 For Series 160is/ 180is DRAM 16MB A20B–3300–0311 For Series 160is/ 180is DRAM 32MB A20B–3300–0291 For Series 210is DRAM 16MB A20B–3300–0290 For Series 210is DRAM 32MB A20B–3300–0312 For Ser
Page 2823. LCD–MOUNTED TYPE is SERIES HARDWARE GFKE-0222-EN D Mounting positions of DIMM module (1) FROM/SRAM module DIMM module (2) Analog spindle module Connector Connector Connector DIMM module Connector Motherboard No. Name Code Function Remarks (1) FROM/SRAM A20B–3900–0160 FROM 16MB FROM contains vario
Page 283GFKE-0222-EN Axis control card CE card 2 CPU card SRAM DSP CPU CPU D Block diagram Axis 1/2 G/A DSP BOOT control DRAM software DRAM Axis 3/4 CE card 1 Axis 5/6 Compact CPU flash card peripherals G/A CPU BOOT peripherals Axis 7/8 software FSSBC G/A 253 bus conversion Local BUS G/A F–BUS PMC control I
Page 2843. LCD–MOUNTED TYPE is SERIES HARDWARE GFKE-0222-EN D LED display Rear of unit LED LINK Indicates the link state of the Ethernet on the NC side. This LED lights when a link is established. PC Status (Green) D2 Flashes while data is being POWER sent or received over the Ethernet on the PC side. SYSFA
Page 285GFKE-0222-EN 3. LCD–MOUNTED TYPE is SERIES HARDWARE (1) Changes in status LED (green) indication at power–on time (NC side status : Green LED) No. Status LED Status 1.2.3.4 1 jjjj Power is not supplied. 2 JJJJ Initial status immediately after power is switched on; boot is running. 3 jJJJ System acti
Page 2863. LCD–MOUNTED TYPE is SERIES HARDWARE GFKE-0222-EN (3) Alarm LED (red) indication at system alarm occurrence If any of these LEDs lights, it is likely that the hardware is defective. Alarm LED Meaning SVALM Servo alarm SYSEMG Lights when a system alarm occurs. The hardware has detected a fail- ure
Page 287GFKE-0222-EN 3. LCD–MOUNTED TYPE is SERIES HARDWARE Mounting position of rotary switch (LCD–mounted type CNC) Rear of unit Rotary switch D Short plug settings Mother board TMIL1 (short) Be sure to insert these short plugs. RESERVE (open) Be sure to remove these short plugs. (For some boards, the pin
Page 2883. LCD–MOUNTED TYPE is SERIES HARDWARE GFKE-0222-EN 3.5 The CE card has a different configuration from other card printed–circuit boards. CE CARD CE cards 1 and 2 are combined and the compact flash card is attached. D CE card configuration CE card 1 CE card 2 Spacer Compact flash card ÕÕ Connector Õ
Page 289GFKE-0222-EN 3. LCD–MOUNTED TYPE is SERIES HARDWARE 3.6 INSTALLING AND REMOVING OPTIONAL BOARDS 3.6.1 Installing and Removing the Mother WARNING Board Only those personnel who were well trained for maintenance and safety can perform the replacement. When removing the board with the cabinet open, be
Page 2903. LCD–MOUNTED TYPE is SERIES HARDWARE GFKE-0222-EN (2) Loosen the three screws that retain the power supply unit and remove the unit. Then disconnect the cables from PCMCIA2 (PCMCIA interface connector), CN8 (video signal interface connector), and CN2 (soft key connector) located on the mother boar
Page 291GFKE-0222-EN 3. LCD–MOUNTED TYPE is SERIES HARDWARE 3.6.2 Installing and Removing the CE Card D Removing the CE card CE card Mother board Remove the CE cards from the mother board. (Remove these cards from the plug connector on the mother board with CE card 1 and CE card 2 engaged.) D Removing the c
Page 2923. LCD–MOUNTED TYPE is SERIES HARDWARE GFKE-0222-EN D Separating CE card 1 S On side A, CE card 2 is installed. Press both sides of the latch section from CE card 2 of each spacer engaging CE cards 1 and 2 to unlock the latch, then remove CE card 1. CE card 2 (side A) ÕÕ ÕÕ ÕÕ ÕÕ Spacer ÕÕ ÕÕ ÕÕ Rem
Page 293GFKE-0222-EN 3. LCD–MOUNTED TYPE is SERIES HARDWARE D Attaching the spacers On side B (on which the connector for combining the mother board is (spacer specification: mounted), insert a spacer into a spacer hole. A98L–0005–0208) Press the spacer until the latch on side A is completely open. D Instal
Page 2943. LCD–MOUNTED TYPE is SERIES HARDWARE GFKE-0222-EN 3.7 Printed circuit boards LIST OF UNITS AND Name Drawing number PRINTED CIRCUIT Motherboard 160is A20B–8100–0790 BOARDS 180is A20B–8100–0791 210is (SA1) A20B–8100–0794 210is (SB7) A20B–8100–0795 CE card CE card 1 A20B–3300–0330 CE card 2 A20B–3300
Page 295GFKE-0222-EN 3. LCD–MOUNTED TYPE is SERIES HARDWARE 3.8 REPLACING THE WARNING FUSE ON THE UNITS Before replacing the fuse, eliminate the cause by which the fuse blew. Therefore, only those personnel who were well trained for maintenance and safety can perform the replacement. When replacing the fuse
Page 2963. LCD–MOUNTED TYPE is SERIES HARDWARE GFKE-0222-EN 3.9 See Section 2.8, ”REPLACING THE BATTERY” for replacing the battery. REPLACING THE BATTERY 3.10 REPLACING THE FAN MOTOR D Ordering number of fan motor Unit Number of Ordering number Required extension slot number LCD–mounted No extension slot A0
Page 297GFKE-0222-EN 3. LCD–MOUNTED TYPE is SERIES HARDWARE 3.11 LCD back–light can not be replaced for LCD–mounted type is series CNC. REPLACING THE LCD BACK–LIGHT 3.12 For the LCD display unit with a touch panel, the surface of the touch panel is covered with the protection sheet to protect it. When there
Page 2983. LCD–MOUNTED TYPE is SERIES HARDWARE GFKE-0222-EN 3.13 BACKUP UNIT D Specifications Item Ordering number Backup unit PCB A20B–2100–0820 Backup unit cable A02B–0281–K801 D Mounting positions of connectors CN9 Backup unit PCB Front view Connector name Function CN9 Supplying the backup power (main pr
Page 299GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4 STAND–ALONE TYPE i SERIES HARDWARE This chapter describes the printed circuit boards of the CNC control unit of the stand–alone type i series and card PCB functions on the printed circuit boards. The chapter also describes procedures for replacing
Page 3004. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 4.1 HARDWARE CONFIGURATION LCD unit MDI unit Control unit Servo amplifier module/ Servo motor/ spindle amplifier module spindle motor Distributed I/O module, I/O unit MODEL–A, etc. I/O Link Machine operator’s panel, power magnetic circuit, etc. 270
Page 301GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.2 HARDWARE OVERVIEW 4.2.1 Series 16i/160i/160is 271
Page 3024. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN Sub–CPU board(*2) Main CPU board Sub–CPU for two–path control ⋅ 2–axis to 8–axis control CPU for controlling CNC ⋅ Spindle interface ⋅ Power ⋅ Analog output ⋅ 2–axis to 8–axis control ⋅ Spindle interface ⋅ I/O Link RISC board (M series only)(*1) ⋅ P
Page 303GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.2.2 Series 18i/180i/180is Sub–CPU board(*2) Main CPU board Sub–CPU for two–path control ⋅ 2–axis to 6–axis control CPU for controlling CNC ⋅ Spindle interface ⋅ Power ⋅ Analog output ⋅ 2–axis to 6–axis control ⋅ Spindle interface ⋅ I/O Link RISC b
Page 3044. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 4.2.3 Series 21i/210i/210is Main CPU board CPU for controlling CNC ⋅ Power ⋅ 2–axis to 4–axis control ⋅ Spindle interface ⋅ I/O Link ⋅ PMC–SA1/SB7 ⋅ Analog output (option) ⋅ High–speed DI ⋅ RS–232C x 2 ⋅ Memory card interface ⋅ Display interface ⋅ E
Page 305GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.3 TOTAL CONNECTION DIAGRAMS 275
Page 3064. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN Stand–alone type control unit Main board Slot 1 24V–IN(CP1) 24–VDC power 24V–OUT(CP2) To I/O unit, etc. Optical fiber cable LCD UNIT MDUNIT LCD(COP20A) COP20B CK2 24VDC CP1A CA55 CK1 CP1B Memory card (Touch panel) R232–1(JD5A) RS–232–C I/O unit R232
Page 307GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE Stand–alone type control unit Slot 2 Data server board (cannot be used in 21i/210i/210is) ATA card (CD38M) Ethernet Slot 3 Sub–CPU board (cannot be used in 21i/210i/210is) A–OUT(JA40) Analog output for tool drive Position coder SPDL&POS(JA41) { PSM
Page 3084. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN When an option board is used I/O Link II board Mini slot To another unit DeviceNet board Mini slot To another unit PROFIBUS board Mini slot (master) To another unit PROFIBUS board Mini slot (slave) To another unit FL–net board Mini slot To another u
Page 309GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE For the is series CNC display unit, the additional connection shown below is required on the unit. DC24V–IN(CP1) 24VDC Power Supply MDI unit dedicated to PCs Soft Key Cable Soft Key(CK2) Backup(CA75) Backup Unit PC Side Ethernet Hub, etc. (CD38S) PC
Page 3104. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 4.4 CONNECTOR AND CARD CONFIGURATIONS OF PRINTED CIRCUIT BOARDS 4.4.1 Main CPU Board of Series 16i/18i/21i/160i/ 180i/210i/160is/180is/ 210is D Specifications Item Code Main CPU board of Series 16i/160i/160is A16B–3200–0420 Main CPU board of Series
Page 311GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE D Mounting positions of connectors, LEDs, etc. MAIN Battery case BAT1: Battery LEDs JD5A: RS232C serial port JD5B: RS232C serial port CNM1B: Memory card JD1A: I/O Link JA40: Analog output/high–speed DI JA41: Serial spindle/position coder JD45: CRT L
Page 3124. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D Mounting positions of cards and DIMM modules (4) Power supply unit (1) CPU card (5) Analog spindle module (2) Display control card (3) Axis control card (6) FROM/SRAM module 282
Page 313GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE No. Item Code Function Remarks (1) CPU card A20B–3300–0310 DRAM 16MB For Series 16i/18i/160i/180i/ 160is/180is A20B–3300–0311 DRAM 32MB For Series 16i/18i/160i/180i/ 160is/180is A20B–3300–0291 DRAM 16MB For Series 21i/210i/210is A20B–3300–0290 DRAM
Page 3144. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN No. Item Code Function Remarks (4) Power unit A20B–8100–0851 (5) Analog spindle A20B–3900–0170 Analog spindle position coder module (6) FROM/SRAM A20B–3900–0160 FROM 16MB FROM stores various control module SRAM 1MB software products. SRAM is backed
Page 315GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE D LED display D Fuse burn–out detection LED FUSE (Red) Lit if the fuse is blown. D LED status transition at power–up j: Off J: On 7–segment STATUS Status LED Not lit jjjj Power off 8 JJJJ CPU not activated after power–up F NC system loading started
Page 3164. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D LED display when a system alarm occurs j: Off J: On l: Blink (if CPU card A20B–3300–031X is used) ALARM jJj System failure. The software detected an error and stopped the system. ALARM JJj An error occurred on the local bus in the main CPU board.
Page 317GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE D 7–segment LED display when a system alarm occurs If a system alarm occurs, a number blinks as shown below, depending on the system alarm number. System 7–segment alarm num- System alarm type LED ber 0 900 to 909 ROM parity alarm. System ROM parity
Page 3184. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D Block diagram DRAM Analog output Position coder FROM SRAM 288
Page 319GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.4.2 Sub–CPU Board D Specifications Item Code Sub–CPU board A16B–2203–0751 D Mounting positions of connectors, LEDs, etc. LED display JA40–2: Analog output JA41–2: Serial spindle/position coder COP10A–2: FSSB2 CA69B: Servo check COP10A–1: FSSB2 289
Page 3204. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D Mounting positions of cards and DIMM module (1) CPU card (2) Axis control card No. Item Code Function Remarks (1) CPU card A20B–3300–0310 DRAM 16MB A20B–3300–0311 DRAM 32MB (2) Axis control card A20B–3300–0243 Axis control 2 axes Servo software Se
Page 321GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE D LED display D LED display at power–up j: Off J: On STATUS jjjj Power off STATUS JJJj CPU not activated after power–up STATUS Jjjj Initialization completed, normal operation in progress D LED display when a system alarm occurs j: Off J: On l: Blink
Page 322Servo card CPU card D Block diagram Axis 1/2 G/A DSP control DRAM Axis 3/4 Axis 5/6 G/A CPU 4. STAND–ALONE TYPE i SERIES HARDWARE Axis 7/8 peripherals 292 Local BUS G/A G/A F–BUS Bus Peripheral (to back panel) conversion control Sub–CPU board FSSB Serial spindle (to servo amplifier) Analog output Ca
Page 323GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.4.3 The RISC function and data server function are provided on a single RISC Board, Data option board. If the RISC function alone is needed, a RISC board is used. If just the data server function is needed, a data server board is used. If Server B
Page 3244. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D Mounting position of card (For RISC card, RISC+DATA SERVER board) (1) CPU card No. Item Code Function Remarks (1) CPU card A20B–3300–0102 Standard type 294
Page 325GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE D LED display of the RISC The RISC function uses the green STATUS LEDs and red ALARM LEDs function in the upper part of the face plate. The red ALARM LEDs are used also by the data server function. <1> Status LED indication (green LED turned on) Ala
Page 3264. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN <3> Alarm LED indication (red LED) Alarm LED State JjJ The power supply for the processor core on the RISC board is de- fective. jjJ A DRAM parity error occurred on the CPU card. JJj System emergency jJj (Reserved) J : ON j : OFF NOTE The LEDs displ
Page 327GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE LED status transition at power–up LED statuses f: Off F: On l: Blink Z: Don’t care LED display No. Board status (L1 to L4) 1 ff Power off ff 2 FF Initial state immediately after power–up FF 3 fF MPU initialization completed FF 4 fF Firmware download
Page 3284. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN NOTE If an error, indicated by repeatedly flashing a LONG and SHORT combination other than the above, occurs, contact FANUC. LED display when an error occurs (ALARM) LED statuses j: Off J: On LED display No. Board status 123 1 jJJ An MPU transfer er
Page 329GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.4.4 Loader Control Board D Specification Name Specification Loader Control Board A16B–2203–0740 D Connector location LED display JD1A : FANUC I/O LINK CNBK : Brake drive output CNPW : Emergency stop control LED display for I/O alarm CRM1 : DI/DO f
Page 3304. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D Card location (1) CPU card (2) Axis control card No. Item Code Function Remarks (1) CPU card A20B–3300–0291 CNC control A20B–3300–0032 4 axes (2) Axis control card Axis control A20B–3300–0033 2 axes 300
Page 331GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE – LED Display Transition at Power–up NO. LED display NC Status 1 STATUS:jjjj Power off 2 STATUS:JJJJ Startup status immediately after power is turned on 3 STATUS:jJJJ RAM initialized 4 STATUS:JjJJ Software ID set; keys initialized 5 STATUS:jjJJ Wait
Page 3324. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 4.4.5 C Board, Serial Communication Board D Specifications Item Code C board A20B–8100–0330 Serial communication board R.B./DNC2: RS232C I/F A20B–8100–0334 R.B./DNC2: RS422 I/F A20B–8100–0335 DNC1: RS485 I/F A20B–8100–0336 D Mounting positions of co
Page 333GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE D Mounting positions of card and DIMM module (1) DRAM module No. Item Code Function Remarks (1) DRAM module A20B–3900–0042 System RAM 4MB 4.4.6 HSSB Interface Board D Specifications Item Code HSSB interface board A20B–8001–0730 D Mounting positions
Page 3344. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D LED display LEDB Red HSSB communication has been interrupted. LEDA Red A RAM parity alarm occurred in the common RAM on the board. The common RAM is mounted on this board. The RAM is used to exchange information between the CNC and personal comput
Page 335GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE D Rotary switch 1) Setting of ROTARY SWITCH in case of connecting to PC or PANEL i The power–on start sequence can be modified using rotary switch on the board. setting of rotary Description switch 0 Setting for maintenance. The start menu is displa
Page 3364. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 2) Setting of ROTARY SWITCH in case of connecting to CNC display unit with PC functions The power–on start sequence can be modified using rotary switch on the board and short terminal (SW5) on CNC display unit with PC functions. setting of short Des
Page 337GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.4.7 Symbol CAPi T Board D Specifications Item Code Symbol CAPi T board A20B–8100–0560 D Mounting positions of connectors, LEDs, etc. JNA F–BUS backplane connector Setting pin TM1 Connector CP8B D LED display Status display of the red LEDs j: Off J
Page 3384. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D Setting pin TM1 and Setting pin TM1 and connector CP8B are provided for testing at FANUC. connector CP8B The setting of the pin must not be changed. D Mounting positions of card and DIMM module (1) DRAM module No. Item Code Function Remarks (1) DR
Page 339GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE D LED display D Status LED display (green) Status LED1 Lit when the board is released from the reset state and starts operating. LED2 Lit when communication starts. This LED is left on until a reset occurs. LED3 Lit each time transmission is perform
Page 3404. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D Mounting positions of connectors, LEDs, etc. JNA F–BUS backplane connector CD38L: Ethernet interface D LED display D Status transition at power–up, displayed by the green LEDs No. 4321 Ethernet board status 1 jjjj Power off 2 JJJJ Initial state im
Page 341GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE D Status LED display when an error occurs (green) The status LEDs alternately display the LONG and SHORT patterns. The LONG pattern is held longer than the SHORT pattern. STATUS LED indication No. Ethernet/data server board state LONG SHORT 4321 432
Page 3424. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D Mounting positions of connectors, LEDs, etc. JNA F–BUS backplane connector Daughter board (other manufacturer) TM1 TBL: DeviceNet interface Master/slave setting pin D LED display D Meaning of red LED LEDA Lit when an error occurs on the daughter b
Page 343GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.4.11 PROFIBUS Master Board D Specifications Item Code PROFIBUS master board A20B–8100–0470 D Mounting positions of connectors, LEDs, etc. JNA F–BUS backplane connector CN1: PROFIBUS interface D LED display D Status LED display (green) State LED1 L
Page 3444. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 4.4.12 PROFIBUS Slave Board D Specifications Item Code PROFIBUS slave board A20B–8100–0440 D Mounting positions of connectors, LEDs, etc. JNA F–BUS backplane connector CN2: PROFIBUS interface D LED display D Status LED display (green) State LED1 Lit
Page 345GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.4.13 FL–net Board D Specifications Item Code FL–net board A20B–8100–0530 D Mounting positions of connectors, LEDs, etc. JNA F–BUS backplane connector Setting pin TM1 (fixed to B) CD38N: FL–net interface D LED display D Meanings of red LEDs HER Lit
Page 3464. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 4.4.14 Main CPU Board of CNC Display Unit with PC Functions and PANEL i D Specifications Item Code Main CPU board For Windows95 For 10.4”/12.1” LCD A20B–2100–0690 (For basic unit A08B–0082–B001 to –B004, –B011 to –B014, –B021 to –B024) For 15.0” LCD
Page 347GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE D Specifications Item Code Main CPU board For Windows95 For 10.4” LCD A20B–2100–0780 (For basic unit A08B–0082–B031 to –B038, –B041 to –B048, –B051 to –B057) For 12.1” LCD A20B–2100–0781 (For basic unit A13B–0193– B031 to –B038, –B041 to –B048, –B05
Page 3484. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D LED display GR1(Green) +5V(Green) GR2(Green) HDD(Green) GR3(Green) CNC(Green) CNH3 (HDD Signal) COP7 GR4(Green) or CRD(Green) RE1(Red) *6 BUS(Red) RE2(Red) BAT (Red) CD34 (FDD Signal) RE3(Red) FAN(Red) RE4(Red) TRM(Red) Name 1(*6) Name 2(*6) Color
Page 349GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.4.15 Mother Board of CNC Item Code Display Unit for is Mother Board of CNC display unit for is series A20B–8100–0800 Series D Mounting positions of connectors Connector unit Fan motor Fan motor Rear of unit JD48 COP7 CP1 CK2 CD38S CN2 CA75 Motherb
Page 3504. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN Connector number Use JD48 PC side RS232C,USB COP7 High–speed optical communication(HSSB) CN2,CK2 Soft key CP1 DC24V–IN CD38S PC side Ethernet(10BASE–T/100BASE–TX) TP1 Touch panel CA75 Backup unit CN8 Video signal interface PCMCIA2 PCMCIA interface D
Page 351GFKE-0222-EN CE card 2 D Block diagram CPU BOOT DRAM software CE card 1 Compact CPU flash card peripherals 321 G/A bus conversion HSSBC Ethernet control Power supply unit 5V, 3.3V Ethernet HSSB 24VDC To NC Memory card interface RS–232–C USB 4. STAND–ALONE TYPE i SERIES HARDWARE
Page 3524. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D LED display Rear of unit Lights when the unit failed to Alarm (Red) LED1 communicate with the NC over LEDP the HSSB. Lights when the CE card is Lights when the unit communicates LED2 powered on (including during with the NC over the HSSB. backup o
Page 353GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE D Short plug settings Mother board These short plugs are reserved. Be sure to remove them. 323
Page 3544. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 4.5 UNITS AND PRINTED CIRCUIT BOARDS 4.5.1 Basic Units Type Item Drawing No. Remarks 16i/160i/ Basic unit with 1 slot A02B–0281–B801 160is Basic unit with 3 slots A02B–0281–B803 18i/180i/ Basic unit with 1 slot A02B–0283–B801 180is A02B–0297–B801 Fo
Page 355GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE Type Item Drawing No. ID Remarks Card PCB Display control card LCD/MDI A20B–3300–0340 – For CRT LINK A20B–3300–0360 – MDI only A20B–3300–0362 – No display A20B–3300–0364 – LCD/MDI A20B–3300–0341 – 21i/210i/210is When the embedded For CRT LINK A20B–3
Page 3564. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN Type Item Drawing No. ID Remarks DIMM FROM/SRAM module A20B–3900–0160 FROM: C1 FROM 16MB, SRAM module SRAM: 03 1MB A20B–3900–0161 FROM: C1 FROM 16MB, SRAM SRAM: 04 2MB A20B–3900–0162 FROM: C1 FROM 16MB, SRAM SRAM: 05 3MB A20B–3900–0163 FROM: C2 FROM
Page 357GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE Type Item Drawing No. ID Remarks Option Sub–CPU board A16B–2203–0751 1xC0 PCB Loader control board A16B–2203–0740 1x97 RISC + data server board A16B–3200–0390 0x81 3xF5 RISC board A16B–3200–0391 0x81 Data server board A16B–3200–0352 3xF5 ATA card ad
Page 3584. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN Type Item Drawing No. ID Remarks Distributed Operator’s panel I/O module A20B–2002–0470 – Matrix DI supported I/O With MPG interface A20B–2002–0520 – General–purpose DI input With MPG interface A20B–2002–0521 – General–purpose DI input Without MPG i
Page 359GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.5.3 LCD/MDI Unit Item Drawing No. Remarks 9.5″ monochrome LCD unit A02B–0281–C061 9.5″ monochrome LCD unit A02B–0281–C066 Character only 10.4″ color LCD unit A02B–0281–C071 10.4″ color LCD unit A02B–0281–C081 With touch panel For display link 7.2″
Page 3604. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN Item Drawing No. Remarks CAPi T keyboard (horizontal type) A02B–0281–C125#TFBR Alphabetic keys 220x230mm A02B–0281–C125#TFBS Symbolic keys CAPi T keyboard (vertical type) A02B–0281–C126#TFBR Alphabetic keys 220x290mm A02B–0281–C126#TFBS Symbolic key
Page 361GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.5.5 CNC Display Unit with PC Functions and PANEL i Type Item Drawing No. Printed circuit board Main printed circuit board For Windows95 For 10.4”/12.1” LCD A20B–2100–0690 for CNC display unit (For basic unit A08B–0082–B001 to –B004, with PC functi
Page 3624. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN Drawing number Main drawing Type Item of unit for number maintenance (Basic unit) Printed circuit board Base unit LCD Soft key Touch panel for CNC display unit 10.4” LCD A08B–0082–D001 A08B–0082–B001 with PC functions and PANEL i Ę A08B–0082–D002 A0
Page 363GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE Ę: Provided : None NOTE The base unit for maintenance consists of the components of the basic unit from which the main printed circuit board and its retaining screws are excluded. Drawing number Main drawing Type Item for maintenance number Printed
Page 3644. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 4.5.6 Printed circuit boards CNC Display Unit for is Name Drawing number series CNC Motherboard A20B–8100–0800 CE card CE card 1 A20B–3300–0330 CE card 2 A20B–3300–0320 Power supply unit A20B–8100–0720 Printed circuit board of Inverter A20B–8001–092
Page 365GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.6 MOUNTING AND REMOVING AN OPTION BOARD WARNING The replacement described here should be performed by a person fully trained in maintenance and safety. If the cabinet is opened to replace the option board, take extreme care not to touch any high–v
Page 3664. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 4.6.1.2 (1) Holding handles A and B, insert the board into the cabinet until the Mounting the board connector on the back panel is connected. (2) Connect the removed cables to correct positions. Handle A With a hook on the top side Handle B With a h
Page 367GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.6.2 Mounting and Removing a Mini–Slot Option Board (Except DeviceNet Board) 4.6.2.1 (1)Remove cables connected to the target mini–slot option board. Removing the board Remove other cables that would obstruct the removal of the mini–slot option boa
Page 3684. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 4.6.3 Mounting and Removing the DeviceNet Board 4.6.3.1 (1) Remove the terminal block from the connector on the DeviceNet Removing the board board. The terminal block can be pulled out after the screws on both sides are loosened. The terminal block
Page 369GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE Handle C With a hook on the left side Handle D 339
Page 3704. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 4.7 MOUNTING AND REMOVING THE BACK PANEL WARNING The replacement described here should be performed by a person fully trained in maintenance and safety. If the cabinet is opened to replace the back panel, take extreme care not to touch any high–volt
Page 371GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE Fan connector Latch Back panel Back panel 341
Page 3724. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 4.8 REPLACING THE WARNING FUSE OF THE Before starting the replacement of a fuse, remove the cause CONTROL UNIT of the fuse burn–out. Accordingly, the replacement should be performed by a person fully trained in maintenance and safety. If the cabinet
Page 373GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.9 Part programs, offset data, and system parameters are stored in CMOS memory in the control unit. The power to the CMOS memory is backed REPLACING THE up by a lithium battery mounted on the front panel of the control unit. The BATTERY above data
Page 3744. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D Replacing the battery If a lithium battery is used, have A02B–0200–K102 (FANUC internal code: A98L–0031–0012) handy. (1) Turn the CNC on. About 30 seconds later, turn the CNC off. (2) Remove the battery from the top area of the CNC unit. Disconnec
Page 375GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE When using commercial D–size alkaline dry cells D General method Use the connector connected to the lithium battery for an external battery. Following the battery replacement procedure described above, replace the standard lithium battery with an ex
Page 3764. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN D Replacing the battery (1) Have commercial D–size alkaline dry cells handy. (2) Turn the CNC on. (3) Remove the lid from the battery case. (4) Replace the old dry cells with new ones. Mount the dry cells in a correct orientation. (5) Replace the li
Page 377GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.10 REPLACING A FAN UNIT WARNING If the cabinet is opened to replace a fan unit, take extreme care not to touch any high–voltage area (marked with and covered by a shock prevention cover). If the area is uncovered, direct contact with this area wil
Page 3784. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN 4.11 REPLACING THE WARNING FUSE OF THE LCD Before starting the replacement of the fuse, remove the UNIT cause of the fuse burn–out. Accordingly, the replacement should be performed by a person fully trained in maintenance and safety. If the cabinet
Page 379GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.12 REPLACING THE WARNING LCD BACKLIGHT The replacement described here should be performed by a person fully trained in maintenance and safety. If the cabinet is opened to replace the unit, take extreme care not to touch any high–voltage area (mark
Page 3804. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN (2) Disconnect inverter cable connector CP1 and video signal cable connector CN8, then remove the LCD panel from the unit. LCD panel (3) For 9.5″ monochrome LCD Connector Metal catch Back of the LCD panel Backlight (4) After replacing the backlight,
Page 381GFKE-0222-EN 4. STAND–ALONE TYPE i SERIES HARDWARE 4.13 HEAT GENERATION OF THE UNITS Heat Unit Remarks generation Control unit 1–slot cabinet 30W (*1) 3–slot cabinet 43W Option board HSSB board 4W Sub–CPU board 14W PMC C board 7W Serial communication 7W board Symbol CAPi T board 10W RISC board 9W Da
Page 3824. STAND–ALONE TYPE i SERIES HARDWARE GFKE-0222-EN Heat Unit Remarks generation MDI unit 0W Operator’s panel I/O module 12W (*1) Connector panel I/O module (ba- 8W (*1) sic) Connector panel I/O module (ex- 5W (*1) pansion) Separate detector interface unit 9W Unit with 4 basic axes only Separate dete
Page 3835. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) 5 MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) This chapter describes the hardware common to the LCD–mounted type i series and stand–alone type i series. 5.1 MOUNTING
Page 3845. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN 5.1 MOUNTING AND WARNING DEMOUNTING CARD Only those personnel who have received approved safety PCBS and maintenance training may perform this replacement work. When opening the cabinet and replacing a c
Page 3855. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) 5.1.1 1) Pull outward the claw of each of the four spacers used to secure the card Demounting a Card PCB, then release each latch. (See Fig. a.) PCB 2) Extract the card PCB upward. (See Fig. b.) Card PCB
Page 3865. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN 5.1.2 1) Check that the claw of each of the spacers is latched outward, then Mounting a Card PCB insert the card PCB into the connector. (See Fig. c.) 2) Push the claw of each spacer downward to secure t
Page 3875. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) 5.2 MOUNTING AND WARNING DEMOUNTING DIMM Only those personnel who have received approved safety MODULES and maintenance training may perform this replacement work. When opening the cabinet and replacing
Page 3885. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN 5.2.1 1) Open the claw of the socket outward. (See Fig. a.) Demounting a DIMM 2) Extract the module slantly upward. (See Fig. b.) Module 5.2.2 1) Insert the module slantly into the module socket, with si
Page 3895. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) 5.3 The performance of the heat exchanger degrades due to a buildup of dirt. Clean the heat exchanger periodically. The cleaning interval depends on MAINTENANCE OF the installation environment. So, clean
Page 3905. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN Cleaning and replacing the air filter Procedure for cleaning and replacing the air filter 1 Before cleaning and replacing the air filter, turn off the fan power supply. 2 Remove the filter cover, then de
Page 3915. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) Cleaning the heat exchanger Procedure for cleaning the heat exchanger 1 Before cleaning the heat exchanger, turn off the fan power supply. 2 Demount the external fan unit from the main body of the heat e
Page 3925. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN D Cleaning the fan of the heat exchanger Procedure for cleaning the fan of the heat exchanger 1 Demount the heat exchanger from the unit, then remove dust and mist from the fan by blowing air or by using
Page 3935. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) 5.4 LIQUID CRYSTAL DISPLAY (LCD) Brightness of the When the ambient temperature is low, the brightness of the LCD monochrome LCD decreases. (The LCD screen is dark particularly immediately after the powe
Page 3945. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN <6> With a dry soft cloth, wipe off moisture completely. 2) Applying the protection sheet 2–1) For A02B–0236–K110 <1> Fold the tab over the front side (the side opposite to the backing sheet). Fold <2> P
Page 3955. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) 2–2) For A02B–0236–K130 <1> Peel off the white film attached on the back (facing the LCD) of the new protection sheet. <2> Attach the protection sheet so that it is to the lower–left of the replacement t
Page 3965. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN Touch panel compensation D Condition that requires Touch panel compensation is required: compensation 1 When the LCD unit is replaced 2 When the touch panel is replaced 3 When the touch panel control pri
Page 3975. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) 6 After pressing all of the nine compensation points, press the key to terminate compensation. To cancel compensation or start all over again, press the key. 7 Upon normal termination, the
Page 3985. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN 5.5 By changing the setting (rotary switch) on an expansion module, a connection can be made to skip an expansion module or expansion DISTRIBUTED I/O modules as shown below. SETTING Basic module Basic mo
Page 3995. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) Setting Indication Meaning of setting position 2 2 Set the rotary switch of an expansion module to this position when the two preceding expansion mod- ules are skipped. 3 – Setting prohibited 4 to F 4, –
Page 4005. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN NOTE To expansion module A (DI/DO = 24/16, with a manual pulse generator interface) (A03B–0815–C002), a rotary switch is added as the other modules are modified. However, expansion module A is always ins
Page 4015. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) 5.6 REPLACING FUSES WARNING ON VARIOUS UNITS Before replacement of a blown fuse, the cause of the blown fuse must be corrected. So, fuse replacement work must be done only by a person who is trained in t
Page 4025. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN D Fuse mounting location on the connector panel I/O modules Fuse Expansion module 3 Expansion module 2 Expansion module 1 Basic module Cable for the I/O Link (A03B–0815–C001) Cable for a manual pulse gen
Page 4035. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) D Fuse mounting location on the operator’s panel I/O modules I/O connector JD1A JD1B JA3 Fuse Power supply connector This drawing is for A20B–2002–0470, A20B–2002–0520, and A20B–2002–0521. D Fuse mountin
Page 4045. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN D Fuse mounting locations on the machine operator’s panel interface unit CM26 FU1 CPD1 FU3 FU2 CM17 JD1A JD1B CM16 CM15 FU1: Fuse for +24V (for protection of general–purpose DO and the power supply of th
Page 4055. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) D Fuse mounting location on the separate detector interface unit Power connector Optical Fuse connector 375
Page 4065. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN 5.7 The control units and various peripheral units supplied from FANUC are designed assuming that those units are accommodated in enclosed ENVIRONMENTAL cabinets. The cabinets mentioned here include: CON
Page 4075. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) 5.8 The CNC is becoming increasingly smaller as the surface mount technology and custom LSI technology advance. COUNTERMEA- SURES AGAINST In many cases, as the CNC becomes more compact, the mounting NOIS
Page 4085. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN NOTE 1 Separate binding is to separate the bound cables of one group at least 10 cm from the bound cables of another group. 2 Electromagnetic shielding is to shield the bound cables of one group from the
Page 4095. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) 5.8.2 With a CNC machine tool, three ground systems are used. Grounding (1) Signal ground system (SG) Signal ground (SG) provides a reference voltage (0 V) for the electric signal system. (2) Frame groun
Page 4105. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN 5.8.3 LCD–mounted type control unit Signal Ground (SG) Connection of Control Unit M4 stud Ground cable Wire of 2 mm2 or more Connect the 0 V line inside the control unit to the ground plate of the cabine
Page 4115. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) LCD stand–alone type control unit For a one–slot rack For a three–slot rack Ground terminal for signals Ground terminal for signals M4 (Screw hole) (Faston terminal) M3 (Screw hole) Ground wire 2 mm2 or
Page 4125. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN 5.8.4 With a power magnetics cabinet, components such as an AC/DC solenoid Noise Suppressor and AC/DC relay are used. When turned on and off, these components generate a high–energy pulse voltage due to
Page 4135. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) 5.8.5 According to the figure below, clamp all cables that require shielding and Cable Clamping and are run to the CNC, servo amplifier, spindle amplifier, and so forth. This clamping method not only sec
Page 4145. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN ÇÇ Mounting plate of the machine ÇÇ Control unit ÇÇ ÇÇ ÇÇ ÇÇ ÇÇ ÇÇ ÇÇ ÇÇ ÇÇ Ground plate ÇÇ ÇÇ ÇÇ ÇÇ ÇÇ Clamp Shield cover ÇÇ Fig. 5.8.5 (b) Cable clamp (2) Prepare a ground plate as shown below. Ground
Page 4155. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) Ground plate 8mm 12mm 20mm Fig. 5.8.5 (d) Ground plate hole diagram Reference: Outline drawing of the clamp 55 mm maximum 28mm 6mm 17mm Fig. 5.8.5 (e) Outline drawing of clamp Ordering code of the clamp:
Page 4165. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN 5.9 An MDI unit usable with a 12.1” LCD has a connector panel that allows various interface connectors to be placed on the front. The connector NOTES ON USING panel has a cover. The cover is opened and c
Page 4175. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) 5.10 REPLACING THE MAINTENANCE PARTS OF CNC DISPLAY UNIT FOR PC FUNCTIONS AND PANEL i 5.10.1 Replacing the Battery D Ordering number Item Ordering number Lithium battery A02B–0200–K102 387
Page 4185. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN D Replacing method (1) After a lapse of five minutes from power up, power off the CNC display unit with PC functions or the PANEL i. Then remove the CNC display unit with PC functions or the PANEL i from
Page 4195. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) When this procedure is used to replace the battery, normally the BIOS settings are not cleared. However, in case the settings are cleared, the following message appears during power up, the default BIOS
Page 4205. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN D Replacing method (1) Make sure the CNC display unit with PC functions or the PANEL i is powered off. (2) Remove the CNC display unit with PC functions or the PANEL i from the panel so that it can be ac
Page 4215. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) D Replacing the fan for (1) Make sure the CNC display unit with PC functions or the PANEL i is main body powered off. (2) Loosen the two screws (A), then remove the fan retaining metal sheet. (3) Remove
Page 4225. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN Fan retaining metal sheet Perform wiring as shown below. Be sure to install the fan in the cor- rect direction. Note the cabling Air Flow direction. Two screws (B) A08B–0082–B031 to –B038, –B041 to –B048
Page 4235. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) D Replacing the fan for (1) Make sure the CNC display unit with PC functions or the PANEL i is HDD powered off. (2) Remove the fan connector (CN7) on the main board. Since the connector is fixed with a l
Page 4245. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN 5.10.5 For the CNC display unit with PC functions or the PANEL i, the surface Replacing the Touch of the touch panel is covered with the protection sheet to protect it. When there are flaws and contamina
Page 4255. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) 5.11 REPLACING THE MAINTENANCE PARTS OF CNC DISPLAY UNIT FOR is SERIES CNC 5.11.1 Replacing Procedure of Mother Board WARNING Only those personnel who were well trained for maintenance and safety can per
Page 4265. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN <2> Disconnect the cables from PCMCIA2 (PCMCIA interface connector), CN8 (video signal interface connector), and CN2 (soft key connector) located on the mother board. When the touch panel is attached, al
Page 4275. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE GFKE-0222-EN AND STAND–ALONE TYPE i SERIES (HARDWARE) D Location of Fuse Rear of units Fuse 5.11.3 Since the display unit for the is series CNC has no battery, replacement Replacing the Battery is not required. 5.11.4 Replacing the Fan Motor D Ordering numb
Page 4285. MATTERS COMMON TO BOTH LCD–MOUNTED TYPE AND STAND–ALONE TYPE i SERIES (HARDWARE) GFKE-0222-EN 5.11.5 LCD back–light can not be replaced for CNC display unit for is series Replacing the LCD CNC. Back–Light 5.11.6 For the LCD display unit with a touch panel, the surface of the touch panel Replacing
Page 429GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 6 INPUT AND OUTPUT OF DATA After you change a SRAM module, you must set various data again. This chapter describes the procedures to input and output the parameters, the part programs and the tool offset values. 6.1 SETTING PARAMETERS FOR INPUT/OUTPUT . . . .
Page 4306. INPUT AND OUTPUT OF DATA GFKE-0222-EN 6.1 SETTING PARAMETERS FOR INPUT/OUTPUT D Setting procedure of Parameter writing is enabled with following steps 1 to 3. parameters 1. Set to MDI mode or emergency stop state. 2. Press OFFSET SETTING key several times or press soft key [SETING] to display SET
Page 431GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 6. After the parameters have been input, set PARAMETER WRITE on the SETTING screen to 0. Press RESET to release alram 100. 7. Convenient method 1) To change parameters in bit unit, press cursor key or , then the cursor becomes bit length and you can set param
Page 4326. INPUT AND OUTPUT OF DATA GFKE-0222-EN 6.2 The main CPU memorized the following data. Outputting the data 1/O device while the CNC is rurnning normally INPUTTING/ (1) CNC paramter OUTPUTTING (2) PMC parameter DATA (3) Pitch error compensation amount (4) Custom macro variable values (5) Tool compen
Page 433GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 0102 pecification number of input/output device Set value Input/output device 0 RS–232–C (Used control codes DC1 to DC4) 1 FANUC CASSETTE ADAPTOR 1 (FANUC CASSETTE B1/ B2) 2 FANUC CASSETTE ADAPTOR 3 (FANUC CASSETTE F1) 3 FANUC PROGRAM FILE Mate, FANUC FA Card
Page 4346. INPUT AND OUTPUT OF DATA GFKE-0222-EN 6.2.3 1. Select MDI mode. Outputting PMC 2. Press OFFSET SETTING key then soft key [SETTING] to select a setting screen. Parameters 3. Set the cursor to PARAMETER WRITE and input 1 and INPUT . At this time, alarm 100 will be generated. 4. Press SYSTEM key and
Page 435GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 6.2.5 When custom macro function is equipped, values of variable no. 500 and Outputting Custom later are output. Macro Variable Values 1. Press OFFSET SETTING key. 2. Press key and soft key [MACRO] to select custom macro variable screen. 3. Press soft key [(O
Page 4366. INPUT AND OUTPUT OF DATA GFKE-0222-EN 6.2.8 1. Set to the emergency stop state. Inputting CNC 2. Confirm that the patameters required to input data is correct. Parameters In addition, l indicates the standard setting for input/output devices made by FANUC. Change these settings according to the u
Page 437GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 7) 0103 Baud rate 1: 50 5: 200 9: 2400 2: 100 6: 300 l10: 4800 3: 110 7: 600 11: 9600 4: 150 8: 1200 12: 19200 [BPS] 3. Press soft key [(OPRT)] and soft key 4. Press soft key [READ] and [EXEC]. Then input of parameters are started. 5. Because alarm 300 will g
Page 4386. INPUT AND OUTPUT OF DATA GFKE-0222-EN 6.2.10 1. Release the emergency stop and select EDIT mode. Inputting Pitch Error 2. Confirm that PARAMETER WRITE=1 on the setting screen. Compensation Amount 3. Press PROG key and soft key [PRGRM] to display program contents. 4. Press soft key [(OPRT)], , [F
Page 439GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 12.Press address O and a program number (0001 for example) ,then press DELETE to delete the program. 6.2.12 Item 4 is not required for PPR. Inputting Tool 1. Select the EDIT mode. Compensation Amount 2. Turn off the program protect (KEY=1). 3. Press PROG key,
Page 4406. INPUT AND OUTPUT OF DATA GFKE-0222-EN For PPR, item 4 is not required. 1. Confirm that mode is EDIT mode. 2. Turn off the program protect (KEY3=1). 3. Press PROG key and press soft key [PRGRM] to select a part program file. 4. Press soft key [(OPRT)], [F SRH], and 6 [EXEC] to select a part progra
Page 441GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 6.3 INPUT/OUTPUT Super CAPi DATA 6.3.1 The following operation allows all the data used for Super CAPi M to be Input/Output of input and output in a lump. Conversational Data in a 1. Confirm the parameters shown below: P0020: I/O CHANNEL (select I/O device) :
Page 4426. INPUT AND OUTPUT OF DATA GFKE-0222-EN Series16i Conversational Data Screen DATA I/O @ READ DATA I/O PARA GUIDE READ I/O CHANNEL =0 @ PUNCH EXEC I/O DEVICE NO. =3 OR @ ALL CAP DATA PUNCH @ DEFAULT DATA EXEC @ PRE–TOOL LIST @ TOOL FILE @ CUT COND FILE SELECT FROM SOFT-KEY < FLOPPY READ PUNCH ALL DE
Page 443GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 6.3.2 You can input and output files individually. Input and Output of Each Execute the same operations from step 1 to 6 in the previous section 3.3.1. File (Super CAPi M) (1) Reading or Punching default files 7 Press [DEF. FILE]. 8 @ For reading, input a fil
Page 4446. INPUT AND OUTPUT OF DATA GFKE-0222-EN PROGRAM NO. = 1234 ³SFTKY INITAL SET FC25 BAR PROC(01) BAR OUTER END HEAD–L ROUGH T0505 PROC(02) BAR OUTER END HEAD–L FIN T0505 PROC(03) TRANS PROC(04) BAR OUTER END HEAD–R ROUGH T0505 PROC(05) BAR OUTER END HEAD–R FIN T0505 < CAN- EXE CEL C When [EXEC] is pr
Page 445GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA Input of conversational The machining program punched out by applying the procedure described machining programs on the previous page can be read into the NC via a reader/punch interface. A machining program can also be read from the memory card by setting bi
Page 4466. INPUT AND OUTPUT OF DATA GFKE-0222-EN (3) Display the tool data menu screen, then press [+]. The following soft keys appear. Press [PUNCH]. < 10 11 READ PUN CLEA \ CH R NOTE 1 When data is output to a memory card, the file name is CAPTOOL.DAT. 2 When an attempt is made to output data to a memory
Page 447GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 6.4 INITIAL SCREEN INPUTTING/ Symbolic OUTPUTTING Symbol FAPT TURN CAPi T PRESS [FAMILY PRESS [DATA PROGRAM] SET] KEY **FAMILY PROGRAM** **PARAMETER & DATA SET** 1. FAMILY PROGRAM OUTPUT 1. SYSTEM DATA SETTING 2. FAMILY PROGRAM INPUT 2. SETTING DATA CORRECTIO
Page 4486. INPUT AND OUTPUT OF DATA GFKE-0222-EN [TABLE 1] Input/Output of Family Program I/O Item Operation on I/O Remarks device Input Family program 2, n [INPUT] n=P⇒FANUC PPR ⇒ n=B⇒FANUC Cassette Sub cycle 5, n [INPUT] n=C⇒Sub Memory Output Family program 1, n [INPUT] *When n is omitted, parameter Sub c
Page 449GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 6.5 Symbol CAPi T data is stored in the sub–memory (SRAM) on the symbol CAPi T board. When replacing the symbol CAPi T board, perform data DUMP/RESTORE OF input/output operation according to this section. Symbol CAPi T DATA 6.5.1 1. System parameter (FAPT–SYS
Page 4506. INPUT AND OUTPUT OF DATA GFKE-0222-EN 6.6 CLEARING Symbol CAPi T DATA 6.6.1 Deleting File Name and Symbolic FAPT TURN Files (Initial screen) Press [Family program] Press [DATA SET] key key “Family program” menu “PARAMETER & DATASET” screen menu key Press [FILE NAME] key Not only file names of fam
Page 451GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 6.6.2 Press SP while turning on power. Clearing Symbol CAPi T Memory 421
Page 4526. INPUT AND OUTPUT OF DATA GFKE-0222-EN 6.7 To input/output a particular type of data, the corresponding screen is usually selected. For example, the parameter screen is used for parameter DATA INPUT/OUTPUT input from or output to an external input/output unit, while the program ON THE ALL IO scree
Page 453GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 6.7.1 Input/output–related parameters can be set on the ALL IO screen. Setting Parameters can be set, regardless of the mode. Input/Output–Related Parameters Setting input/output–related parameters Procedure 1 Press function key SYSTEM . 2 Press the rightmost
Page 4546. INPUT AND OUTPUT OF DATA GFKE-0222-EN 5 Set the parameters corresponding to the type of input/output unit to be used. (Parameter setting is possible regardless of the mode.) Tip First, set an I/O channel. The parameters on this screen change to those corresponding to a specified I/O channel. D I/
Page 455GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 6.7.2 A program can be input and output using the ALL IO screen. Inputting and When entering a program using a cassette or card, the user must specify the input file containing the program (file search). Outputting Programs File search Procedure 1 Press soft
Page 4566. INPUT AND OUTPUT OF DATA GFKE-0222-EN Inputting a program Procedure 1 Press soft key [PRGRM] on the ALL IO screen, described in Section 6.7.1. 2 Select EDIT mode. A program directory is displayed. 3 Press soft key [(OPRT)] . The screen and soft keys change as shown below. ⋅ A program directory is
Page 457GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA Outputting programs Procedure 1 Press soft key [PRGRM] on the ALL IO screen, described in Section 6.7.1. 2 Select EDIT mode. A program directory is displayed. 3 Press soft key [(OPRT)] . The screen and soft keys change as shown below. ⋅ A program directory is
Page 4586. INPUT AND OUTPUT OF DATA GFKE-0222-EN Deleting files Procedure 1 Press soft key [PRGRM] on the ALL IO screen, described in Section 6.7.1. 2 Select EDIT mode. A program directory is displayed. 3 Press soft key [(OPRT)] . The screen and soft keys change as shown below. ⋅ A program directory is disp
Page 459GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 6.7.3 Parameters can be input and output using the ALL IO screen. Inputting and Outputting Parameters Inputting parameters Procedure 1 Press soft key [PARAM] on the ALL IO screen, described in Section 6.7.1. 2 Select EDIT mode. 3 Press soft key [(OPRT)] . Sof
Page 4606. INPUT AND OUTPUT OF DATA GFKE-0222-EN 6.7.4 Offset data can be input and output using the ALL IO screen. Inputting and Outputting Offset Data Inputting offset data Procedure 1 Press soft key [OFFSET] on the ALL IO screen, described in Section 6.7.1. 2 Select EDIT mode. 3 Press soft key [(OPRT)] .
Page 461GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 6.7.5 Custom macro common variables can be output using the ALL IO screen. Outputting Custom Macro Common Variables Outputting custom macro common variables Procedure 1 Press soft key [MACRO] on the ALL IO screen, described in Section 6.7.1. 2 Select EDIT mod
Page 4626. INPUT AND OUTPUT OF DATA GFKE-0222-EN 6.7.6 The ALL IO screen supports the display of a directory of floppy files, as Inputting and well as the input and output of floppy files. Outputting Floppy Files Displaying a file directory Procedure 1 Press the rightmost soft key (continuous menu key) on t
Page 463GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA READ/PUNCH (FLOPPY) O1234 N12345 No. FILE NAME (Meter) VOL 0001 PARAMETER 46.1 0002 ALL.PROGRAM 12.3 0003 O0001 11.9 0004 O0002 11.9 0005 O0003 11.9 0006 O0004 0007 O0005 11.9 0008 O0010 11.9 0009 O0020 11.9 11.9 F SRH File No.=2 >2_ EDIT * * * * * * * * * *
Page 4646. INPUT AND OUTPUT OF DATA GFKE-0222-EN Inputting a file Procedure 1 Press the rightmost soft key (continuous menu key) on the ALL IO screen, described in Section 6.7.1. 2 Press soft key [FLOPPY] . 3 Select EDIT mode. The floppy screen is displayed. 4 Press soft key [(OPRT)] . The screen and soft k
Page 465GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA Outputting a file Procedure 1 Press the rightmost soft key (continuous menu key) on the ALL IO screen, described in Section 6.7.1. 2 Press soft key [FLOPPY] . 3 Select EDIT mode. The floppy screen is displayed. 4 Press soft key [(OPRT)] . The screen and soft
Page 4666. INPUT AND OUTPUT OF DATA GFKE-0222-EN Deleting a file Procedure 1 Press the rightmost soft key (continuous menu key) on the ALL IO screen, described in Section 6.7.1. 2 Press soft key [FLOPPY] . 3 Select EDIT mode. The floppy screen is displayed. 4 Press soft key [(OPRT)] . The screen and soft ke
Page 467GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 6.8 By setting the I/O channel (parameter No. 20) to 4, files on a memory card can be referenced, and different types of data such as part programs, DATA INPUT/OUTPUT parameters, and offset data on a memory card can be input and output in USING A MEMORY text
Page 4686. INPUT AND OUTPUT OF DATA GFKE-0222-EN Displaying a directory of stored files Procedure 1 Press the EDIT switch on the machine operator’s panel. 2 Press function key PROG . 3 Press the rightmost soft key (continuous menu key). 4 Press soft key [CARD]. The screen shown below is displayed. Using pag
Page 469GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA Searching for a file Procedure 1 Press the EDIT switch on the machine operator’s panel. 2 Press function key PROG . 3 Press the rightmost soft key (continuous menu key). 4 Press soft key [CARD]. The screen shown below is displayed. DIRECTORY (M–CARD) O0034 N0
Page 4706. INPUT AND OUTPUT OF DATA GFKE-0222-EN Reading a file Procedure 1 Press the EDIT switch on the machine operator’s panel. 2 Press function key PROG . 3 Press the rightmost soft key (continuous menu key). 4 Press soft key [CARD]. Then, the screen shown below is displayed. DIRECTORY (M–CARD) O0034 N0
Page 471GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA 8 To specify a file with its file name, press soft key [N READ] in step 6 above. The screen shown below is displayed. DIRECTORY (M–CARD) O0001 N00010 No. FILE NAME COMMENT 0012 O0050 (MAIN PROGRAM) 0013 TESTPRO (SUB PROGRAM–1) 0014 O0060 (MACRO PROGRAM) ~ ~ R
Page 4726. INPUT AND OUTPUT OF DATA GFKE-0222-EN Writing a file Procedure 1 Press the EDIT switch on the machine operator’s panel. 2 Press function key PROG . 3 Press the rightmost soft key (continuous menu key). 4 Press soft key [CARD]. The screen shown below is displayed. DIRECTORY (M–CARD) O0034 N00045 N
Page 473GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA Deleting a file Procedure 1 Press the EDIT switch on the machine operator’s panel. 2 Press function key PROG . 3 Press the rightmost soft key (continuous menu key). 4 Press soft key [CARD]. The screen shown below is displayed. DIRECTORY (M–CARD) O0034 N00045
Page 4746. INPUT AND OUTPUT OF DATA GFKE-0222-EN Batch input/output with a memory card On the ALL IO screen, different types of data including part programs, parameters, offset data, pitch error data, custom macros, and workpiece coordinate system data can be input and output using a memory card; the screen
Page 475GFKE-0222-EN 6. INPUT AND OUTPUT OF DATA PAGE 6 With page keys PAGE and , scroll through the file directory or program directory. 7 When this screen is displayed, the program data item is selected. The soft keys for other screens are displayed by pressing the rightmost soft key (continuous menu key)
Page 4766. INPUT AND OUTPUT OF DATA GFKE-0222-EN Error codes Memory card error codes Code Meaning 007 The memory card is protected. 030 The memory card is not inserted into its slot. 032 The memory card’s battery is exhausted. 102 The memory card does not have sufficient free space. 105 No memory card is mo
Page 477GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC 7 INTERFACE BETWEEN CNC AND PMC This chapter describes the signals between the machine operator’s panel, magnetics cabinet and the PMC, connection of the signals between PMC and CNC, and confirmation method of on/off state of these signals. It also descri
Page 4787.1 GENERAL OF High–speed processing signal PMCDGN Input Contacts *DEC a *ESP, SKIP, ESKIP, XAE, YAE, ZAE (M series) [0] . . 0V Open *DEC a *ESP, SKIP, ESKIP, XAE, ZAE, +MIT a (T series) [1] . . 24V Close INTERFACE NC PMCDGN PMCDGN * DI/DO PMC–SA/SB MT (Machine Tool builder) ST1 DOOR ST ST1 G X RV X
Page 479GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC 7.2 SPECIFICATION OF PMC 7.2.1 Specification Series 21i/210i/210is–B Series 16i/160i/160is/18i/180i/180is/21i/210i/210is–B Function PMC–SA1 PMC–SA1 PMC–SB7 (loader control) Programmingmethod Ladder Ladder Ladder Number of ladder levels 2 2 3 1st level exe
Page 4807. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN NOTE 1 The maximum number of steps assumes programming using basic instructions. The maximum number of steps varies according to the status of functional instruction use. 2 The total sequence program size (including all of the ladders, symbols/comments,
Page 481GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC NOTE 1 I/O of channel 2 of the I/O Link can be assigned. This area is usable when the I/O Link point extension option is selected. 2 This area is reserved for the PMC. I/O cannot be assigned to this area. Do not use this area for sequence programs. 3 This
Page 4827. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN (3) R9002 to R9005 (Operation output registers for the DIVB functional instruction) The data remaining after the DIVB functional instruction is executed in output. #7 #6 #5 #4 #3 #2 #1 #0 R9002 R9003 Register for remainder R9004 (used by DIVB instruction
Page 483GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC R9091.5 104ms 96ms 200ms R9091.6 504ms 496ms 1s (5) Ladder execution start signal, ladder stop signal, ladder execution state signal (PMC–SB7) 1 Ladder execution start signal and latter stop signal With the ladder execution start signal or the ladder stop
Page 4847. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 R9015 R9091.2: Ladder execution state signal 0: Ladder stopped 1: Ladder being executed 7.2.4 Execution Period of PMC For PMC–SA1 Sequence program 1st level From NC (High–speed se- (1) quence) END1 2nd level (Normal sequence) (2)–
Page 485GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC For PMC–SB7 CNC (F) 1st level END1 2nd level Synchronized buffer END2 3rd END2level END3 Machine (X) From NC Ladder execution time 1st level Division 1 Division 2 Division n 2nd level 3rd level 8ms 8ms 8ms The ratio of the 1st level execution time to the
Page 4867. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN D For a ladder that uses the 3rd level, the setting of the upper limit (150) may not ensure full 3rd level operation. In such a case, set this parameter so that the processing times of the 1st level and 2nd level are reduced. The 1st ladder level or the
Page 487GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC 7.3 PMC SCREEN 7.3.1 PMC Menu Selection Procedure Using Soft Keys PMC–SA1 screen menu selection procedure [PMC] [PMCLAD] Ladder diagram display screen [PMCDGN] [TITLE] Title screen [STATUS] Signal status screen [ALARM] Alarm screen [TRACE] Trace function
Page 4887. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN PMC–SB7 screen menu selection procedure [PMC] [PMCLAD] [EDIT] Ladder diagram display screen Selection monitor function Ladder diagram editing screen [PMCDGN] [TITLE] Title screen [STATUS] Signal status screen [ALARM] Alarm screen [TRACE] Signal trace scr
Page 489GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC 7.3.2 Press soft key [PMCLAD], and a sequence program is displayed PMCLAD Screen dynamically and operation monitoring can be confirmed : (PMC–SA1) Number of net displayed Ladder display RUN/STOP status LADDER NET 0001–0004 MONIT RUN Comment LOG1 LOG1 ALWA
Page 4907. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN [Remarks] ⋅ The search function searches a signal in the forward direction and displays the ladder with the searched signal at its head. Because there may exist plural contacts, repeat the search operation to find plural locations, repeat the search oper
Page 491GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC D Display of setting trigger The setting address, condition and counter are displayed at the title line. “MODE:ON : X0000. 0 : 0 : 0001 ” COUNT: Trigger checking number (default 1) POINT: Trigger checking number (default 0) 0 : the top of the 1st level 1
Page 4927. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN (4) [TRGSRC]: An instruction at which the trigger function has been stopped by a specified address signal is searched for and indicated by blinking. (5) [INIT] : The trigger setting is initialized. D Divided display of ladder This function is used for di
Page 493GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC 7.3.3 Screen transitions are made as shown below. Ladder Diagram Display/Editing (PMC–SB7) PMC main menu [<] [LADDER DIAGRAM] Display (NOTE 1) Display function Program list (monitor) display screen [LIST] [ZOOM] [LIST] [ZOOM] [SWITCH] Ladder diagram Selec
Page 4947. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN D Transition to the selection monitor screen [SWITCH] D Forced input/output function (FORCING mode) “Number” + ENTER key Screen manipulation Soft keys on the ladder diagram display screen Main soft keys on the ladder diagram display screen Program list L
Page 495GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC D [SEARCH] Address/net number search This soft key searches for the address or net number corresponding to an entered character string, and displays the address on the screen. Both a bit address and a byte address can be searched for. When a number is ent
Page 4967. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN 4 [EDIT] Calling the ladder diagram editing screen This soft key switches the screen display to the ladder diagram editing screen. This soft key is displayed only when the programmer function is enabled. While the online monitor function is enabled, the
Page 497GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC Title information (details) Total number of programs Program subject to manipulation List display area Key input line Message display line Additional information line Simplified display screen A choice between the detail display screen and simplified disp
Page 4987. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN 3 [SETING] Screen setting This soft key calls the setting screen for the program list display screen. Various settings for program list display can be modified. To return to the program list display screen, use the return key [<]. For details of the sett
Page 499GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC 2 Calling the screen from the ladder diagram display screen On the ladder diagram display screen, press the [SWITCH] soft key. Ladder diagram display screen Selection monitor screen The selection monitor screen is shown below. Initially, no ladder diagram
Page 5007. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN Screen manipulation Selection monitor screen Jump to a ladder diagram net Program list screen Selection monitor screen initialization Erasing one net Setting for display Reading a ladder diagram net Switching to the ladder diagram display screen Soft key
Page 501GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC D Reading a ladder net on A ladder net can be read from the selection monitor screen. Use the the selection monitor procedure below to read a ladder net. screen (a) Specification of an address 1 Enter an address to be monitored. (Example: R14.7) 2 Press t
Page 5027. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN Ladder diagram display screen (search soft keys) 7.3.3.4 On the ladder diagram editing screen, a ladder program can be edited, and Ladder diagram editing its operation can be modified. To display the ladder diagram editing screen, press the [EDIT] soft k
Page 503GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC Ladder diagram editing screen CAUTION 1 A ladder can be edited, regardless of whether operation is in progress or stopped. Before an edited ladder can be executed, however, the ladder must be updated. Press the [UPDATE] soft key or update the ladder when
Page 5047. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN Screen manipulation Soft keys on the ladder diagram editing screen Program list Net selection Copy Switching to search soft keys Addition of a new net Cut Paste Deletion Modification of a net Reflection of modifications Screen setting Sequence program st
Page 505GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC 6 [SELECT] Selection of multiple nets This soft key is used to specify multiple nets when editing such as deletion, cut, or copy is performed. Determine the start point of a selection range with the [SELECT] soft key, then specify the end point of the sel
Page 5067. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN WARNING Use special care when starting/stopping a ladder program. If a ladder program is started/stopped when the start/stop timing is incorrect, or the machine state is improper, the machine may operate unexpectedly. Moreover, when a ladder program is s
Page 507GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC D Deleting a contact/coil function instruction [ ] D Adding/deleting a connection line [ ], [ ], [ ] D Editing the function instruction data table [TABLE] D Line/column insertion [INSLIN], [INSCLM], [APPCLM] D Changing the address of a contact or coil “Bi
Page 5087. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN 7.3.3.6 Signal trace function (PMC–SB7) Signal trace screen The signal trace screen is displayed when you press the [TRACE] soft key (initial screen) on the PMC diagnosis screen. Signal trace screen (initial screen) Trace parameter setting When you press
Page 509GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC (a) Sample/mode Set a sampling mode. D Period: A time period is used for sampling. D Signal transition: A signal transition is used for sampling. (b) Sampling/resolution Set the resolution of sampling. The default is 8 ms. The setting range is 8 ms to 1,0
Page 5107. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN Trigger position <– 1 second –><–––– 9 seconds ––––> | | | –1 0 9 (SEC) (i) Sampling condition This item becomes settable when “signal transition” is selected as the trace stop condition. Set a condition for sampling. D Trigger: Sampling is performed whe
Page 511GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC Sampling address setting (a) Address setting On page 2 of the trace parameter setting screen, set the address of a signal to be sampled. Trace parameter setting screen (page 2) Specify a bit address for a signal address. If a byte address is input, bits 0
Page 5127. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN Trace execution After trace parameter setting, press the [START] soft key on the trace screen. Trace operation is started. The screens below are examples of execution in the period mode and signal transition mode. Signal trace execution screen (time cycl
Page 513GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC Checking trace results Upon completion of trace execution, trace results can be checked. Signal trace result screen (time cycle mode) (a) Automatic selection range calculation display When you press the [MARK] soft key, the cursor position at that time is
Page 5147. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN (b) Enlarged/reduced trace result data display With the [Z.IN] or [Z.OUT] soft key, the graph can be enlarged or reduced. This operation changes the scale value of one graph division. Immediately after trace operation, the graph is enlarged to a maximum
Page 515GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC 7.3.4 Press soft key [PMCDGN] then PMC’s diagnostic screen is displayed. PMCDGN Screen D TITLE screen The title data registered when a ladder program is prepared is displayed. Page number PMC TITLE DATA #1 MONIT RUN PMC PROGRAM NO. : EDITION NO. : PMC CON
Page 5167. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN D STATUS screen On/Off state of input/output signals and internal relay is displayed. PMC SIGNAL STATUS MONIT RUN ADDRESS 7 6 5 4 3 2 1 0 ED7 ED6 ED5 ED4 ED3 ED2 ED1 ED0 Signal G0000 0 0 0 0 1 0 1 0 name ED15 ED14 ED13 ED12 ED11 ED10 ED9 ED8 Signal state
Page 517GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC D TRACE screen Every time a specified signal changes, the signal status is memorized in (PMC–SA1) the trace memory. This function is useful for identifying intermittent troubles. 1 Trace parameter screen PMC SIGNAL TRACE MONIT RUN TRACE MODE : (0:1BYTE/1:
Page 5187. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN 2 Trace memory contents display screen PMC SIGNAL TRACE MONIT RUN 1ST ADDRESS=X008(E1) 2ND ADDRESS=G000(FF) Trace address NO. 7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0 and mask 0000 . . . . . . . . . . . . . . . . data(in pa- rentheses) I * * * * * * * ÀÀÀÀÀÀÀÀÀÀÀ
Page 519GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC 7.3.5 PMCPRM Screen D Inputting PMC parameters from the MDI 1 Set to MDI mode or emergency stop state. 2 Set PARAMETER WRITE (on setting screen) to 1 or set the program protect signal (KEY4) to 1. PWE KEY4 Timer f – Counter f f Either one Keep relay f – D
Page 5207. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN D COUNTER screen This screen sets and displays max. value of counter and current value of the counter instruction (SUB 4). Page no. (screen is scrolled by page key) Max. value of counter (Minimum value is specified by counter ins.) Current value of count
Page 521GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC D DATA TABLE screen 1 Data table setting screen No. of screen PMC DATA TBL CONTROL #001 MONIT RUN GROUP TABLE COUNT = 2 No. of data table NO. ADDRESS PARAMETER TYPE NO.OF DATA groups 001 D0000 00000000 0 10 002 D0020 00000011 1 20 003 004 No. of 005 data
Page 5227. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN 2 Data display screen Group number Page number PMC PRM (DATA) 001/001 MONIT RUN NO. ADDRESS DATA 000 D0000 0 001 D0001 0 002 D0002 0 003 D0003 0 004 D0004 0 005 D0005 0 006 D0006 0 007 D0007 0 008 D0008 0 009 D0009 0 C.DATA G–SRCH SEARCH a. Soft key [C.D
Page 523GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC D Trace function start (PMC–SB7:K906.5) Manual (0): The trace function starts trace operation when the [EXEC] soft key is pressed. Automatic (1): The trace function starts sampling automatically after the power is turned on. D Enable editing (PMC–SB7:K901
Page 5247. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN 7.3.7 Online Setting 7.3.7.1 Online setting screen Fig. 7.3.7.1 Online monitor setting screen Meanings of Soft key EMG ST: Terminates communication forcibly. Use this key if communication becomes abnormal and the connection cannot be terminated normally.
Page 525GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC (2) Set the parameter of ”CHANNEL” and ”BAUD RATE”. (3) Move the cursor to the ”RS–232C” item with Up or Down Cursor key. (4) Select ”USE” with Left or Right Cursor key. 2 Case of connection by Ethernet (FAPT LADDER–III, Ladder Editing Package) (1) Move t
Page 5267. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN USE TIME : The maximum time in the communication processing is displayed. RS–232C : The communication condition of RS–232C is displayed. HIGH SPEED I/F : The communication condition of HIGH SPEED I/F is displayed. Displayed during the communication with
Page 527GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC 7.4 LIST OF SIGNALS BY EACH MODE D Automatic operation MODE INPUT/OUTPUT SIGNAL FEED RATE, ETC EDIT [PMC ⇒ CNC] KEY3(Program protect key) [PMC ⇒ CNC) [PMC ⇒ CNC] ST (Cycle start) *FV0 to 7 *SP (Feed hold) (Feed rate over- SBK (Single block) ride) DRN (Dry
Page 5287. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN D Manual operation MODE INPUT/OUTPUT SIGNAL FEED RATE, ETC Handle/ [PMC ⇒ CNC] [PMC ⇒ CNC] M incremental HSnA to D (Axis selection) n:1 to 3(No. of MPGs) MP1, MP2 A +α, –α (Jog feed) (Multiplier) N U JOG [PMC ⇒ CNC] [PMC ⇒ CNC] A RT (Rapid traverse) *JV0
Page 529GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC 7.5 (1) For 1–path control LIST OF INPUT/ The relationship of the addresses of the interface signals transferred between the CNC and PMC are shown below. OUTPUT SIGNALS CNC QG0001+– PMC I0001+ – MT IF0001+– Q0001+ – (2) For 2–path control The relationship
Page 5307. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN D List of input/output signals f : Available F : Available only with 2–path control – : Unavailable T M Symbol Signal name Address series series *+ED1 to *+ED8 External deceleration signal QG0945+ f f *+L1 to *+L8 Overtravel signal QG0913+ f f *-ED1 to *
Page 531GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC T M Symbol Signal name Address series series *SSTP1 QG0220 f f *SSTP2 QG0221 f f Individual spindle stop signals *SSTP3 QG0222 f f *SSTP4 QG0215 f f *SUCPF Spindle unclamp completion signal QG0229 f – *TLV0 to *TLV9 Tool life count override signal QG0393
Page 5327. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN T M Symbol Signal name Address series series ARSTA QG0569 f f ARSTB QG0601 f f Alarm reset signal (serial spindle) ARSTC QG1641 f f ARSTD QG2137 f f B00 to B31 2nd auxiliary function code signal IF0241+ to IF0265+ f f BAL Battery alarm signal IF0011 f f
Page 533GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC T M Symbol Signal name Address series series DEFMDA QG0580 f f DEFMDB QG0612 f f Differential mode command signal (serial spindle) DEFMDC QG1652 f f DEFMDD QG2148 f f DEN Distribution end signal IF0012 f f DM00 IF0080 f f DM01 IF0079 f f Decode M signal D
Page 5347. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN T M Symbol Signal name Address series series EC0A to EC6A QG1145 to +6 f f EC0B to EC6B QG1221 to +6 f f Axis control command signal (PMC axis control) EC0C to EC6C QG1337 to +6 f f EC0D to EC6D QG1433 to +6 f f ECKZA IF1042 f f ECKZB IF1066 f f Followin
Page 535GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC T M Symbol Signal name Address series series EIF0A to EIF15A QG1153+,QG1161+ f f EIF0B to EIF15B QG1249+,QG1257+ f f Axis control feedrate signal (PMC axis control) EIF0C to EIF15C QG1345+,QG1353+ f f EIF0D to EIF15D QG1441+,QG1449+ f f EINPA IF1041 f f E
Page 5367. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN T M Symbol Signal name Address series series EOTNA IF1047 f f EOTNB IF1071 f f - Negative-direction overtravel signal (PMC axis control) EOTNC IF1095 f f EOTND IF1119 f f EOTPA IF1046 f f EOTPB IF1070 f f - Positive-direction overtravel signal (PMC axis
Page 537GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC T M Symbol Signal name Address series series EXOFA IF0381 f f EXOFB IF0413 f f Motor activation off status signal (serial spindle) EXOFC IF1365 f f EXOFD IF2149 f f EXRD External read start signal QG0466 f f EXSTP External read/punch stop signal QG0467 f
Page 5387. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN T M Symbol Signal name Address series series HROV 1% step rapid traverse override select signal QG0776 f f HS1A to HS1D Manual handle feed axis selection signal QG0145 to +3 f f HS1AO Software operator's panel signal(HS1A) IF0617 f f HS1BO Software opera
Page 539GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC T M Symbol Signal name Address series series KEY1 to KEY4 Memory protect signal QG0372 to +3 f f KEYO Software operator's panel signal(KEY1 to KEY4) IF0607 f f LDT1A IF0365 f f LDT1B IF0397 f f Load detection signal 1 (serial spindle) LDT1C IF1349 f f LDT
Page 5407. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN T M Symbol Signal name Address series series Flexible synchronization control mode select signal switching MFSYNA to MFSYND IF1577 to 3 – f accepted signals MH Manual handle feed select check signal IF0026 f f MHPCC HPCC mode signal IF0535 – f MI1 to MI8
Page 541GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC T M Symbol Signal name Address series series MRDYA QG0568 f f MRDYB QG0600 f f Machine ready signal (serial spindle) MRDYC QG1640 f f MRDYD QG2136 f f MREF Manual reference position return selection check signal IF0038 f f MRMT DNC operation select check
Page 5427. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN T M Symbol Signal name Address series series OVRA QG0581 f f OVRB QG0613 f f Analog override command signal (serial spindle) OVRC QG1653 f f OVRD QG2149 f f PBATL Absolute position detector battery voltage low alarm signal IF1384 f f PBATZ Absolute posit
Page 543GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC T M Symbol Signal name Address series series RCFNA IF0372 f f RCFNB IF0404 f f Output switch completion signal (serial spindle) RCFNC IF1356 f f RCFND IF12140 f f RCHA QG0576 f f RCHB QG0608 f f Power line status check signal (serial spindle) RCHC QG1648
Page 5447. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN T M Symbol Signal name Address series series RSLA QG0575 f f RSLB QG0607 f f Output switch request signal (serial spindle) RSLC QG1647 f f RSLD QG2143 f f RST Reset signal IF0010 f f RT Manual rapid traverse selection signal QG0160 f f RTAP Rigid tapping
Page 545GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC T M Symbol Signal name Address series series SGN QG0270 f f SGN2 QG0286 f f Spindle motor command polarity select signal SGN3 QG0302 f f SGN4 QG2190 f f SHA00 to SHA11 QG0625 to QG0636 f f SHB00 to SHB11 QG0641 to QG0652 f f Spindle orientation external s
Page 5467. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN T M Symbol Signal name Address series series SPSLA QG0571 f f SPSLB QG0603 f f Spindle select signal (serial spindle) SPSLC QG1643 f f SPSLD QG2139 f f SPSTP Spindle stop complete signal QG0231 f – SPSYC Spindle synchronous control signal QG0307 f f SPWR
Page 547GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC T M Symbol Signal name Address series series SYNC to SYNC8 QG1105+ f – Synchronous control axis selection signals SYNC to SYNC7 QG1105 to +6 F – SYNCJ1 to SYNCJ8 Simple synchronous manual feed axis select signal QG1121+ – f SYNMOD EGB mode signal IF0527 f
Page 5487. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN T M Symbol Signal name Address series series UINT Interrupt signal for custom macro QG0428 f f UO000 to UO015 IF0433+,IF0441+ f f Output signal for custom macro UO100 to UO131 IF0449+ to IF0473+ f f WATO Waiting signal IF0511 F F WOQSM Workpiece coordina
Page 549GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC 7.6 LIST OF ADDRESSES D Address list (1–path For a signal that is common to the M series and T series, and is usable for control) only one of the two series, hatching is provided on the upper part (the T series) or lower part (M series) for which the sign
Page 5507. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN PMC → CNC Address Bit number #7 #6 #5 #4 #3 #2 #1 #0 QG0001+ ED7 ED6 ED5 ED4 ED3 ED2 ED1 ED0 QG0009+ ED15 ED14 ED13 ED12 ED11 ED10 ED9 ED8 QG0017+ ESTB EA6 EA5 EA4 EA3 EA2 EA1 EA0 QG0025+ QG0033+ MFIN3 MFIN2 FIN QG0041+ BFIN AFL BFIN TFIN SFIN EFIN MFIN
Page 551GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG0201+ EPNS EPN13 EPN12 EPN11 EPN10 EPN9 EPN8 QG0209+ *SSTP4 SWS4 PC4SLC PC3SLC QG0217+ CON *SSTP3 *SSTP2 *SSTP1 SWS3 SWS2 SWS1 QG0225+ PC2SLC SPSTP *SCPF *SUCPF GR2 GR1 QG0233+ *SSTP SOR SAR GR31 GR21 QG0241+ SOV7 SOV6 SOV5 SOV4
Page 5527. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG0401+ *TLV9 *TLV8 QG0409+ *CHLD CHPST *CHP8 *CHP4 *CHP2 *CHP0 QG0417+ RMTDI7 RMTDI6 RMTDI5 RMTDI4 RMTDI3 RMTDI2 RMTDI1 RMTDI0 QG0425+ CDZ SMZ UINT TMRON QG0433+ UI007 UI006 UI005 UI004 UI003 UI002 UI001 UI000 QG0441+ UI015 UI014
Page 553GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG0601+ RCHB RSLB INTGB SOCNB MCFNB SPSLB *ESPB ARSTB QG0609+ RCHHGB MFNHGB INCMDB OVRB DEFMDB NRROB ROTAB INDXB QG0617+ DSCNB SORSLB MPOFB SLVB MORCMB QG0625+ SHA07 SHA06 SHA05 SHA04 SHA03 SHA02 SHA01 SHA00 QG0633+ SHA11 SHA10 SHA
Page 5547. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG0801+ +J8 +J7 +J6 +J5 +J4 +J3 +J2 +J1 QG0809+ QG0817+ –J8 –J7 –J6 –J5 –J4 –J3 –J2 –J1 QG0825+ QG0833+ +EXL8 +EXL7 +EXL6 +EXL5 +EXL4 +EXL3 +EXL2 +EXL1 QG0841+ –EXL8 –EXL7 –EXL6 –EXL5 –EXL4 –EXL3 –EXL2 –EXL1 QG0849+ MI8 MI7 MI6 MI
Page 555GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG0993+ DTCH8 DTCH7 DTCH6 DTCH5 DTCH4 DTCH3 DTCH2 DTCH1 QG1001+ IUDD8 IUDD7 IUDD6 IUDD5 IUDD4 IUDD3 IUDD2 IUDD1 QG1009+ SVF8 SVF7 SVF6 SVF5 SVF4 SVF3 SVF2 SVF1 QG1017+ QG1025+ QG1033+ QG1041+ *IT8 *IT7 *IT6 *IT5 *IT4 *IT3 *IT2 *IT1
Page 5567. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG1193+ EID31A EID30A EID29A EID28A EID27A EID26A EID25A EID24A QG1201+ DRNE RTE OVCE ROV2E ROV1E QG1209+ *FV7E *FV6E *FV5E *FV4E *FV3E *FV2E *FV1E *FV0E QG1217+ QG1225+ QG1233+ EBUFB ECLRB ESTPB ESOFB ESBKB EMBUFB ELCKZB EFINB QG
Page 557GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG1393+ QG1401+ QG1409+ QG1417+ QG1425+ EBUFD ECLRD ESTPD ESOFD ESBKD EMBUFD ELCKZD EFIND QG1433+ EMSBKD EC6D EC5D EC4D EC3D EC2D EC1D EC0D QG1441+ EIF7D EIF6D EIF5D EIF4D EIF3D EIF2D EIF1D EIF0D QG1449+ EIF15D EIF14D EIF13D EIF12D
Page 5587. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG1593+ IOLBH3 IOLBH2 QG1601+ EASIP8 EASIP7 EASIP6 EASIP5 EASIP4 EASIP3 EASIP2 EASIP1 QG1609+ QG1617+ QG1625+ FTCLR FTCAL FTCMD QG1633+ MRDYC ORCML SFRC SRVC CTH1C CTH2C TLMHC TLMLC QG1641+ RCHC RSLC INTGC SOCNC MCFNC SPSLC *ESPC
Page 559GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG1793+ QG1801+ QG1809+ QG1817+ QG1825+ QG1833+ QG1841+ QG1849+ QG1857+ QG1865+ QG1873+ QG1881+ QG1889+ QG1897+ QG1905+ QG1913+ QG1921+ QG1929+ QG1937+ QG1945+ QG1953+ QG1961+ QG1969+ QG1977+ QG1985+ 529
Page 5607. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG1993+ QG2001+ QG2009+ QG2017+ QG2025+ QG2033+ QG2041+ QG2049+ QG2057+ QG2065+ QG2073+ QG2081+ QG2089+ QG2097+ QG2105+ QG2113+ QG2121+ QG2129+ MRDYD ORCMD SFRD SRVD CTH1D CTH2D TLMHD TLMLD QG2137+ RCHD RSLD INTGD SOCND MCFND SPSL
Page 561GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG2193+ QG2201+ QG2209+ QG2217+ QG2225+ QG2233+ QG2241+ QG2249+ QG2257+ QG2265+ QG2273+ QG2281+ QG2289+ QG2297+ QG2305+ QG2313+ QG2321+ QG2329+ QG2337+ ITCD QG2345+ QG2353+ QG2361+ QG2369+ QG2377+ QG2385+ 531
Page 5627. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG2393+ QG2401+ QG2409+ QG2417+ QG2425+ QG2433+ QG2441+ QG2449+ QG2457+ QG2465+ QG2473+ QG2481+ QG2489+ QG2497+ QG2505+ QG2513+ QG2521+ QG2529+ QG2537+ QG2545+ QG2553+ 532
Page 563GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC CNC → PMC Address Bit number #7 #6 #5 #4 #3 #2 #1 #0 IF0001+ OP SA STL SPL RWD IF0009+ MA TAP ENB DEN BAL RST AL IF0017+ MDRN CUT SRNMV THRD CSS RPDO INCH IF0025+ MTCHIN MEDT MMEM MRMT MMDI MJ MH MINC IF0033+ MREF MAFL MSBK MABSM MMLK MBDT1 IF0041+ MBDT9
Page 5647. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF0201+ S31 S30 S29 S28 S27 S26 S25 S24 IF0209+ T07 T06 T05 T04 T03 T02 T01 T00 IF0217+ T15 T14 T13 T12 T11 T10 T09 T08 IF0225+ T23 T22 T21 T20 T19 T18 T17 T16 IF0233+ T31 T30 T29 T28 T27 T26 T25 T24 IF0241+ B07 B06 B05 B04 B03 B0
Page 565GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF0401+ MORA2B MORA1B PORA2B SLVSB RCFNB RCHPB CFINB CHPB IF0409+ EXOFB SORENB MSOVRB INCSTB PC1DTB IF0417+ IF0425+ EKENB BGEACT RPALM RPBSY PRGDPL INHKY IF0433+ UO007 UO006 UO005 UO004 UO003 UO002 UO001 UO000 IF0441+ UO015 UO014 U
Page 5667. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF0601+ SPO KEYO DRNO MLKO SBKO BDTO IF0609+ ROV2O ROV1O RTAP MP2O MP1O IF0617+ RTO HS1DO HS1CO HS1BO HS1AO IF0625+ *FV7O *FV6O *FV5O *FV4O *FV3O *FV2O *FV1O *FV0O IF0633+ *JV7O *JV6O *JV5O *JV4O *JV3O *JV2O *JV1O *JV0O IF0641+ *J
Page 567GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF0801+ ZP48 ZP47 ZP46 ZP45 ZP44 ZP43 ZP42 ZP41 IF0809+ IF0817+ MV8 MV7 MV6 MV5 MV4 MV3 MV2 MV1 IF0825+ IF0833+ INP8 INP7 INP6 INP5 INP4 INP3 INP2 INP1 IF0841+ IF0849+ MVD8 MVD7 MVD6 MVD5 MVD4 MVD3 MVD2 MVD1 IF0857+ IF0865+ MMI8 MM
Page 5687. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF1001+ IF1009+ –OT8 –OT7 –OT6 –OT5 –OT4 –OT3 –OT2 –OT1 IF1017+ IF1025+ IF1033+ *EAXSL EOV0 IF1041+ EBSYA EOTNA EOTPA EGENA EDENA EIALA ECKZA EINPA IF1049+ EABUFA EMFA IF1057+ EM28A EM24A EM22A EM21A EM18A EM14A EM12A EM11A IF1065
Page 569GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF1201+ IF1209+ EM48D EM44D EM42D EM41D EM38D EM34D EM32D EM31D IF1217+ IF1225+ IF1233+ IF1241+ IF1249+ IF1257+ IF1265+ IF1273+ IF1281+ IF1289+ IF1297+ IF1305+ IF1313+ IF1321+ IF1329+ IF1337+ IF1345+ ORARC TLMC LDT2C LDT1C SARC SDT
Page 5707. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF1401+ IF1409+ IF1417+ EDGN EPARM EVAR EPRG EWTIO ESTPIO ERDIO IOLNK IF1425+ SRLNO3 SRLNO2 SRLNO1 SRLNO0 IF1433+ IF1441+ CLRCH8 CLRCH7 CLRCH6 CLRCH5 CLRCH4 CLRCH3 CLRCH2 CLRCH1 IF1449+ IF1457+ EACNT8 EACNT7 EACNT6 EACNT5 EACNT4 E
Page 571GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF1601+ IF1609+ IF1617+ IF1625+ IF1633+ IF1641+ IF1649+ IF1657+ IF1665+ EGBM8 EGBM7 EGBM6 EGBM5 EGBM4 EGBM3 EGBM2 EGBM1 IF1673+ IF1681+ IF1689+ IF1697+ IF1705+ IF1713+ IF1721+ IF1729+ IF1737+ IF1745+ IF1753+ IF1761+ IF1769+ IF1777+
Page 5727. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF1801+ IF1809+ IF1817+ IF1825+ IF1833+ IF1841+ IF1849+ IF1857+ IF1865+ IF1873+ IF1881+ IF1889+ IF1897+ IF1905+ IF1913+ IF1921+ IF1929+ IF1937+ IF1945+ IF1953+ IF1961+ IF1969+ IF1977+ IF1985+ IF1993+ 542
Page 573GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF2001+ IF2009+ IF2017+ IF2025+ IF2033+ IF2041+ IF2049+ IF2057+ IF2065+ IF2073+ IF2081+ IF2089+ IF2097+ IF2105+ IF2113+ SPWRN8 SPWRN7 SPWRN6 SPWRN5 SPWRN4 SPWRN3 SPWRN2 SPWRN1 IF2121+ SPWRN9 IF2129+ ORARD TLMD LDT2D LDT1D SARD SDTD
Page 5747. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF2201+ IF2209+ IF2217+ IF2225+ IF2233+ IF2241+ IF2249+ IF2257+ IF2265+ IF2273+ IF2281+ IF2289+ IF2297+ IF2305+ IF2313+ IF2321+ IF2329+ IF2337+ IF2345+ IF2353+ IF2361+ IF2369+ IF2377+ IF2385+ IF2393+ 544
Page 575GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF2401+ IF2409+ IF2417+ IF2425+ IF2433+ IF2441+ IF2449+ IF2457+ IF2465+ IF2473+ IF2481+ IF2489+ IF2497+ IF2505+ IF2513+ IF2521+ 545
Page 5767. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN D Address list (2–path In general, signal addresses are assigned to each path as indicated below. control) However, some signals common to both paths are allocated to path 1. The table below indicates the addresses of the interface signals between the CN
Page 577GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC PMC → CNC Path 1 Address Bit number #7 #6 #5 #4 #3 #2 #1 #0 QG0001+ ED7 #1 ED6 #1 ED5 #1 ED4 #1 ED3 #1 ED2 #1 ED1 #1 ED0 #1 QG0009+ ED15 #1 ED14 #1 ED13 #1 ED12 #1 ED11 #1 ED10 #1 ED9 #1 ED8 #1 QG0017+ ESTB #1 EA6 #1 EA5 #1 EA4 #1 EA3 #1 EA2 #1 EA1 #1 EA0
Page 5787. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG0201+ EPNS#1 EPN13#1 EPN12#1 EPN11#1 EPN10#1 EPN9#1 EPN8#1 QG0209+ *SSTP4#1 SWS4#1 PC4SLC#1 PC3SLC#1 QG0217+ CON #1 *SSTP3#1 *SSTP2#1 *SSTP1#1 SWS3 #1 SWS2 #1 SWS1 #1 QG0225+ PC2SLC#1 SPSTP#1 *SCPF#1 *SUCPF#1 GR2 #1 GR1 #1 QG023
Page 579GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG0401+ *TLV9 #1 *TLV8 #1 QG0409+ *CHLD #1 CHPST #1 *CHP8 #1 *CHP4 #1 *CHP2 #1 *CHP0 #1 QG0417+ QG0425+ CDZ #1 SMZ #1 UINT #1 TMRON#1 QG0433+ UI007 #1 UI006 #1 UI005 #1 UI004 #1 UI003 #1 UI002 #1 UI001 #1 UI000 #1 QG0441+ UI015 #1
Page 5807. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG0601+ RCHB#1 RSLB #1 INTGB #1 SOCNB#1 MCFNB#1 SPSLB#1 *ESPB#1 ARSTB#1 QG0609+ RCHHGB#1 MFNHGB#1 INCMDB#1 OVRB#1 DEFMDB#1 NRROB#1 ROTAB#1 INDXB#1 QG0617+ DSCNB#1 SORSLB#1 MPOFB#1 SLVB#1 MORCMB#1 QG0625+ SHA07#1 SHA06#1 SHA05#1 SH
Page 581GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 3# #2 #1 #0 QG0801+ +J8#1 +J7#1 +J6#1 +J5#1 +J4 #1 +J3 #1 +J2 #1 +J1 #1 QG0809+ QG0817+ –J8 #1 –J7 #1 –J6 #1 –J5 #1 –J4 #1 –J3 #1 –J2 #1 –J1 #1 QG0825+ QG0833+ +EXL8#1 +EXL7#1 +EXL6#1 +EXL5#1 +EXL4#1 +EXL3#1 +EXL2#1 +EXL1#1 QG0841+ –EXL8#1 –EX
Page 5827. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG0993+ DTCH8#1 DTCH7#1 DTCH6#1 DTCH5#1 DTCH4#1 DTCH3#1 DTCH2#1 DTCH1#1 QG1001+ IUDD8#1 IUDD7#1 IUDD6#1 IUDD5#1 IUDD4#1 IUDD3#1 IUDD2#1 IUDD1#1 QG1009+ SVF8 #1 SVF7 #1 SVF6 #1 SVF5 #1 SVF4 #1 SVF3 #1 SVF2 #1 SVF1 #1 QG1017+ QG1025
Page 583GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG1193+ EID31A#1 EID30A#1 EID29A#1 EID28A#1 EID27A#1 EID26A#1 EID25A#1 EID24A#1 QG1201+ DRNE#1 RTE #1 OVCE#1 ROV2E#1 ROV1E#1 QG1209+ *FV7E#1 *FV6E#1 *FV5E#1 *FV4E#1 *FV3E#1 *FV2E#1 *FV1E#1 *FV0E#1 QG1217+ QG1225+ QG1233+ EBUFB#1 EC
Page 5847. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG1393+ QG1401+ QG1409+ QG1417+ QG1425+ EBUFD#1 ECLRD#1 ESTPD#1 ESOFD#1 ESBKD#1 EMBUFD#1 ELCKZD#1 EFIND#1 QG1433+ EMSBKD#1 EC6D #1 EC5D #1 EC4D #1 EC3D #1 EC2D #1 EC1D #1 EC0D #1 QG1441+ EIF7D#1 EIF6D#1 EIF5D#1 EIF4D#1 EIF3D#1 EIF
Page 585GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG1593+ QG1601+ EASIP8#1 EASIP7#1 EASIP6#1 EASIP5#1 EASIP4#1 EASIP3#1 EASIP2#1 EASIP1#1 QG1609+ QG1617+ QG1625+ QG1633+ MRDYC#1 ORCMC#1 SFRC#1 SRVC#1 CTH1C#1 CTH2C#1 TLMHC#1 TLMLC#1 QG1641+ RCHC#1 RSLC#1 INTGC#1 SOCNC#1 MCFNC#1 SPS
Page 5867. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG1793+ QG1801+ QG1809+ QG1817+ QG1825+ QG1833+ QG1841+ QG1849+ QG1857+ QG1865+ QG1873+ QG1881+ QG1889+ QG1897+ QG1905+ QG1913+ QG1921+ QG1929+ QG1937+ QG1945+ QG1953+ QG1961+ QG1969+ QG1977+ QG1985+ 556
Page 587GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG1993+ QG2001+ QG2009+ QG2017+ QG2025+ QG2033+ QG2041+ QG2049+ QG2057+ QG2065+ QG2073+ QG2081+ QG2089+ QG2097+ QG2105+ QG2113+ QG2121+ QG2129+ MRDYD#1 ORCMD#1 SFRD#1 SRVD#1 CTH1D#1 CTH2D#1 TLMHD#1 TLMLD#1 QG2137+ RCHD#1 RSLD#1 INT
Page 5887. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG2193+ QG2201+ QG2209+ QG2217+ QG2225+ QG2233+ QG2241+ QG2249+ QG2257+ QG2265+ QG2273+ QG2281+ QG2289+ QG2297+ QG2305+ QG2313+ QG2321+ QG2329+ QG2337+ ITCD#1 QG2345+ QG2353+ QG2361+ QG2369+ QG2377+ QG2385+ 558
Page 589GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG2393+ QG2401+ QG2409+ QG2417+ QG2425+ QG2433+ QG2441+ QG2449+ QG2457+ QG2465+ QG2473+ QG2481+ QG2489+ QG2497+ QG2505+ QG2513+ QG2521+ QG2529+ QG2537+ QG2545+ QG2553+ 559
Page 5907. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN PMC → CNC Path 2 Address Bit number #7 #6 #5 #4 #3 #2 #1 #0 QG10001+ ED7#2 ED6#2 ED5#2 ED4#2 ED3#2 ED2#2 ED1#2 ED0#2 QG10009+ ED15#2 ED14#2 ED13#2 ED12#2 ED11#2 ED10#2 ED9#2 ED8#2 QG10017+ ESTB#2 EA6#2 EA5#2 EA4#2 EA3#2 EA2#2 EA1#2 EA0#2 QG10025+ QG10033
Page 591GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG10201+ EPNS#2 EPN13#2 EPN12#2 EPN11#2 EPN10#2 EPN9#2 EPN8#2 QG10209+ *SSTP4#2 SWS4#2 PC4SLC#2 PC3SLC#2 QG10217+ CON#2 *SSTP3#2 *SSTP2#2 *SSTP1#2 SWS3#2 SWS2#2 SWS1#2 QG10225+ PC2SLC#2 SPSTP#2 *SCPF#2 *SUCPF#2 GR2#2 GR1#2 QG10233+
Page 5927. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG10401+ *TLV9 #2 *TLV8 #2 QG10409+ *CHLD #2 CHPST #2 *CHP8 #2 *CHP4 #2 *CHP2 #2 *CHP0 #2 QG10417+ QG10425+ CDZ#2 SMZ#2 UINT#2 TMRON#2 QG10433+ UI007#2 UI006#2 UI005#2 UI004#2 UI003#2 UI002#2 UI001#2 UI000#2 QG10441+ UI015#2 UI014
Page 593GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG10601+ RCHB#2 RSLB#2 INTGB #2 SOCNB#2 MCFNB#2 SPSLB#2 *ESPB#2 ARSTB#2 QG10609+ RCHHGB#2 MFNHGB#2 INCMDB#2 OVRB#2 DEFMDB#2 NRROB#2 ROTAB#2 INDXB#2 QG10617+ DSCNB#2 SORSLB#2 MPOFB#2 SLVB#2 MORCMB#2 QG10625+ SHA07#2 SHA06#2 SHA05#2
Page 5947. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG10801+ +J8#2 +J7#2 +J6#2 +J5#2 +J4#2 +J3#2 +J2#2 +J1#2 QG10809+ QG10817+ –J8#2 –J7#2 –J6#2 –J5#2 –J4#2 –J3#2 –J2#2 –J1#2 QG10825+ QG10833+ +EXL8#2 +EXL7#2 +EXL6#2 +EXL5#2 +EXL4#2 +EXL3#2 +EXL2#2 +EXL1#2 QG10841+ –EXL8#2 –EXL7#2
Page 595GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG10993+ DTCH8#2 DTCH7#2 DTCH6#2 DTCH5#2 DTCH4#2 DTCH3#2 DTCH2#2 DTCH1#2 QG11001+ IUDD8#2 IUDD7#2 IUDD6#2 IUDD5#2 IUDD4#2 IUDD3#2 IUDD2#2 IUDD1#2 QG11009+ SVF8#2 SVF7#2 SVF6#2 SVF5#2 SVF4#2 SVF3#2 SVF2#2 SVF1#2 QG11017+ QG11025+ QG
Page 5967. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG11193+ EID31A#2 EID30A#2 EID29A#2 EID28A#2 EID27A#2 EID26A#2 EID25A#2 EID24A#2 QG11201+ DRNE#2 RTE#2 OVCE#2 ROV2E#2 ROV1E#2 QG11209+ *FV7E#2 *FV6E#2 *FV5E#2 *FV4E#2 *FV3E#2 *FV2E#2 *FV1E#2 *FV0E#2 QG11217+ QG11225+ QG11233+ EBUF
Page 597GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG11393+ QG11401+ QG11409+ QG11417+ QG11425+ EBUFD#2 ECLRD#2 ESTPD#2 ESOFD#2 ESBKD#2 EMBUFD#2 ELCKZD#2 EFIND#2 QG11433+ EMSBKD#2 EC6D#2 EC5D#2 EC4D#2 EC3D#2 EC2D#2 EC1D#2 EC0D#2 QG11441+ EIF7D#2 EIF6D#2 EIF5D#2 EIF4D#2 EIF3D#2 EIF2
Page 5987. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG11593+ QG11601+ EASIP8#2 EASIP7#2 EASIP6#2 EASIP5#2 EASIP4#2 EASIP3#2 EASIP2#2 EASIP1#2 QG11609+ QG11617+ QG11625+ QG11633+ MRDYC#2 ORCMC#2 SFRC#2 SRVC#2 CTH1C#2 CTH2C#2 TLMHC#2 TLMLC#2 QG11641+ RCHC#2 RSLC#2 INTGC#2 SOCNC#2 MCF
Page 599GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG11793+ QG11801+ QG11809+ QG11817+ QG11825+ QG11833+ QG11841+ QG11849+ QG11857+ QG11865+ QG11873+ QG11881+ QG11889+ QG11897+ QG11905+ QG11913+ QG11921+ QG11929+ QG11937+ QG11945+ QG11953+ QG11961+ QG11969+ QG11977+ QG11985+ 569
Page 6007. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG11993+ QG12001+ QG12009+ QG12017+ QG12025+ QG12033+ QG12041+ QG12049+ QG12057+ QG12065+ QG12073+ QG12081+ QG12089+ QG12097+ QG12105+ QG12113+ QG12121+ QG12129+ MRDYD#2 ORCMD#2 SFRD#2 SRVD#2 CTH1D#2 CTH2D#2 TLMHD#2 TLMLD#2 QG1213
Page 601GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 QG12193+ QG12201+ QG12209+ QG12217+ QG12225+ QG12233+ QG12241+ QG12249+ QG12257+ QG12265+ QG12273+ QG12281+ QG12289+ QG12297+ QG12305+ QG12313+ QG12321+ QG12329+ QG12337+ ITCD#2 QG12345+ QG12353+ QG12361+ QG12369+ QG12377+ QG12385+
Page 6027. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG12393+ QG12401+ QG12409+ QG12417+ QG12425+ QG12433+ QG12441+ QG12449+ QG12457+ QG12465+ QG12473+ QG12481+ QG12489+ QG12497+ QG12505+ QG12513+ QG12521+ QG12529+ QG12537+ QG12545+ QG12553+ 572
Page 603GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC CNC Path 1 → PMC Address Bit number #7 #6 #5 #4 #3 #2 #1 #0 IF0001+ OP#1 SA#1 STL#1 SPL#1 RWD#1 IF0009+ MA#1 TAP#1 ENB#1 DEN#1 BAL#1 RST#1 AL#1 IF0017+ MDRN#1 CUT#1 SRNMV#1 THRD#1 CSS#1 RPDO#1 INCH#1 IF0025+ MTCHIN#1 MEDT#1 MMEM#1 MRMT#1 MMDI#1 MJ#1 MH#1
Page 6047. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF0201+ S31#1 S30#1 S29#1 S28#1 S27#1 S26#1 S25#1 S24#1 IF0209+ T07#1 T06#1 T05#1 T04#1 T03#1 T02#1 T01#1 T00#1 IF0217+ T15#1 T14#1 T13#1 T12#1 T11#1 T10#1 T09#1 T08#1 IF0225+ T23#1 T22#1 T21#1 T20#1 T19#1 T18#1 T17#1 T16#1 IF0233
Page 605GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF0401+ MORA2B#1 MORA1B#1 PORA2B#1 SLVSB#1 RCFNB#1 RCHPB#1 CFINB#1 CHPB#1 IF0409+ EXOFB#1 SORENB#1 MSOVRB#1 INCSTB#1 PC1DTB#1 IF0417+ IF0425+ EKENB BGEACT#1 RPALM#1 RPBSY#1 PRGDPL INHKY IF0433+ UO007#1 UO006#1 UO005#1 UO004#1 UO003
Page 6067. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF0601+ SPO#1 KEYO#1 DRNO#1 MLKO#1 SBKO#1 BDTO#1 IF0609+ ROV2O#1 ROV1O#1 RTAP#1 MP2O#1 MP1O#1 IF0617+ RTO#1 HS1DO#1 HS1CO#1 HS1BO#1 HS1AO#1 IF0625+ *FV7O#1 *FV6O#1 *FV5O#1 *FV4O#1 *FV3O#1 *FV2O#1 *FV1O#1 *FV0O#1 IF0633+ *JV7O#1 *J
Page 607GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF0801+ ZP48#1 ZP47#1 ZP46#1 ZP45#1 ZP44#1 ZP43#1 ZP42#1 ZP41#1 IF0809+ IF0817+ MV8#1 MV7#1 MV6#1 MV5#1 MV4#1 MV3#1 MV2#1 MV1#1 IF0825+ IF0833+ INP8#1 INP7#1 INP6#1 INP5#1 INP4#1 INP3#1 INP2#1 INP1#1 IF0841+ IF0849+ MVD8#1 MVD7#1 M
Page 6087. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF1001+ IF1009+ –OT7#1 –OT6#1 –OT5#1 –OT4#1 –OT3#1 –OT2#1 –OT4#1 IF1017+ IF1025+ IF1033+ *EAXSL#1 EOV0#1 IF1041+ EBSYA#1 EOTNA#1 EOTPA#1 EGENA#1 EDENA#1 EIALA#1 ECKZA#1 EINPA#1 IF1049+ EABUFA#1 EMFA#1 IF1057+ EM28A#1 EM24A#1 EM22A
Page 609GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF1201+ IF1209+ EM48D#1 EM44D#1 EM42D#1 EM41D#1 EM38D#1 EM34D#1 EM32D#1 EM31D#1 IF1217+ IF1225+ IF1233+ IF1241+ IF1249+ IF1257+ IF1265+ IF1273+ IF1281+ IF1289+ IF1297+ IF1305+ IF1313+ IF1321+ IF1329+ IF1337+ IF1345+ ORARC#1 TLMC#1
Page 6107. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF1401+ IF1409+ IF1417+ EDGN#1 EPARM#1 EVAR#1 EPRG#1 EWTIO#1 ESTPIO#1 ERDIO#1 IOLNK#1 IF1425+ SRLNO3#1 SRLNO2#1 SRLNO1#1 SRLNO0#1 IF1433+ IF1441+ CLRCH8#1 CLRCH7#1 CLRCH6#1 CLRCH5#1 CLRCH4#1 CLRCH3#1 CLRCH2#1 CLRCH1#1 IF1449+ IF14
Page 611GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF1601+ IF1609+ IF1617+ IF1625+ IF1633+ IF1641+ IF1649+ IF1657+ IF1665+ IF1673+ IF1681+ IF1689+ IF1697+ IF1705+ IF1713+ IF1721+ IF1729+ IF1737+ IF1745+ IF1753+ IF1761+ IF1769+ IF1777+ IF1785+ IF1793+ 581
Page 6127. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF1801+ IF1809+ IF1817+ IF1825+ IF1833+ IF1841+ IF1849+ IF1857+ IF1865+ IF1873+ IF1881+ IF1889+ IF1897+ IF1905+ IF1913+ IF1921+ IF1929+ IF1937+ IF1945+ IF1953+ IF1961+ IF1969+ IF1977+ IF1985+ IF1993+ 582
Page 613GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF2001+ IF2009+ IF2017+ IF2025+ IF2033+ IF2041+ IF2049+ IF2057+ IF2065+ IF2073+ IF2081+ IF2089+ IF2097+ IF2105+ SPWRN8 #1 SPWRN7 #1 SPWRN6 #1 SPWRN5 #1 SPWRN4 #1 SPWRN3 #1 SPWRN2 #1 SPWRN1 #1 IF2113+ SPWRN9 #1 IF2121+ IF2129+ ORARD
Page 6147. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF2201+ IF2209+ IF2217+ IF2225+ IF2233+ IF2241+ IF2249+ IF2257+ IF2265+ IF2273+ IF2281+ IF2289+ IF2297+ IF2305+ IF2313+ IF2321+ IF2329+ IF2337+ IF2345+ IF2353+ IF2361+ IF2369+ IF2377+ IF2385+ IF2393+ 584
Page 615GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF2401+ IF2409+ IF2417+ IF2425+ IF2433+ IF2441+ IF2449+ IF2457+ IF2465+ IF2473+ IF2481+ IF2489+ IF2497+ IF2505+ IF2513+ IF2521+ 585
Page 6167. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN CNC Path 2 → PMC Address Bit number #7 #6 #5 #4 #3 #2 #1 #0 IF10001+ OP#2 SA#2 STL#2 SPL#2 RWD#2 IF10009+ MA#2 TAP#2 ENB#2 DEN#2 BAL#2 RST#2 AL#2 IF10017+ MDRN#2 CUT#2 SRNMV#2 THRD#2 CSS#2 RPDO#2 INCH#2 IF10025+ MTCHIN#2 MEDT#2 MMEM#2 MRMT#2 MMDI#2 MJ#2
Page 617GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF10201+ S31#2 S30#2 S29#2 S28#2 S27#2 S26#2 S25#2 S24#2 IF10209+ T07#2 T06#2 T05#2 T04#2 T03#2 T02#2 T01#2 T00#2 IF10217+ T15#2 T14#2 T13#2 T12#2 T11#2 T10#2 T09#2 T08#2 IF10225+ T23#2 T22#2 T21#2 T20#2 T19#2 T18#2 T17#2 T16#2 IF1
Page 6187. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF10401+ MORA2B#2 MORA1B#2 PORA2B#2 SLVSB#2 RCFNB#2 RCHPB#2 CFINB#2 CHPB#2 IF10409+ EXOFB#2 SORENB#2 MSOVRB#2 INCSTB#2 PC1DTB#2 IF10417+ IF10425+ BGEACT#2 RPALM#2 RPBSY#2 IF10433+ UO007#2 UO006#2 UO005#2 UO004#2 UO003#2 UO002#2 UO
Page 619GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF10601+ SPO#2 KEYO#2 DRNO#2 MLKO#2 SBKO#2 BDTO#2 IF10609+ ROV2O#2 ROV1O#2 RTAP#2 MP2O#2 MP1O#2 IF10617+ RTO#2 HS1DO#2 HS1CO#2 HS1BO#2 HS1AO#2 IF10625+ *FV7O#2 *FV6O#2 *FV5O#2 *FV4O#2 *FV3O#2 *FV2O#2 *FV1O#2 *FV0O#2 IF10633+ *JV7O#
Page 6207. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF10801+ ZP48#2 ZP47#2 ZP46#2 ZP45#2 ZP44#2 ZP43#2 ZP42#2 ZP41#2 IF10809+ IF10817+ MV8#2 MV7#2 MV6#2 MV5#2 MV4#2 MV3#2 MV2#2 MV1#2 IF10825+ IF10833+ INP8#2 INP7#2 INP6#2 INP5#2 INP4#2 INP3#2 INP2#2 INP1#2 IF10841+ IF10849+ MVD8#2
Page 621GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF11001+ IF11009+ –OT7#2 –OT6#2 –OT5#2 –OT4#2 –OT3#2 –OT2#2 –OT1#2 IF11017+ IF11025+ IF11033+ *EAXSL#2 EOV0#2 IF11041+ EBSYA#2 EOTNA#2 EOTP#2 EGENA#2 EDENA#2 EIALA#2 ECKZA#2 EINPA#2 IF11049+ EABUFA#2 EMFA#2 IF11057+ EM28A#2 EM24A#2
Page 6227. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF11201+ IF11209+ EM48D#2 EM44D#2 EM42D#2 EM41D#2 EM38D#2 EM34D#2 EM32D#2 EM31D#2 IF11217+ IF11225+ IF11233+ IF11241+ IF11249+ IF11257+ IF11265+ IF11273+ IF11281+ IF11289+ IF11297+ IF11305+ IF11313+ IF11321+ IF11329+ IF11337+ IF11
Page 623GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF11401+ IF11409+ IF11417+ EDGN#2 EPARM#2 EVAR#2 EPRG#2 EWTIO#2 ESTPIO#2 ERDIO#2 IOLNK#2 IF11425+ SRLNO3#2 SRLNO2#2 SRLNO1#2 SRLNO0#2 IF11433+ IF11441+ CLRCH8#2 CLRCH7#2 CLRCH6#2 CLRCH5#2 CLRCH4#2 CLRCH3#2 CLRCH2#2 CLRCH1#2 IF11449
Page 6247. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF11601+ IF11609+ IF11617+ IF11625+ IF11633+ IF11641+ IF11649+ IF11657+ IF11665+ IF11673+ IF11681+ IF11689+ IF11697+ IF11705+ IF11713+ IF11721+ IF11729+ IF11737+ IF11745+ IF11753+ IF11761+ IF11769+ IF11777+ IF11785+ IF11793+ 594
Page 625GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF11801+ IF11809+ IF11817+ IF11825+ IF11833+ IF11841+ IF11849+ IF11857+ IF11865+ IF11873+ IF11881+ IF11889+ IF11897+ IF11905+ IF11913+ IF11921+ IF11929+ IF11937+ IF11945+ IF11953+ IF11961+ IF11969+ IF11977+ IF11985+ IF11993+ 595
Page 6267. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF12001+ IF12009+ IF12017+ IF12025+ IF12033+ IF12041+ IF12049+ IF12057+ IF12065+ IF12073+ IF12081+ IF12089+ IF12097+ IF12105+ IF12113+ SPWRN8 #2 SPWRN7 #2 SPWRN6 #2 SPWRN5 #2 SPWRN4 #2 SPWRN3 #2 SPWRN2 #2 SPWRN1 #2 IF12121+ SPWRN9
Page 627GFKE-0222-EN 7.INTERFACE BETWEEN CNC AND PMC #7 #6 #5 #4 #3 #2 #1 #0 IF12201+ IF12209+ IF12217+ IF12225+ IF12233+ IF12241+ IF12249+ IF12257+ IF12265+ IF12273+ IF12281+ IF12289+ IF12297+ IF12305+ IF12313+ IF12321+ IF12329+ IF12337+ IF12345+ IF12353+ IF12361+ IF12369+ IF12377+ IF12385+ IF12393+ 597
Page 6287. INTERFACE BETWEEN CNC AND PMC GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 IF12401+ IF12409+ IF12417+ IF12425+ IF12433+ IF12441+ IF12449+ IF12457+ IF12465+ IF12473+ IF12481+ IF12489+ IF12497+ IF12505+ IF12513+ IF12521+ 598
Page 629GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8 EMBEDDED ETHERNET FUNCTION This chapter describes the specifications of the embedded Ethernet function for Series 16i/18i/21i/160i/180i/210i/160is/180is/210is–B. 599
Page 6308. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 8.1 EMBEDDED ETHERNET AND PCMCIA ETHERNET The embedded Ethernet function can be used by selecting one of two types of devices: the embedded Ethernet port and PCMCIA Ethernet card. The PCMCIA Ethernet card is to be inserted into the memory card slot to the l
Page 631GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.2 With the embedded Ethernet function, the following functions can be operated: LIST OF FUNCTIONS S FACTOLINK function S FOCAS1/Ethernet function S DNC1/Ethernet function S FTP file transfer function 8.2.1 With the FACTOLINK function, data can be displaye
Page 6328. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN H Absolute position H Relative position H Machine position H Remaining travel amount H Actual speed D NC program D Part program storage directory information D NC data file H Parameter H Tool offset value H Custom macro variable H Workpiece origin offset H
Page 633GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.2.3 The DNC1/Ethernet function allows a personal computer to remotely DNC1/Ethernet control and monitor the CNC. The DNC1/Ethernet function provides software libraries in a simpler function call format when compared with Function the FOCAS1/Ethernet funct
Page 6348. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN Differences between the FOCAS1/Ethernet function and DNC1/Ethernet function Compared with the FOCAS1/Ethernet function, the DNC1/Ethernet function provides software libraries in a simpler function call format for frequently used functions. 604
Page 635GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.2.4 The FTP file transfer function transfers files with FTP. The function can FTP File Transfer read and punch NC programs and various types of NC data. Function NOTE The FTP file transfer function is usable with the control software for the embedded Ethe
Page 6368. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN NOTE 1 The embedded Ethernet function includes the FTP file transfer function. This function is almost equivalent to the NC data transfer function in the FTP mode of the Data Server function of the option board. 2 Compared with the option board, the embedde
Page 637GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.3 This section describes the setting of the parameters for the embedded Ethernet function for the Series 16i/18i/21i/160i/180i/210i/160is/180is/ SETTING THE 210is–B. EMBEDDED ETHERNET FUNCTION 8.3.1 This subsection describes the settings required to opera
Page 6388. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 8.3.1.2 On the Ethernet parameter setting screen, set the parameters for operating FACTOLINK parameter the FACTOLINK function. setting screen Display Procedure 1 Place the CNC in the MDI mode. 2 Press the function key SYSTEM . 3 Press the continuous menu ke
Page 639GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION PAGE 7 Switch the screen display with the page keys PAGE . If data is already registered, the data is displayed. 609
Page 6408. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN Display item and setting items Display item related to The item related to the embedded Ethernet function is displayed. the embedded Ethernet Item Description function MAC ADDRESS Embedded Ethernet MAC address Embedded Ethernet Set the TCP/IP–related items
Page 641GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.3.1.3 The NC parameters related to the FACTOLINK function are described Parameters below. Parameters 0802 Communicationchannel [Data type] Byte [Valid data range] 21: Select the embedded Ethernet. #7 #6 #5 #4 #3 #2 #1 #0 0810 MONO TIME BGS [Data type] Bit
Page 6428. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 0814 Trigger PMC address for logging [Data type] Word [Valid data range] 0 to 65535 Set a PMC address that serves as a trigger for specifying logging data. 0815 Logging data transmission interval [Data type] Double–word [Unit of data] Seconds [Valid data ra
Page 643GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.3.1.4 An example of minimum setting required to operate the FACTOLINK Using the FACTOLINK function on a small network is provided below. In this example, one personal computer is connected to two CNCs function on a small through FACTOLINK. network D On Pe
Page 6448. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 8.3.1.5 When configuring a large network or expanding an existing network, Configuring a large consult with your network manager to set an IP address, subnet mask, and router IP address. network 8.3.2 This subsection describes the settings required to opera
Page 645GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.3.2.2 On the Ethernet parameter setting screen, set the parameters for operating FOCAS1/Ethernet the FOCAS1/Ethernet function. parameter setting screen Display Procedure 1 Place the CNC in the MDI mode. 2 Press the function key SYSTEM . 3 Press the contin
Page 6468. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN If data is already registered, the data is displayed. 616
Page 647GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION Display item and setting items Display item related to The item related to the embedded Ethernet function is displayed. the embedded Ethernet Item Description function MAC ADDRESS Embedded Ethernet MAC address Embedded Ethernet Set the TCP/IP–related items
Page 6488. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN NOTE 1 When a small value is set for the item of time interval, communication load increases, and the performance of the network can be adversely affected. 2 The parameters for the PCMCIA Ethernet card are set to the following default values before shipment
Page 649GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.3.2.3 An example of minimum setting required to operate the Using the FOCAS1/Ethernet function on a small network is provided below. In this example, one personal computer is connected to two CNCs FOCAS1/Ethernet through FOCAS1/Ethernet. function on a sma
Page 6508. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 8.3.2.4 An example of minimum setting required to operate the DNC1/Ethernet Using the DNC1/Ethernet function on a small network is provided below. In this example, one personal computer is connected to two CNCs function on a small through DNC1/Ethernet. net
Page 651GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.3.2.5 When configuring a large network or expanding an existing network, Configuring a large consult with your network manager to set an IP address, subnet mask, and router IP address. network 8.3.3 This subsection describes the settings required to opera
Page 6528. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 8.3.3.2 On the Ethernet parameter setting screen, set the parameters for operating FTP file transfer the FTP file transfer function. parameter setting screen Display Procedure 1 Place the CNC in the MDI mode. 2 Press the function key SYSTEM . 3 Press the co
Page 653GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION If data is already registered, the data is displayed. 623
Page 6548. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN Display item and setting items Display item related to The item related to the embedded Ethernet function is displayed. the embedded Ethernet Item Description function MAC ADDRESS Embedded Ethernet MAC address Embedded Ethernet Set the TCP/IP–related items
Page 655GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.3.3.3 The NC parameters related to the FTP file transfer function are described Parameters below. Parameters 0020 I/O CHANNEL: Input/output device selection [Data type] Byte [Valid data range] 9: Select the embedded Ethernet as the input/output device. 09
Page 6568. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 8.3.3.4 An example of minimum setting required to operate the FTP file transfer Using the FTP file function on a small network is provided below. (Windows NT 4.0 Workstation is used as the OS for the personal computer.) transfer function on a In this exampl
Page 657GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.3.3.5 When configuring a large network or expanding an existing network, Configuring a large consult with your network manager to set an IP address, subnet mask, and router IP address. network 8.3.4 This subsection describes the method of parameter input
Page 6588. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN (b) Type 192.168.1.1 with the MDI keys. (c) Press the [INPUT] soft key or the function key INPUT to enter the data. This stores the parameter in the nonvolatile memory of the CNC. NOTE Turn on the power again so that you should make a changed parameter effe
Page 659GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION Method of lowercase character input The method of entering lowercase characters when specifying a user name, password, and login DIR is described below. Procedure 1 Place the CNC in the MDI mode. 2 Display the Ethernet parameter screen. 3 Move the cursor to
Page 6608. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 3 Move the cursor to LOGIN DIR with cursor keys. 4 Press the [STRING] soft key. The cursor position and soft key display change as shown below. 630
Page 661GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 5 Type ”/NCDATA/NCPROGRAM/LINE001/GROUP0” with the MDI keys, then press the [INPUT] soft key. 6 Next, type the remaining character string ”02” with the MDI keys, then press the [INPUT] soft key. [Tip] For example, even if the character string is divided int
Page 6628. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 7 To insert ”/FACTORY0010” between ”NCPROGRAM” and ”/LINE001”, move the cursor to ”/” prefixed to ”LINE001” then type ”/FACTORY0010” with the MDI keys. Finally, press the [INSERT] soft key. 8 To delete a character, move the cursor to the character to be del
Page 663GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION Method of entering special characters The method of entering special characters such as ”\” unavailable with the MDI keys is described below. As an example, the procedure for setting the character string ”PROG$” is described. Procedure 1 Place the CNC in th
Page 6648. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 5 Press the [$] soft key. 6 Press the [INPUT] soft key. 634
Page 665GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.4 There are two types of embedded Ethernet devices: the embedded Ethernet port and PCMCIA Ethernet card. SWITCHING Screen operation is required to switch between these two types of devices. BETWEEN THE EMBEDDED ETHERNET DEVICES Procedure 1 Place the CNC i
Page 6668. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 5 Press the [SWITCH] soft key. The screen for switching between the embedded Ethernet port and the PCMCIA Ethernet card appears. 6 Press the [PCMCIA] soft key. A confirmation message appears. Press the [EXEC] soft key to switch the device. NOTE Information
Page 667GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.5 This section describes the operation required of each embedded Ethernet function. EMBEDDED ETHERNET OPERATIONS 8.5.1 The operation of the FACTOLINK function is described below. FACTOLINK Function Display Procedure 1 Press the function key MESSAGE . 2 Pr
Page 6688. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 8.5.2 The operation of the FTP file transfer function is described below. FTP File Transfer Function 8.5.2.1 A list of the files held on the hard disk embedded to the host computer is Host file list display displayed. Procedure 1 Press the function key PROG
Page 669GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION NOTE Depending on the FTP server software, the number of displayed programs may differ between the host file list screen above and the host file list (detail) screen described below. 5 When a list of files is larger than one page, the screen display can be
Page 6708. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN NOTE The host file list (detail) screen shown above is an example of screen display, and information displayed may vary according to the specification of the FTP server used with the host computer. Display items D Number of registered The number of files re
Page 671GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.5.2.2 When a list of the files held on the hard disk embedded to the host Host file search computer is displayed, a file can be placed at the start of the list by specifying its file number. Procedure 1 Display the host file list screen. 2 Press the [SEAR
Page 6728. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 8.5.2.4 A file (NC program) on the host computer can be read to the CNC NC program input memory. For the host file list screen Procedure 1 Place the CNC in the EDIT mode. 2 Display the host file list screen. 3 Press the [READ] soft key. 4 Type the file numb
Page 673GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION For the program screen Procedure 1 Place the CNC in the EDIT mode. 2 Press the function key PROG . 3 Press the continuous menu key at the right end of the soft key display. 4 Press the [PRGRM] soft key. The program screen appears. 5 Press the [(OPRT)] soft
Page 6748. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 5 Press the [EXEC] soft key. 6 During output, ”OUTPUT” blinks in the lower–right corner of the screen. [Example of use] When an NC program (O0001) in the CNC memory is to be output to the hard disk embedded to the host computer, enter O0001. NOTE An outputt
Page 675GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.5.2.6 With the FTP file transfer function, the types of data listed below can be Input/output of various input/output. This subsection describes the input/output method. types of data A) NC parameter B) Tool offset value C) Custom macro variable D) Workpi
Page 6768. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 8 Press the [EXEC] soft key. 9 During output, ”OUTPUT” blinks in the lower–right corner of the screen. File name The fixed file name PRAMETER is used. File format, restrictions Refer to the operator’s manual of each CNC. Tool offset value input The file (to
Page 677GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION File name The fixed file name TOOLOFS is used. File format, restrictions Refer to the operator’s manual of each CNC. Workpiece origin offset value input The file (workpiece origin offset value) on the host computer can be input to the CNC memory. Procedure
Page 6788. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN Pitch error compensation input The file (pitch error compensation) on the host computer can be input to the CNC memory. Procedure 1 Place the CNC in the EDIT mode. 2 Press the function key SYSTEM . 3 Press the continuous menu key at the right end of the sof
Page 679GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION M code group input The file (M code group) on the host computer can be input to the CNC memory. Procedure 1 Place the CNC in the EDIT mode. 2 Press the function key SYSTEM . 3 Press the continuous menu key at the right end of the soft key display. 4 Press t
Page 6808. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN Operation history data input The file (operation history data) on the host computer can be input to the CNC memory. Procedure 1 Place the CNC in the EDIT mode. 2 Press the function key SYSTEM . 3 Press the continuous menu key at the right end of the soft ke
Page 681GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.5.2.7 The host computer to which the FTP file transfer function attempts to Checking and changing make a connection as the current communication destination can be checked. of the connection host Procedure 1 Press the function key PROG . 2 Press the conti
Page 6828. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN NOTE The title of the host computer that is the current communication destination of the embedded Ethernet is displayed in reverse video. 5 The connected host can be changed by pressing the [CON–1], [CON–2], or [CON–3] soft key. Display items D Port number,
Page 683GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.6 If an error occurs with each function of the embedded Ethernet function, the error message screen for the embedded Ethernet function displays an EMBEDDED error message. ETHERNET ERROR MESSAGE SCREEN Display Procedure 1 Press the function key MESSAGE . 2
Page 6848. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN PAGE 5 Switch the screen display with the page keys PAGE . [Tip] The latest error message is displayed at the top of the screen. To the right of an error message, the date and time data of the occurrence of the error is displayed. The format of date and tim
Page 685GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.7 With the embedded Ethernet function, a dedicated maintenance screen is available. EMBEDDED The maintenance screen enables operations to be checked when the ETHERNET embedded Ethernet function operates abnormally. MAINTENANCE SCREEN Display Procedure 1 P
Page 6868. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 6 The screen below is used to check the state of the communication cable and whether a communication destination exists. Enter the IP address of a communication destination through MDI keys, then press the [PING] soft key. Communication is performed three t
Page 687GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 7 The screen below is used to check the communication state of the embedded Ethernet function and the error detection count of the Ethernet controller. The screen consists of two pages: one page for an error detection count for transmission, and the other f
Page 6888. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 8 The screen below is used to check the state of each task of the embedded Ethernet function. Symbol Meaning MASTER CTRL E Ethernet controller being initialized D Data being processed(NOTE) W Waiting for data processing(NOTE) P Waiting for parameter setting
Page 689GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION Symbol Meaning PMC X Waiting for completion of Ethernet controller initializa- tion D Data being processed(NOTE) W Waiting for data processing(NOTE) FTP X Waiting for completion of Ethernet controller initializa- tion D Data being processed(NOTE) W Waiting
Page 6908. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 8.8 This section describes troubleshooting and check items associated with the embedded Ethernet function. TROUBLESHOOTING 8.8.1 1) Is an STP cable used for connection between the hub and embedded Check Items Related to Ethernet? Connection with the 2) Is t
Page 691GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 4) Is the length of the backbone cable 500 m or less? 5) Does the cable (transceiver cable) connecting a hub to a transceiver satisfy the specified length? S Usually, the maximum allowable length of a transceiver cable is 50 m. However, the maximum allowabl
Page 6928. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 8.8.4 This subsection describes how to check the state of communication Checking between the CNC and personal computer. Communication Checking the connection status and settings If communication with the CNC is not satisfactory or fails from time to time, c
Page 693GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 2) When no response is received (error) If no response is received from the CNC, the cause is considered to be a hardware connection error and/or software setting error. Check the hardware connection and software settings. Checking the influence of noise Th
Page 6948. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 2) Press the emergency stop button of the machine to turn off servo/spindle amplifier activation, then issue a ping command from the personal computer. 3) Count the number of lost packets (to which no response is returned). If lost packets occur in this sta
Page 695GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.9 If an error occurs with the embedded Ethernet function, the log screen of the embedded Ethernet function displays an error message. ERROR MESSAGES This section describes error messages displayed on the log screen. The major error messages are described
Page 6968. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN 8.9.2 TCP PORT NUMBER(???) IS INVALID EMB_ETH The setting (???) of the TCP port number is incorrect. Correct the TCP port number. FOCAS1/ETHER LOG Illegal Broadcast IP ADDRESS Screen The broadcast address for UDP transmission is incorrect. Correct the subne
Page 697GFKE-0222-EN 8. EMBEDDED ETHERNET FUNCTION 8.10 This section briefly describes Ethernet–related terms. The descriptions below provide minimum information only. For further GLOSSARY FOR information, refer to relevant publications available on the market. ETHERNET TCP/IP For Ethernet–based communicati
Page 6988. EMBEDDED ETHERNET FUNCTION GFKE-0222-EN IP addresses are internationally managed systematically. This means that before an IP address can be used, the IP address must be obtained formally from the international organization. If the network used by a user is a local network closed within the user’
Page 699GFKE-0222-EN 9. DIGITAL SERVO 9 DIGITAL SERVO This chapter describes servo tuning screen required for maintenance of digital servo and adjustment of reference position. 9.1 INITIAL SETTING SERVO PARAMETERS . . . . . . 670 9.2 SERVO TUNING SCREEN . . . . . . . . . . . . . . . . . . . . 684 9.3 ADJUST
Page 7009. DIGITAL SERVO GFKE-0222-EN 9.1 This section describes how to set initial servo parameters, which is used for field adjustment of machine tool. INITIAL SETTING 1. Turn on power at the emergency stop condition. SERVO PARAMETERS 2. Set the parameter to display the servo tuning screen. #7 #6 #5 #4 #3
Page 701GFKE-0222-EN 9. DIGITAL SERVO (2) Motor ID No. Select the motor ID No. of the servo motor to be used, according to the motor model and drawing number (the middle four digits of A06B–XXXX–BXXX) listed in the tables on subsequent pages. NOTE Servo axes are controlled in groups of two axes. So, for suc
Page 7029. DIGITAL SERVO GFKE-0222-EN - Linear motor Motor model 1500A/4 3000B/2 6000B/2 9000B/2 Motor specification 0410 0411 0412 0413 Motor type No. 90 91 92 93 Motor model 15000C/2 3000B/4 6000B/4 9000B/4 Motor specification 0414 0411–B811 0412–B811 0413–B811 Motor type No. 94 120 121 122 Motor model 15
Page 703GFKE-0222-EN 9. DIGITAL SERVO - αMi series servo motor Servo software series 9060 90B0 Motor model and motor type number αM2/5000i 162(262) A H αM3/5000i 165(265) A H αM8/4000i 185(285) A H αM12/4000i 188(288) A H αM22/4000i 215(315) A H αM30/4000i 218(318) A H αM40/4000i 222(322) A H - Linear motor
Page 7049. DIGITAL SERVO GFKE-0222-EN For aL series servo motor Model name a L3/3000 a L6/2000 a L9/3000 a L25/3000 a L50/2000 Drawing number 0561 0562 0564 0571 0572 Format number 56 or 68 57 or 69 58 or 70 59 60 For aC series servo motor Model name a C3/2000 a C6/2000 a C12/2000 a C22/1500 Drawing number
Page 705GFKE-0222-EN 9. DIGITAL SERVO (4) CMR PRM 1820 Command multiply ratio 1) When CMR is 1/2 to 1/27 Set value= 1 +100 CMR 2) When CMR is 0.5 to 48 Set value=2×CMR (5) Turn off the power then back on. (6) N/M of feed gear (F⋅FG) PRM 2084 n for flexible feed gear PRM 2085 m for flexible feed gear Setting
Page 7069. DIGITAL SERVO GFKE-0222-EN Setting for use of a separate detector (full–closed) Number of position pulses corresponding F⋅FG numerator (v 32767) to a predetermined amount of travel = (as irreducible fraction) F⋅FG denominator (v 32767) Number of position pulses corresponding to a predetermined am
Page 707GFKE-0222-EN 9. DIGITAL SERVO D Display The FSSB setting screen displays FSSB–based amplifier and axis information. This information can also be specified by the operator. 1. Press function key SYSTEM . 2. To display [FSSB], press continuous menu key several times. 3. Pressing soft key [FSSB] causes
Page 7089. DIGITAL SERVO GFKE-0222-EN D AXIS NO. (controlled axis number) The axis number of each controlled axis specified in parameters (Nos. 1920 to 1929) is displayed. If a number specified in these parameters falls outside the range of between 1 and the maximum number of controlled axes, 0 is displayed
Page 709GFKE-0222-EN 9. DIGITAL SERVO D M1 (connector number for pulse module 1) This item is the number of the connector for pulse module 1, specified in parameter No. 1931. D M2 (connector number for pulse module 2) This item is the number of the connector for pulse module 2, specified in parameter No. 19
Page 7109. DIGITAL SERVO GFKE-0222-EN AMPLIFIER MAINTENANCE O1000 N00001 AXIS NAME EDITION TEST MAINTE–NO. 1 X 01A 010123 01 2 Y 01A 010123 01 3 Z 01A 010123 01 4 A 02B 010123 01 5 B 02B 010123 01 6 C 02B 010123 01 MDI **** *** *** 13:11:56 [ AMP ][ AXIS ][ MAINTE ][ ][ ] The amplifier maintenance screen di
Page 711GFKE-0222-EN 9. DIGITAL SERVO CAUTION 1 For the parameters to be specified on the FSSB setting screen, do not attempt to enter values on the parameter screen using the MDI or a G10 command. Use only the FSSB screen to enter values for these parameters. 2 If pressing soft key [SET] results in a warni
Page 7129. DIGITAL SERVO GFKE-0222-EN 2) Axis setting screen AXIS SETTING O1000 N00001 AXIS NAME AMP M1 M2 1–DSF Cs TNDM 1 X A1–L 0 0 0 0 1 2 Y A1–M 1 0 1 0 0 3 Z A2–L 0 0 0 1 0 4 A A3–L 0 0 0 0 2 5 B A3–M 0 0 0 0 0 6 C A4–L 0 0 0 0 0 >_ MDI **** *** *** 13:11:56 [SETTING][ ][ READ ][ ][ INPUT ] On the axis
Page 713GFKE-0222-EN 9. DIGITAL SERVO When soft key [SET] is pressed on the axis setting screen after data entry, the warning message “SPECIFIED DATA IS OUT OF RANGE” is displayed if any of the following conditions is satisfied. D Both M1 and M2 are nonzero for an axis. D Any two of TWO–AXES, Cs, and TANDEM
Page 7149. DIGITAL SERVO GFKE-0222-EN 9.2 SERVO TUNING SCREEN 9.2.1 Set a parameter to display the servo tuning screen. Parameter Setting #7 #6 #5 #4 #3 #2 #1 #0 3111 SVS #0 (SVS) 0 : Servo tuning screen is not displayed. 1 : Servo tuning screen is displayed. 9.2.2 1. Press SYSTEM key and soft key [SV. PARA
Page 715GFKE-0222-EN 9. DIGITAL SERVO #7 #6 #5 #4 #3 #2 #1 #0 Alarm1 OVL LV OVC HCA HVA DCA FBA OFA DGN (200) : #7 (OVL) : Overload alarm #6 (LV) : Insufficient voltage alarm #5 (OVC) : Overcurrent alarm #4 (HCA) : Abnormal current alarm #3 (HVA) : Excessive voltage alarm #2 (DCA) : Discharge alarm #1 (FBA)
Page 7169. DIGITAL SERVO GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 Alarm4 DTE CRC STB PRM DGN (203) : #7 (DTE) : Communication error of serial pulse coder. There is no response. Generally, a leading cause is a break in a wire. #6 (CRC) : Communication error of serial pulse coder. Transmitted data is in error. #5
Page 717GFKE-0222-EN 9. DIGITAL SERVO 9.3 ADJUSTING REFERENCE POSITION (DOG METHOD) 9.3.1 General Speed Rapid traverse (PRM1420α) FL rate (PRM1425 α ) Time Rapid traverse acc./dec. time constant (PRM1620 α ) *DECα PCZ Grid Grid shift amount Reference counter capacity (PRM1850) (PRM1821) 10mm/rev 10000P + Er
Page 7189. DIGITAL SERVO GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 PRM 1005 DLZ #1(DLZ) 0 : The normal method (dog) is used for reference position return. 1 : Reference position setting without dogs is used (axis by axis). NOTE A reference position can be set axis by axis by setting bit 1 of parameter No. 1002 t
Page 719GFKE-0222-EN 9. DIGITAL SERVO D Separate Type Pulse Coder or Linear Scale is Used PRM 1821 Reference counter capacity per axis [P] Normally, the number of feedback pulses per motor revolution is set to the reference counter capacity. When plural reference marks are on a linear scale, a quotient of t
Page 7209. DIGITAL SERVO GFKE-0222-EN 9.4 When there are no dog nor limit switch for reference position return, this function enables the tool to return the reference position that is set by DOGLESS MTB. REFERENCE When the absolute position detector is used, the reference position once POSITION SETTING set
Page 721GFKE-0222-EN 9. DIGITAL SERVO 9.4.3 Associated Parameters #7 #6 #5 #4 #3 #2 #1 #0 PRM 1002 DLZ #1(DLZ) 0 : Dog is used for reference position return 1 : Dogless reference position setting (all axes) #7 #6 #5 #4 #3 #2 #1 #0 PRM 1005 DLZ #1(DLZ) 0 : The normal method (dog) is used for reference positi
Page 7229. DIGITAL SERVO GFKE-0222-EN 9.5 αi SERVO WARNING INTERFACE General The αi servo system can report the warning status before one of the following target alarms occurs. When the warning status is entered, a report to the PMC is issued. For example, this signal can be used by the machine for retracti
Page 723GFKE-0222-EN 9. DIGITAL SERVO A timing chart for handling a warning is shown below. Occurrence of a warning Servo amplifier SVWRN1–4 (Warning) Perform deceleration stop or block stop during this time period with the PMC to stop the machine without damage. The time period varies with the warning type
Page 7249. DIGITAL SERVO GFKE-0222-EN 9.6 αi SERVO INFORMATION SCREEN General In the αi servo system, ID information output from each of the connected units is obtained and output to the CNC screen. The units that have ID information are shown below. (Remark: Some instances of these units do not have ID inf
Page 725GFKE-0222-EN 9. DIGITAL SERVO Displaying the servo ID screen 1 Press the SYSTEM function key, then press the [System] soft key. 2 Press the [SV Information] soft key to display the screen as shown below. NOTE Servo information is stored in flash ROM. If there is a difference between the servo inform
Page 7269. DIGITAL SERVO GFKE-0222-EN Additional Information Even if replacement is performed reasonably such as for repairing, this function incorrectly indicates the * mark when it detects the replacement. To clear the * mark, follow the steps below to update the registered data, as described in the editi
Page 727GFKE-0222-EN 9. DIGITAL SERVO Screen operation Mode Key operation Use Viewing Page key Scrolls up or down on a screen–by–screen basis. (*1) Editing Soft key (*2) [INPUT] Replace the selected ID information at the cursor posi- tion with the character string in key–in buffer. [CANCEL] Deletes the char
Page 72810. AC SPINDLE (SERIAL INTERFACE) GFKE-0222-EN 10 AC SPINDLE (SERIAL INTERFACE) This chapter outlines the serial interface and analog interface spindle amplifiers and explains related parameters. 10.1 AC SPINDLE (SERIAL INTERFACE) . . . . . . . . . . . 699 10.1.1Outline of Spindle Control . . . . .
Page 729GFKE-0222-EN 10. AC SPINDLE (SERIAL INTERFACE) 10.1 AC SPINDLE (SERIAL INTERFACE) 10.1.1 Outline of Spindle Control 699
Page 73010. AC SPINDLE (SERIAL INTERFACE) GFKE-0222-EN S instruction M instruction NC PMC M03,M04,M05,M19 FIN *SSTP(Spindle stop) Motor speed SOVx( Spindle override) SF,GR1O,GR2O,GR3O (For machining center) GR1,GR2 (For lathe) S SOR( Orientation) (PRM 3735 to 3752) 0 1 R010 to R120 Orientation speed (PRM 37
Page 731GFKE-0222-EN 10. AC SPINDLE (SERIAL INTERFACE) 10.1.1.1 Method A of gear change Output Motor speed for machining center 4095 Max Gear 2 PRM 3736 Gear 3 Gear 1 PRM 3735 0 0 PRM 3741 PRM 3742 PRM 3743 S code (min–1) 10.1.1.2 Method B of gear change Output Motor speed for machining 4095 Max center (PRM
Page 73210. AC SPINDLE (SERIAL INTERFACE) GFKE-0222-EN 10.1.2 Spindle Setting and Tuning Screen 10.1.2.1 Display method (1) Confirm the parameters #7 #6 #5 #4 #3 #2 #1 #0 3111 SPS Bit1 (SPS) 0 : The spindle tuning screen is not displayed. l 1 : The spindle tuning screen is displayed. (2) Press the SYSTEM ke
Page 733GFKE-0222-EN 10. AC SPINDLE (SERIAL INTERFACE) D Spindle Select a spindle for which data is to be set. S11: Main spindle amplifier for the 1st spindle S12: Subspindle amplifier for the 1st spindle S21: Main spindle amplifier for the 2nd spindle S22: Subspindle amplifier for the 2nd spindle D Paramet
Page 73410. AC SPINDLE (SERIAL INTERFACE) GFKE-0222-EN D Displayed parameters The displayed parameters vary depending on the operation mode. Spindle position- Normal Orientation Synchronization Rigid tapping Cs contour ing control operation control control Proportional gain Proportional gain Proportional ga
Page 735GFKE-0222-EN 10. AC SPINDLE (SERIAL INTERFACE) 10.1.2.4 Spindle monitor screen SPINDLE MONITOR SCREEN ALARM : AL–27(POSITION CODER DIS.) OPERATION : Cs AXIS OONTROL SPINDLE SPEED : 100 DEG/MIN MOTOR SPEED : 150 RPM 0 50 100 150 200 LOAD METER (%) JJJJJ CONTROL INPUT : ORCM MRDY *ESP CONTROL OUTPUT :
Page 73610. AC SPINDLE (SERIAL INTERFACE) GFKE-0222-EN D Operation Following 6 modes are available: a. Normal operation b. Orientation c. Synchronous operation d. Rigid tapping e. Cs contour cotrol f. Spindle positioning control D Load meter The load meter displays spindle load in a unit of 10%. 1) Load met
Page 737GFKE-0222-EN 10. AC SPINDLE (SERIAL INTERFACE) 10.1.2.5 Correspondence between operation mode and parameters on spindle tuning screen D Normal operation mode S11: S12: S21: S22: 1st Main 1st Sub 2nd Main 2nd Sub Proportional gain(HIGH) 4040 4206 4040 4206 Proportional gain (LOW) 4041 4207 4041 4207
Page 73810. AC SPINDLE (SERIAL INTERFACE) GFKE-0222-EN D Synchronization control Numerals are parameter numbers : mode S11: S12: S21: S22: 1st Main 1st Sub 2nd Main 2nd Sub Proportional gain(HIGH) 4044 4210 4044 4210 Proportional gain(LOW) 4045 4211 4045 4211 Integral gain(HIGH) 4052 4052 4214 4214 Integral
Page 739GFKE-0222-EN 10. AC SPINDLE (SERIAL INTERFACE) D Spindle contouring Numerals are parameter numbers : control mode (Cs axis control) S11: S12: S21: S22: 1st Main 1st Sub 2nd Main 2nd Sub Proportional gain(HIGH) 4046 4046 Proportional gain (LOW) 4047 4047 Integral gain(HIGH) 4054 4054 Integral gain(LO
Page 74010. AC SPINDLE (SERIAL INTERFACE) GFKE-0222-EN 10.1.3 The standard parameters related to each motor model can be set Automatic Setting of automatically. Standard Parameters D The specifications for controlling a motor depend on the specifications defined by the machine tool builder. The parameters d
Page 741GFKE-0222-EN 10. AC SPINDLE (SERIAL INTERFACE) 10.1.4 Warning Interface for the αi Spindle Overview For the αi spindle, the warning state can be reported before an alarm is issued. When the warning state is entered, a report to the PMC is sent. For example, this signal can be used for retracting too
Page 74210. AC SPINDLE (SERIAL INTERFACE) GFKE-0222-EN Warning Contents Details number 58 Converter main If the main circuit of the PSM is overloaded, the warn- circuit overloaded ing signal is output. Since the spindle continues to operate at this time, use the PMC to perform proces- sing as needed. About
Page 743GFKE-0222-EN 10. AC SPINDLE (SERIAL INTERFACE) 10.1.5 αi Spindle Information Screen General In the αi spindle system, ID information output from each of the connected units is obtained and output to the CNC screen. The units that have ID information are shown below. (Remark: Some instances of these
Page 74410. AC SPINDLE (SERIAL INTERFACE) GFKE-0222-EN Displaying the spindle information screen 1 Press the SYSTEM function key, then press the [SYSTEM] soft key. 2 Press the [SP–INF] soft key to display the screen as shown below. NOTE Spindle information is stored in flash ROM. If there is a difference be
Page 745GFKE-0222-EN 10. AC SPINDLE (SERIAL INTERFACE) Additional Information Even if replacement is performed reasonably such as for repairing, this function incorrectly indicates the * mark when it detects the replacement. To clear the * mark, follow the steps below to update the registered data, as descr
Page 74610. AC SPINDLE (SERIAL INTERFACE) GFKE-0222-EN Screen operation on the editing screen Mode Key operation Use Viewing Page key Scrolls up or down on a screen–by–screen basis. (*1) Editing Soft key (*2) [INPUT] Replace the selected ID information at the cursor posi- tion with the character string in k
Page 747GFKE-0222-EN 10. AC SPINDLE (SERIAL INTERFACE) 10.2 AC SPINDLE (ANALOG INTERFACE) 10.2.1 Outline of Spindle Control 717
Page 74810. AC SPINDLE (SERIAL INTERFACE) GFKE-0222-EN 10.2.1.1 Block diagram S command M command PMC NC M03 to M05, M06, M19 CW/CCW command, Spindle speed orientation, etc. conversion FIN Miscellaneous function end Motor speed *SSTP Gear 1 Gear 2 Spindle stop GR1O, GR2O, GR3O Gear selection (16M/18M) GR1,
Page 749GFKE-0222-EN 10. AC SPINDLE (SERIAL INTERFACE) 10.2.1.2 Calculation of S analog voltage and related parameters [M series] 1 Gear change method A (bit 2 of parameter 3705 = 0) SVC Motor speed Gear 1 Gear 2 Gear 3 (4095) 10V Max PRM 3736 PRM 3735 0V S code 0 PRM 3741 PRM 3742 PRM 3743 (min–1) 2 Gear c
Page 75010. AC SPINDLE (SERIAL INTERFACE) GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 3706 TCW CWM TCW CWM Sign of output voltage 0 0 Analog voltage (+) with both M03 and M04 0 1 Analog voltage (–) with both M03 and M04 1 0 (+) with M03, (–) with M04 1 1 (–) with M03, (+) with M04 [M series] #7 #6 #5 #4 #3 #2 #1 #
Page 751GFKE-0222-EN 10. AC SPINDLE (SERIAL INTERFACE) 10.2.1.3 Tuning S analog voltage (D/A converter) (1) For M series, change the upper and lower limits as follows: ⋅ When gear change method A is used: Parameter 3736 = 4095, parameter 3735 = 0 ⋅ When gear change method B is used: Parameter 3751 = 4095, p
Page 75210. AC SPINDLE (SERIAL INTERFACE) GFKE-0222-EN (4) If the output voltage is not correct, perform the following calculation, and change the value of parameter 3730 to adjust the gain of the D/A converter: Setting + 10V (Current value of PRM 3730) Measured voltage (5) Execute an S command again and co
Page 753GFKE-0222-EN 11.TROUBLESHOOTING 11 TROUBLESHOOTING This chapter describes troubleshooting procedure. 11.1 CORRECTIVE ACTION FOR FAILURES . . . . . . 725 11.2 NO MANUAL OPERATION NOR AUTOMATIC OPERATION CAN BE EXECUTED . . . . . . . . . . . 727 11.3 JOG OPERATION CANNOT BE DONE . . . . . . . . 731 11
Page 75411. TROUBLESHOOTING GFKE-0222-EN 11.25 ALARM 5136 (FSSB: NUMBER OF AMPS IS SMALL) . . . . . . . 791 11.26 ALARM 900 (ROM PARITY) . . . . . . . . . . . . . . . . . 794 11.27 ALARMS 910 AND 911 (SRAM PARITY) . . . . . . 796 11.28 ALARMS 912 TO 919 (DRAM PARITY) . . . . . . . 799 11.29 ALARMS 920 AND 9
Page 755GFKE-0222-EN 11.TROUBLESHOOTING 11.1 When a failure occurs, it is important to correctly grasp what kind of failure occured and take appropriate action, to promptly recover the CORRECTIVE machine. ACTION FOR Check for the failure according to the following procedure : FAILURES When? With what What f
Page 75611. TROUBLESHOOTING GFKE-0222-EN ⋅ For a failure related to spindles When did the failure occur ? (during power–on, acceleration, deceleration, or constant rotation) 3 What failure occurred ? ⋅ Which alarm was displayed on the alarm display screen? (Check the axis along which an alarm has occurred f
Page 757GFKE-0222-EN 11.TROUBLESHOOTING 11.2 NO MANUAL OPERA- TION NOR AUTOMAT- IC OPERATION CAN BE EXECUTED Points (1) Execute the following procedure when no manual nor automatic operation is done (2) Check whether position display shows correct position (3) Check CNC status display (4) Check CNC internal
Page 75811. TROUBLESHOOTING GFKE-0222-EN (c) Confirm the status of modes Operation mode status is displayed on the lower part of CRT as follows : If nothing is displayed, mode select signal is not input. Check mode select signal using PMC’s diagnostic function (PMCDGN). For details, refer to section 1.9 CNC
Page 759GFKE-0222-EN 11.TROUBLESHOOTING a. In–position check is It shows that positioning is not yet completed. Check the contents of the being done following diagnostic number. (It is 1 in the following condition) DGN 0300 Position Error >PARAM 1826 In–position width 1) Check the parameters according to th
Page 76011. TROUBLESHOOTING GFKE-0222-EN c. Jog feedrate override is Check the signals using PMC’s diagnostic function (PMCDGN) 0% #7 #6 #5 #4 #3 #2 #1 #0 QG0081+ *JV7 *JV6 *JV5 *JV4 *JV3 *JV2 *JV1 *JV0 QG0089+ *JV15 *JV14 *JV13 *JV12 *JV11 *JV10 *JV9 *JV8 When the override is 0% all bits of the above addre
Page 761GFKE-0222-EN 11.TROUBLESHOOTING 11.3 JOG OPERATION CANNOT BE DONE Points (1) Check whether position display is operating. (2) Check CNC status display. (3) Check internal status using Diagnostic funciton. Causes and Remedies 1. Position display (1) Check mode selection status (JOG mode is not select
Page 76211. TROUBLESHOOTING GFKE-0222-EN * By defining a straight line or arc in the CNC beforehand using the R area of the PMC, +Jg and "Ja allow the tool to move along both X– and Y–axes simultaneously. The exchange of information with the R area of the PMC is performed by the macro software or PMC sequen
Page 763GFKE-0222-EN 11.TROUBLESHOOTING a. In–position check is It shows that positioning is not yet completed. Check the contents of the being done following diagnostic number. (It is 1 in the following condition) DGN 0300 Position Error >PARAM 1826 In–positio width 1) Check the parameters according to the
Page 76411. TROUBLESHOOTING GFKE-0222-EN c. Jog feedrate override is Check the signals using PMC’s diagnostic function (PMCDGN) 0% #7 #6 #5 #4 #3 #2 #1 #0 QG0081+ *JV7 *JV6 *JV5 *JV4 *JV3 *JV2 *JV1 *JV0 QG0089+ *JV15 *JV14 *JV13 *JV12 *JV11 *JV10 *JV9 *JV8 When the override is 0% all bits of the above addre
Page 765GFKE-0222-EN 11.TROUBLESHOOTING 11.4 HANDLE OPERATION CANNOT BE DONE Causes and actions If manual handle operation cannot be performed, the probable causes include the following: D The servo is not activated. D Manual pulse generators are not connected properly to the I/O module. D The I/O link of t
Page 76611. TROUBLESHOOTING GFKE-0222-EN (2) Manual pulse generator failures When rotated, a manual pulse generator generates the signals shown below. Using an oscilloscope, measure the signals from the screw terminal block located at the rear of a manual pulse generator. If no signals are output, measure t
Page 767GFKE-0222-EN 11.TROUBLESHOOTING I/O module for connec- Group 0 Control unit tor panel This manual pulse Allocated to generator I/F is use a manual effective. pulse generator Operator’s panel I/O module Group 1 Allocated to use a manual This manual pulse pulse generator generator I/F is not effective
Page 76811. TROUBLESHOOTING GFKE-0222-EN 4 Checking the parameters (1) Check CNC status display at lower left corner of the CRT. and input signals (See Section 1.9.) When the status display shows HND, mode selection is correct. If it is not HND, mode select signal is not input correctly. Check the mode sele
Page 769GFKE-0222-EN 11.TROUBLESHOOTING (3) Manual handle feed multiplication is not correct Check the following signals using PMC’s PCDGN. Also confirm the following parameters based on the parameter list. #7 #6 #5 #4 #3 #2 #1 #0 QG0153+ MP2 MP1 In handle mode, the travel distance per step can be changed.
Page 77011. TROUBLESHOOTING GFKE-0222-EN 11.5 AUTOMATIC OPERATION CANNOT BE DONE Points (1) Check manual operation is possible. (2) Check the status of cycle start LED on machine operator’s manual. (3) Check status of CNC. Causes and Remedies When manual operation is either impossible, perform countermeasur
Page 771GFKE-0222-EN 11.TROUBLESHOOTING 2. When an automatic CNC’s status display shows “STRT” on the CRT. operation is in progress (1) Check the contents of diagnostic nos. 000 to 015. (Cycle start LED is lit) No. Message Display a. 000 WAITING FOR FIN SIGNAL : 1(Example) b. 001 MOTION :0 c. 002 DWELL :0 d
Page 77211. TROUBLESHOOTING GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 QG0041+ BFIN TFIN SFIN MFIN #0(MFIN) : M function finish signal #2(SFIN) : S function finish signal #3(TFIN) : T function finish signal #4(BFIN) : 2nd auxiliary function finish signal #7 #6 #5 #4 #3 #2 #1 #0 IF0057+ BF TF SF MF #0(M
Page 773GFKE-0222-EN 11.TROUBLESHOOTING Signal End state Finish signal 0 1 store signal 0 1 b. Travel command is being CNC is reading an axis command (X,Y,Z,...) in a program and giving the executed command to the axis. c. A dwell command is CNC is reading a dwell command (G04) in a program and is executing
Page 77411. TROUBLESHOOTING GFKE-0222-EN f. Interlock signal or start lock signal is input Start lock signal is input #7 #6 #5 #4 #3 #2 #1 #0 QG0057+ STLK #1 (STLK) With this signal being 1, start lock signal is input. There are a plural number of interlock
Page 775GFKE-0222-EN 11.TROUBLESHOOTING #7 #6 #5 #4 #3 #2 #1 #0 IF0881+ MDTCH8 MDTCH7 MDTCH6 MDTCH5 MDTCH4 MDTCH3 MDTCH2 MDTCH1 When signal MDTHn is “1”, the axis detach function is in valid. The control axis detach function becomes valid by the following signal issued from the PMC or a CNC side parameter.
Page 77611. TROUBLESHOOTING GFKE-0222-EN When override value is 0%, all bits of the above address is [1111 . . . 1111] or [0000 . . . 0000]. *JV15 . . . . . . . . . . . . . . JV0 Override 1111 1111 1111 1111 0.00% 1111 1111 1111 1110 0.01% : 1101 1000 1110 1111 100.00% : 0000 0000 0000 0001 655.34% 0000 000
Page 777GFKE-0222-EN 11.TROUBLESHOOTING (c) Thread cutting does not operate 1) Position coder does not rotate Check the connection between spindle and position coder The following failure is considered: ⋅ Timing belt is broken ⋅ Key is removed ⋅ Coupling is loose ⋅ Connector of signal cable is loosened 2) P
Page 77811. TROUBLESHOOTING GFKE-0222-EN 11.6 CYCLE START LED SIGNAL HAS TURNED OFF Points (1) After cycle operation is started, then stopped, check as follows: (2) Confirm cycle start LED on machine operator’s panel. (3) Confirm CNC’s diagnostic function. Causes and Remedies The reason why cycle start LED
Page 779GFKE-0222-EN 11.TROUBLESHOOTING b. External reset signal is input #7 #6 #5 #4 #3 #2 #1 #0 QG0065+ ERS #7(ERS) : When the bit is 1, external reset signal is input. This signal is usually used for a confirmation signal of M02 when an M02 is specified in a program as the end of a program. Therefore, wh
Page 78011. TROUBLESHOOTING GFKE-0222-EN 11.7 NOTHING IS DISPLAYED ON THE LCD WHEN THE POWER IS TURNED ON Causes and actions If nothing is displayed on the LCD at power–up or if the LCD is locked with “GRAPHIC IS READY.” or the slot status screen displayed, the probable causes include the following: D For t
Page 781GFKE-0222-EN 11.TROUBLESHOOTING D LCD display Referring to the hardware chapter, check the LCD on/off status of the motherboard. If the motherboard has started up normally and the LCD display indicates normal operation, a probable cause is a fault of the display system, such as a cable not connected
Page 78211. TROUBLESHOOTING GFKE-0222-EN [For the stand–alone type] D Power supply of the LCD Check that the power cable is connected to the connector CP1A of the unit LCD unit. Connector for connecting the backlight cable Inverter printed circuit board Connector for connecting the LCD cable LCD control pri
Page 783GFKE-0222-EN 11.TROUBLESHOOTING D Main CPU board If any of the above actions does not solve the problem, replace the main CPU board and the CPU card. D Installation positions of the display control card and the CPU card CPU card Display control card 753
Page 78411. TROUBLESHOOTING GFKE-0222-EN 11.8 THE DISPLAY ON THE LCD UNIT FLASHES Causes and actions This situation can occur only with the stand–alone type. If a break is detected in the optical cable (HSSB) that connects the LCD unit to the main CPU board, the display on the LCD unit flashes. The same sit
Page 785GFKE-0222-EN 11.TROUBLESHOOTING 11.9 INPUT FROM AND OUTPUT TO I/O DEVICES CANNOT BE PERFORMED INPUT/ OUTPUT CANNOT BE PERFORMED PROPERLY Causes and actions If the I/O Link is not established, if the signals from an I/O device cannot be input normally to the CNC, or if the signals from the CNC cannot
Page 78611. TROUBLESHOOTING GFKE-0222-EN D Checking the power Check that the connected I/O devices are connected properly to the power supplies of the I/O supplies and that the voltages are as prescribed. devices Check that the power–on sequence is correct. Time at which an I/O device is to be turned on Bef
Page 787GFKE-0222-EN 11.TROUBLESHOOTING 11.10 IN A CONNECTOR PANEL I/O UNIT, DATA IS INPUT TO AN UNEXPECTED ADDRESS If data is input to an invalid address in a connector panel I/O unit (for example, data that should be input to I0033+ is actually input to I0081+ in a connector panel I/O unit), the most like
Page 78811. TROUBLESHOOTING GFKE-0222-EN 11.11 The most likely cause is that power is not being supplied to the expansion unit. IN A CONNECTOR → Check whether 24–V power is supplied to 18P and 50P of the PANEL I/O UNIT, NO expansion unit, DI and DO signals are not input and output. DATA IS OUTPUT TO → Check
Page 789GFKE-0222-EN 11.TROUBLESHOOTING 11.12 ALARM 85 TO 87 (READER/PUNCHER (START) INTERFACE ALARM) YES Alarm 85? NO · Check baud rate and other I/O pa rameters YES · I/O device is Alarm 86? faulty NO Is I/O NO parameter correct? YES Set correct parameters OFF Is power of I/O ? ON Turn on I/O device Is ca
Page 79011. TROUBLESHOOTING GFKE-0222-EN Value of parame- ter 0020 0 1 2 3 Function Feed 0101#7 0111#7 0121#7 0131#7 Data input code 0101#3 0111#3 0121#3 0131#3 Stop bit 0101#0 0111#0 0121#0 0131#0 Type of I/O device 102 112 122 132 Baud rate 103 113 123 133 Commu- 0135#3 – – – 0 1 nication meth
Page 791GFKE-0222-EN 11.TROUBLESHOOTING 0102 Type of I/O device 0112 0122 Value TYPE OF I/O DEVICE 0132 0 RS–232–C (if the following units are not used) 1 FANUC CASSETTE B1/B2 (bubble cassette) 2 FANUC CASSETTE F1 (Old type FLOPPY CASSETTE ADAP- TOR) 3 FANUC PROGRAM FILE Mate, FANUC FA CARD ADAPTOR FANUC FL
Page 79211. TROUBLESHOOTING GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 0135 RMS R42 PRA ETX ASC #7(RMS) In protocol A, status of remote / tape operation of SAT command is 0 : Always transmitted by 0. 1 : Transmitted by the contents of remote / tape switching request issued by SET command from the CNC. #3(R42) 0 :
Page 793GFKE-0222-EN 11.TROUBLESHOOTING < Cable connection> R232C (JD36A) (JD36B) (JD5L) Punch panel RD (01) (03) RD 0V (02) DR (03) (06) DR 0V (04) CS (05) (05) CS 0V (06) CD (07) (08) CD 0V (08) (09) +24V (10) SD (11) (02) SD 0V (12) ER (13) (20) ER 0V (14) RS (15) (04) RS 0V (16) (07) SG (17) (18) +24V (
Page 79411. TROUBLESHOOTING GFKE-0222-EN CAUTION 1 When CS is not used, connect it to RS. 2 For protocol A or extended protocol A: When DR is not used, connect it to ER. Always connect CD to ER. RS422 (JD6A) (JD6L) Host computer RD (01) (04) RD *RD (02) (22) *RD RT (03) (17) TT *RT (04) (35) *TT CS (05) (07
Page 795GFKE-0222-EN 11.TROUBLESHOOTING 11.13 ALARM 90 (REFERENCE POSITION RETURN IS ABNORMAL) Contents Reference position return was executed when the following condition is not satisfied: The CNC received one rotation signal at least one time when the axis is moving to the reference position at a speed hi
Page 79611. TROUBLESHOOTING GFKE-0222-EN (1) Check whether the motor ratated more than one rota- tion (one rotation signal is issued ) at faster than 128 pulses of position error amount. NO Return start position is too close Rotated ? · Chagne the return start position. YES · Move the machine at faster that
Page 797GFKE-0222-EN 11.TROUBLESHOOTING 11.14 Absolute position data in the serial pulse coder was lost. (This alarm will be generated when serial pulse coder is exchanged or ALARM 300 position feedback signal cable of the serial pulse coder is disconnected). (REQUEST FOR REFERENCE POSITION RETURN) Remedies
Page 79811. TROUBLESHOOTING GFKE-0222-EN 11.15 ALARM 401 (V READY OFF) Causes and actions This alarm is issued if the servo ready signal (VRDY) of a servo amplifier does not turn on or if the signal turns off during operation. There are cases in which this alarm is issued because another servo alarm is issu
Page 799GFKE-0222-EN 11.TROUBLESHOOTING D Example of connection around the amplifier (Typical example) (servo (servo amplifier) amplifier) Control power supply Emergency stop circuit Serial spindle Servo Servo Spindle motor motor motor 3–phase Breaker AC reactor Single– phase Breaker Check items D Is the PS
Page 80011. TROUBLESHOOTING GFKE-0222-EN D Installation positions of the axis control cards [For the LCD–mounted type] Axis control card Motherboard Axis control card Sub–CPU board Axis control card Loader control board 770
Page 801GFKE-0222-EN 11.TROUBLESHOOTING [For the stand–alone type] Axis control card Axis control card Main CPU board Sub CPU board Axis control card Loarder control board 771
Page 80211. TROUBLESHOOTING GFKE-0222-EN 11.16 ALARM 404 (V READY ON) Causes and actions This alarm is issued if the servo ready signal (VRDY) of a servo amplifier remains on. The servo amplifier or the axis control cards on the CNC may be defective. D VRDY CNC Servo amplifier (main CPU board) MCON: From th
Page 803GFKE-0222-EN 11.TROUBLESHOOTING D Installation positions of the axis control cards [For the LCD–mounted type] Axis control card Motherboard Axis control card Sub–CPU board Axis control card Loader control board 773
Page 80411. TROUBLESHOOTING GFKE-0222-EN [For the stand–alone type] Axis control card Axis control card Main CPU board Sub CPU board Axis control card Loarder control board 774
Page 805GFKE-0222-EN 11.TROUBLESHOOTING 11.17 ALARM 462 (SEND CNC DATA FAILED) ALARM 463 (SEND SLAVE DATA FAILED) Causes and actions Alarm 462 is issued if a slave (servo amplifier) cannot receive correct data due to an FSSB communication error. Alarm 463 is issued if the CNC cannot receive correct data due
Page 80611. TROUBLESHOOTING GFKE-0222-EN D Installation positions of the axis control cards [For the LCD–mounted type] Axis control card Motherboard Axis control card Sub–CPU board Axis control card Loader control board 776
Page 807GFKE-0222-EN 11.TROUBLESHOOTING [For the stand–alone type] Axis control card Axis control card Main CPU board Sub CPU board Axis control card Loarder control board 777
Page 80811. TROUBLESHOOTING GFKE-0222-EN 11.18 Digital servo parameters are abnormal. (Digital servo parameters are set incorrectly.) ALARM 417 (DIGITAL SERVO SYSTEM IS ABNORMAL) D Causes 1 Confirm the setting value of the following parameters: PRM 2020 : Motor format number PRM 2022 : Motor rotation direct
Page 809GFKE-0222-EN 11.TROUBLESHOOTING 11.19 ALARM 700 (OVERHEAT: CONTROL UNIT) Causes and actions This alarm is issued if the ambient temperature of the CNC control unit is abnormally high. As an installation condition, the ambient temperature of the CNC must not exceed 58°C (for LCD–mounted type CNC) or
Page 81011. TROUBLESHOOTING GFKE-0222-EN 11.20 ALARM 701 (OVERHEAT: FAN MOTOR) Causes and actions This alarm is issued if a fault occurs in any of the fan motors, such as the stoppage of a fan motor during the operation of the CNC. D Fan motors Fan motors are installed in the uppermost portion of the CNC co
Page 811GFKE-0222-EN 11.TROUBLESHOOTING [For the stand–alone type] For the stand–alone type, a fan can be replaced together with its case. Fan motor for Fan motor for 2–slot track 1–slot track Specifications of fan motors Ordering information For 1–slot track A02B–0265–C101 For 2–slot track A02B–0260–C021 7
Page 81211. TROUBLESHOOTING GFKE-0222-EN 11.21 Spindle speed changes abnormally due to load. ALARM 704 (SPINDLE SPEED FLUCTUATION DETECTION ALARM) Remedies Check whether spindle speed is constant by view of the speed meter on CRT. YES Constant ? NO Is a heavy cutting being per- formed ? Confirm spindle load
Page 813GFKE-0222-EN 11.TROUBLESHOOTING 11.22 ALARM 749 (SERIAL SPINDLE COMMUNICATION ERROR) Causes and actions An error occurred in the communication between the serial spindle amplifier (SPM) and the CNC. The probable causes include: D Contact failure of the connection cable D Defective printed circuit bo
Page 81411. TROUBLESHOOTING GFKE-0222-EN 11.23 ALARM 750 (SPINDLE SERIAL LINK STARTUP FAILURE) Causes and actions This alarm is issued if a serial spindle amplifier (SPM) does not enter the normal startup state when the CNC is turned on. This alarm is not issued once the CNC system including the spindle amp
Page 815GFKE-0222-EN 11.TROUBLESHOOTING [Diagram of connection of three or four amplifiers per path] Motherboard (Main CPU board) Sub–CPU board Connector panel SPM (first) JA41 JA48 JA7A–1 JA7B JA7A–2 JA7A SPM (second) JA7B JA7A SPM (third) JA7B JA7A SPM (fourth) JA7B JA7A Check that the cables are connecte
Page 81611. TROUBLESHOOTING GFKE-0222-EN S2E: 0 : The second spindle is normal during the spindle serial control startup. 1 : The second spindle was detected to have a fault during the spindle serial control startup. S1E: 0 : The first spindle is normal during the spindle serial control startup. 1 : The fir
Page 817GFKE-0222-EN 11.TROUBLESHOOTING 11.24 ALARM 5134 (FSSB: OPEN READY TIME OUT) ALARM 5135 (FSSB: ERROR MODE) ALARM 5137 (FSSB: CONFIGURATION ERROR) ALARM 5197 (FSSB: OPEN TIME OUT) ALARM 5198 (FSSB: ID DATA NOT READ) Causes and actions These alarms are issued if any of the axis control cards and the s
Page 81811. TROUBLESHOOTING GFKE-0222-EN If the FSSB does not become ready to open in 4, alarm 5134 is issued. If an error is detected in 5, alarm 5137 is issued. If the FSSB does not open within a fixed period of time, alarm 5197 is issued. If the ready signal is not returned within a fixed period of time,
Page 819GFKE-0222-EN 11.TROUBLESHOOTING D Installation positions of the axis control cards [For the LCD–mounted type] Axis control card Motherboard Axis control card Sub–CPU board Axis control card Loader control board 789
Page 82011. TROUBLESHOOTING GFKE-0222-EN [For the stand–alone type] Axis control card Axis control card Main CPU board Sub CPU board Axis control card Loarder control board 790
Page 821GFKE-0222-EN 11.TROUBLESHOOTING 11.25 ALARM 5136 (FSSB: NUMBER OF AMPS IS SMALL) Causes and actions The number of servo amplifiers recognized by the FSSB is insufficient, compared with the number of controlled axes. D FSSB setting screen If this alarm is issued, display the amplifier setting screen
Page 82211. TROUBLESHOOTING GFKE-0222-EN D Installation positions of the axis control cards [For the LCD–mounted type] Axis control card Motherboard Axis control card Sub–CPU board Axis control card Loader control board 792
Page 823GFKE-0222-EN 11.TROUBLESHOOTING [For the stand–alone type] Axis control card Axis control card Main CPU board Sub CPU board Axis control card Loarder control board 793
Page 82411. TROUBLESHOOTING GFKE-0222-EN 11.26 ALARM 900 (ROM PARITY) Causes and actions A ROM parity error occurred. The software including the CNC system software, servo software, PMC management software, and PMC Ladder is stored in the flash memory on the FROM/SRAM module. It starts execution after being
Page 825GFKE-0222-EN 11.TROUBLESHOOTING [For the stand–alone type] FROM/SRAM module The FROM/SRAM module is installed under the axis control card. Main CPU board 795
Page 82611. TROUBLESHOOTING GFKE-0222-EN 11.27 ALARMS 910 AND 911 (SRAM PARITY) Causes and actions A parity error occurred in the SRAM used to store data such as parameters and machining programs. This alarm is issued if the battery has run down or if the data in the SRAM is destroyed due to some external c
Page 827GFKE-0222-EN 11.TROUBLESHOOTING D Installation position of the FROM/SRAM module [For the LCD–mounted type] FROM/SRAM module [For the stand–alone type] FROM/SRAM module The FROM/SRAM module is installed under the axis control card. Main CPU board 797
Page 82811. TROUBLESHOOTING GFKE-0222-EN D SRAM parity on the If alarm 972 is issued, indicating on the screen that an SRAM parity error loader control board or occurred on the loader or Symbol CAPi T, take appropriate action on the Symbol CAPi T board loader control board or Symbol CAPi T board. The SRAM f
Page 829GFKE-0222-EN 11.TROUBLESHOOTING 11.28 ALARMS 912 TO 919 (DRAM PARITY) Causes and actions The management software for the CNC is loaded from the FROM to the DRAM at power on, so that it is executed on the DRAM. A parity error occurred on this DRAM. These alarms occur if the data on the DRAM is destro
Page 83011. TROUBLESHOOTING GFKE-0222-EN [For the stand–alone type] CPU card Main CPU board D DRAM parity on an If alarm 972 is issued, indicating on the screen that a DRAM parity error option board occurred on an option board, take appropriate action on the option board on which the DRAM parity error occur
Page 831GFKE-0222-EN 11.TROUBLESHOOTING 11.29 ALARMS 920 AND 921 (SERVO ALARMS) Causes and actions A watchdog error or RAM parity error occurred in the circuit on an axis control card. Alarm 920 indicates that either of the above errors occurred in the control circuit for axes 1 to 4. Alarm 921 indicates th
Page 83211. TROUBLESHOOTING GFKE-0222-EN [For the stand–alone type] CPU card Axis control card Main CPU board 802
Page 833GFKE-0222-EN 11.TROUBLESHOOTING D Servo alarm on the If alarm 972 is issued, indicating on the screen that a servo alarm occurred sub–CPU board or loader on the sub–CPU or loader, take appropriate action on the sub–CPU board control board or loader control board. Screen display example SYSTEM ALARM
Page 83411. TROUBLESHOOTING GFKE-0222-EN [For the stand–alone type] CPU card CPU card Axis control card Axis control card Sub CPU board Loarder control board 804
Page 835GFKE-0222-EN 11.TROUBLESHOOTING 11.30 ALARM 926 (FSSB ALARM) Causes and actions A fault occurred on the FSSB (serial servo bus) that connects servo amplifiers to the CNC. This alarm is issued if a fault occurs in any of the axis control cards making up the FSSB, optical cables, and servo amplifiers.
Page 83611. TROUBLESHOOTING GFKE-0222-EN D Identifying the defective Use the display on the CNC screen location If alarm 926 is issued, information such as the following is displayed at the bottom of the CNC screen. It can be used to identify the defective location. MODE STATUS information information Bits
Page 837GFKE-0222-EN 11.TROUBLESHOOTING If the pattern of the STATUS information is A (1) The optical cable that connects together the slave corresponding to bits 12 to 15 of the MODE information and the preceding slave may be defective. Or, either of the slaves connected together with that optical cable ma
Page 83811. TROUBLESHOOTING GFKE-0222-EN D Installation position of the axis control card [For the LCD–mounted type] Axis control card Motherboard [For the stand–alone type] Axis control card Main CPU board 808
Page 839GFKE-0222-EN 11.TROUBLESHOOTING D FSSB alarm on the If alarm 972 is issued, indicating on the screen that an FSSB alarm sub–CPU board or loader occurred on the sub–CPU or loader, take appropriate action on the control board sub–CPU board or loader control board. Screen display example SYSTEM ALARM 9
Page 84011. TROUBLESHOOTING GFKE-0222-EN [For the stand–alone type] Axis control card Axis control card Sub CPU board Loarder control board 810
Page 841GFKE-0222-EN 11.TROUBLESHOOTING 11.31 ALARM 930 (CPU INTERRUPT) Causes and actions An interrupt that can never be generated during normal operation was generated. The cause of the fault cannot be identified, but the fault may have occurred in the peripheral circuit of the CPU. If the problem is solv
Page 84211. TROUBLESHOOTING GFKE-0222-EN [For the stand–alone type] CPU card Main CPU board D Examining the noise See the section on the measures against noise, examine the noise environment environment of the CNC. D CPU interrupt on an If alarm 972 is issued, indicating on the screen that a CPU interrupt w
Page 843GFKE-0222-EN 11.TROUBLESHOOTING 11.32 ALARM 935 (SRAM ECC ERROR) Causes and actions An ECC error occurred in the SRAM used to store data such as parameters and machining programs. This alarm is issued if the battery has run down or if the data in the SRAM is destroyed due to some external cause. Or,
Page 84411. TROUBLESHOOTING GFKE-0222-EN D Installation position of the FROM/SRAM module [For the LCD–mounted type] FROM/SRAM module [For the stand–alone type] FROM/SRAM module The FROM/SRAM module is installed under the axis control card. Main CPU board 814
Page 845GFKE-0222-EN 11.TROUBLESHOOTING 11.33 ALARM 950 (PMC SYSTEM ALARM) Causes and actions This alarm is issued if a fault is detected in the PMC. The probable causes include an I/O link communication error and a defective PMC control circuit D Connecting the I/O Link The I/O Link is a serial interface t
Page 84611. TROUBLESHOOTING GFKE-0222-EN 1) If bit 0 of the binary representation of xx is “1”, this indicates that the master station (CNC) received invalid communication data. For example, assume that the following is displayed on the screen: SYSTEM ALARM 950 PMC SYSTEM ALARM PC050 IOLINK CH1 aabb–4142:aa
Page 847GFKE-0222-EN 11.TROUBLESHOOTING In this case, check the following: (1) If bit 5 of yy is “1” Perform examination with the same procedure as that in 1). (2) If bit 6 of yy is “1” or if bit 7 of yy is “1” First, replace the device of the slave station of the indicated group number. If the problem is n
Page 84811. TROUBLESHOOTING GFKE-0222-EN 11.34 ALARM 951 (PMC WATCHDOG ALARM) Causes and actions This alarm is issued if a fault (watchdog alarm) is detected in the PMC. A probable cause is that the MC control circuit is defective. D Replacing the The PMC control circuit is installed on the motherboard. Rep
Page 849GFKE-0222-EN 11.TROUBLESHOOTING 11.35 ALARM 972 (NMI ALARM ON AN OPTION BOARD) Causes and actions This alarm indicates that an error was detected on an option board, not on the main CPU board. D Screen display If alarm 972 is issued, the following is displayed on the screen: Screen display example S
Page 85011. TROUBLESHOOTING GFKE-0222-EN 11.36 ALARM 973 (NMI ALARM WITH AN UNKNOWN CAUSE) Causes and actions An error that can never occur during normal operation occurred. The cause of the error cannot be identified. D Replacing printed circuit Replace all the printed circuit boards installed (including c
Page 851GFKE-0222-EN 11.TROUBLESHOOTING 11.37 ALARM 974 (F–BUS ERROR) Causes and actions A bus error occurred on the FANUC–BUS connecting each option board. This alarm indicates that a fault occurred during the exchange of data between the main CPU and an option board. D Replacing the CPU card Replace the C
Page 85211. TROUBLESHOOTING GFKE-0222-EN D Installation position of the CPU card [For the LCD–mounted type] CPU card Motherboard [For the stand–alone type] CPU card Main CPU board 822
Page 853GFKE-0222-EN 11.TROUBLESHOOTING D F–BUS error on an If alarm 972 is issued, indicating on the screen that an F–BUS error option board occurred on an option board, replace the CPU card on the option board on which the F–BUS error occurred or the option board itself. Some option boards have a circuit
Page 85411. TROUBLESHOOTING GFKE-0222-EN 11.38 ALARM 975 (BUS ERROR) Causes and actions A bus error occurred on the motherboard. This alarm indicates that an error occurred during the exchange of data within the motherboard. D Replacing the CPU card Replace the CPU card on the motherboard. D Replacing other
Page 855GFKE-0222-EN 11.TROUBLESHOOTING 11.39 ALARM 976 (LOCAL BUS ERROR) Causes and actions A bus error occurred on the local bus on the motherboard. This alarm indicates that an error occurred during the exchange of data within the motherboard. D Replacing the CPU card Replace the CPU card on the motherbo
Page 85611. TROUBLESHOOTING GFKE-0222-EN 11.40 For an explanation of the following servo alarms, refer to the FANUC SERVO MOTOR αi series Maintenance Manual (B–65285EN) or SERVO ALARMS FANUC SERVO MOTOR α series Maintenance Manual (B–65165E). Number Message Contents 417 SERVO ALARM: n–TH AXIS – PA- This ala
Page 857GFKE-0222-EN 11.TROUBLESHOOTING Number Message Contents 439 n AXIS : CNV. OVERVOLT POWER 1) PSM: The DC link voltage is too high. 2) PSMR: The DC link voltage is too high. 3) α series SVU: The C link voltage is too high. 4) β series SVU: The link voltage is too high. 440 n AXIS : CNV. EX DECELERATIO
Page 85811. TROUBLESHOOTING GFKE-0222-EN Number Message Contents 460 n AXIS : FSSB DISCONNECT FSSB communication was disconnected suddenly. The possible causes are as follows: 1) The FSSB communication cable was disconnected or broken. 2) The power to the amplifier was turned off suddenly. 3) A low–voltage
Page 859GFKE-0222-EN 11.TROUBLESHOOTING D Installation positions of the axis control cards [For the LCD–mounted type] Axis control card Motherboard Axis control card Sub–CPU board Axis control card Loader control card 829
Page 86011. TROUBLESHOOTING GFKE-0222-EN [For the stand–alone type] Axis control card Axis control card Main CPU board Sub CPU board Axis control card Loarder control board 830
Page 861GFKE-0222-EN 11.TROUBLESHOOTING 11.41 For an explanation of the following SPC alarms (serial pulse coder alarms), refer to the FANUC SERVO MOTOR αi series Maintenance SPC ALARMS Manual (B–65285EN) or FANUC SERVO MOTOR α series Maintenance Manual (B–65165E). Number Message Contents 360 n AXIS: ABNORM
Page 86211. TROUBLESHOOTING GFKE-0222-EN 11.42 For an explanation of the following spindle alarms, refer to the FANUC SERVO MOTOR αi series Maintenance Manual (B–65285EN) or SPINDLE ALARMS FANUC SERVO MOTOR α series Maintenance Manual (B–65165E). Number Contents 7101 to 7199 Spindle 1 alarm (SPM display 01
Page 863APPENDI
Page 864
Page 865GFKE-0222-EN APPENDIX A. ALARM LIST A ALARM LIST A.1 LIST OF ALARM CODES (CNC) . . . . . . . . . . . . . . 836 A.2 LIST OF ALARMS (PMC) . . . . . . . . . . . . . . . . . . . . 875 A.3 ALARM LIST (SERIAL SPINDLE) . . . . . . . . . . . . . 900 A.4 ERROR CODES (SERIAL SPINDLE) . . . . . . . . . . . 912
Page 866A. ALARM LIST APPENDIX GFKE-0222-EN A.1 LIST OF ALARM CODES (CNC) (1) Program errors /Alarms on program and operation (P/S alarm) Number Message Contents 000 PLEASE TURN OFF POWER A parameter which requires the power off was input, turn off power. 001 TH PARITY ALARM TH alarm (A character with incor
Page 867GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 023 ILLEGAL RADIUS COMMAND In circular interpolation by radius designation, negative value was com- (T series) manded for address R. Modify the program. 025 CANNOT COMMAND F0 IN G02/G03 F0 (fast feed) was instructed by F1 –digit column feed
Page 868A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Contents 039 CHF/CNR NOT ALLOWED IN NRC Chamfering or corner R was specified with a start–up, a cancel, or (T series) switching between G41 and G42 in tool nose radius compensation. The program may cause overcutting to occur in chamfering or corner
Page 869GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents MISSING MOVE VALUE IN CHF/CNR In the arbitrary angle chamfering or corner R block, the move distance (M series) is less than chamfer or corner R amount. 055 MISSING MOVE VALUE IN CHF/CNR In chamfering or corner R block, the move distance is
Page 870A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Contents 069 FORMAT ERROR IN G70–G73 The final move command in the blocks specified by P and Q of G70, (T series) G71, G72, and G73 ended with chamfering or corner R. Modify the program. 070 NO PROGRAM SPACE IN MEMORY The memory area is insufficient
Page 871GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 085 COMMUNICATION ERROR When entering data in the memory by using Reader / Puncher interface, an overrun, parity or framing error was generated. The number of bits of input data or setting of baud rate or specification No. of I/O unit is in
Page 872A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Contents 101 PLEASE CLEAR MEMORY The power turned off while rewriting the memory by program edit opera- tion. If this alarm has occurred, press while pressing , and only the program being edited will be deleted. Register the deleted pr
Page 873GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 127 NC, MACRO STATEMENT IN SAME NC and custom macro commands coexist. BLOCK Modify the program. 128 ILLEGAL MACRO SEQUENCE The sequence number specified in the branch command was not 0 to NUMBER 9999. Or, it cannot be searched. Modify the p
Page 874A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Contents 149 FORMAT ERROR IN G10L3 A code other than Q1,Q2,P1 or P2 was specified as the life count type in the extended tool life management. 150 ILLEGAL TOOL GROUP NUMBER Tool Group No. exceeds the maximum allowable value. Modify the program. 151
Page 875GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents IMPROPER G–CODE IN G107 Any of the following G codes which cannot be specified in the cylindrical (M series) interpolation mode was specified. 1) G codes for positioning: G28,, G73, G74, G76, G81 – G89, including the codes specifying the ra
Page 876A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Contents 190 ILLEGAL AXIS SELECT In the constant surface speed control, the axis specification is wrong. (See parameter No. 3770.) The specified axis command (P) contains an illegal value. Correct the program. 194 SPINDLE COMMAND IN A contour contro
Page 877GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 213 ILLEGAL COMMAND IN Movement is commanded for the axis to be synchronously controlled. SYNCHRO–MODE Any of the following alarms occurred in the operation with the simple (M series) synchronization control. 1) The program issued the move
Page 878A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Contents 231 ILLEGAL FORMAT IN G10 OR L50 Any of the following errors occurred in the specified format at the pro- grammable–parameter input. 1 Address N or R was not entered. 2 A number not specified for a parameter was entered. 3 The axis number w
Page 879GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 251 ATC ERROR This alarm is issued in the following cases: (M series) S An M06T_ command contains an unusable T code. S An M06 command has been specified when the Z machine coordi nate is positive. S The parameter for the current tool numbe
Page 880A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Contents 4511 ILLEGAL COMMAND IN In a circular punching (G46, G47) command, the same position was CIRCLE-PUNCH specified for both start and end points of the arc, radius (R) of the arc was set to zero, or the pitch (Q) was set to a value exceeding t
Page 881GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 4543 MULTI-PIECE Q COMMAND Although G98P0 was specified, the Q value for the G74 command was ERROR not 1 or 3. Although G98K0 was specified, the Q value for the G73 command was not 1 or 2. 4544 MULTI-PIECE RESTART ERROR In the command for r
Page 882A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Contents 5011 PARAMETER ZERO(CUT MAX) The maximum cutting feedrate (parameter No. 1422, No. 1430, No. (M series) 1431, No. 1432) is 0 in the HPCC mode. 5012 G05 P10000 ILLEGAL START UP Function category: (HPCC) High–precision contour control (M seri
Page 883GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 5043 TOO MANY G68 NESTING Three–dimensional coordinate conversion G68 has been specified (M series) three or more times. TOO MANY G68 NESTING Three–dimensional coordinate conversion G68.1 has been specified (T series) three or more times. 5
Page 884A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Contents 5060 ILLEGAL PARAMETER IN There is a parameter setting error. G02.3/G03.3 Parameter No. 5641 (setting of the linear axis) is not set. (M series) The axis set in parameter No. 5641 is not a linear axis. Parameter No. 5642 (setting of a rotat
Page 885GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 5085 SMOOTH IPL ERROR 1 A block for specifying smooth interpolation contains a syntax error. 5096 MISMATCH WAITING M–CODE Different wait codes (M codes) were specified in HEAD1 and HEAD2. (M series) Correct the program. 5110 NOT STOP POSITI
Page 886A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Contents 5122 ILLEGAL COMMAND IN SPIRAL A spiral interpolation or conical interpolation command has an error. (M series) Specifically, this error is caused by one of the following: 1) L = 0 is specified. 2) Q = 0 is specified. 3) R/, R/, C is specif
Page 887GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 5195 DIRECTION CAN NOT BE JUDGED When the touch sensor with a single contact signal input is used in the (T series) direct input B function for tool offset measurement values, the stored pulse direction is not constant. One of the following
Page 888A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Contents 5227 FILE NOT FOUND A specified file is not found during communication with the built–in Handy File. 5228 SAME NAME USED There are duplicate file names in the built–in Handy File. 5229 WRITE PROTECTED A floppy disk in the built–in Handy Fil
Page 889GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 5303 TOUCH PANEL ERROR A touch panel error occurred. Cause: 1. The touch panel is kept pressed. 2. The touch panel was pressed when power was turned on. Remove the above causes, and turn on the power again. 5306 MODE CHANGE ERROR In a one–t
Page 890A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Contents 5407 ILLEGAL COMMAND IN G41.3 1) A G code that belongs to group 01 except G00 and G01 is specified (M series) in G41.3 mode. 2) An offset command (a G code belonging to group 07) is specified in G41.3 mode. 3) The block next to G41.3 (start
Page 891GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 5445 CRC:MOTION IN G39 (M series) Corner circular interpolation (G39) of cutter compensation is not speci- fied alone but is specified with a move command. 5446 CRC:NO AVOIDANCE (M series) Because there is no interference evade vector, the
Page 892A. ALARM LIST APPENDIX GFKE-0222-EN (2) Background edit alarm Number Message Contents ??? BP/S alarm BP/S alarm occurs in the same number as the P/S alarm that occurs in ordinary program edit. (070, 071, 072, 073, 074 085,086,087 etc.) 140 BP/S alarm It was attempted to select or delete in the backg
Page 893GFKE-0222-EN APPENDIX A. ALARM LIST (5) Serial pulse coder (SPC) alarms No. Message Description 360 n AXIS : ABNORMAL CHECKSUM A checksum error occurred in the built–in pulse coder. (INT) 361 n AXIS : ABNORMAL PHASE DATA A phase data error occurred in the built–in pulse coder. (INT) 362 n AXIS : ABN
Page 894A. ALARM LIST APPENDIX GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 203 DTE CRC STB PRM #7 (DTE) : The serial pulse coder encountered a communication error. The pulse coder, feedbak cable, or feedback receiver circuit is defective. Replace the pulse coder, feedback cable, or NC–axis board #6 (CRC) : The ser
Page 895GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 415 SERVO ALARM: n–TH AXIS – EX- A speed higher than 524288000 units/s was attempted to be set in the CESS SHIFT n–th axis (axis 1–8). This error occurs as the result of improperly set CMR. 417 SERVO ALARM: n–TH AXIS – PA- This alarm occurs
Page 896A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Contents 438 n AXIS : INV. ABNORMAL CUR- 1) SVM: The motor current is too high. RENT 2) α series SVU: The motor current is too high. 3) β series SVU: The motor current is too high. 439 n AXIS : CNV. OVERVOLT POWER 1) PSM: The DC link voltage is too
Page 897GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 460 n AXIS : FSSB DISCONNECT FSSB communication was disconnected suddenly. The possible causes are as follows: 1) The FSSB communication cable was disconnected or broken. 2) The power to the amplifier was turned off suddenly. 3) A low–volta
Page 898A. ALARM LIST APPENDIX GFKE-0222-EN #7 #6 #5 #4 #3 #2 #1 #0 201 ALD EXP When OVL equal 1 in diagnostic data No.200 (servo alarm No. 400 is being generated): #7 (ALD) 0 : Motor overheating 1 : Amplifier overheating When FBAL equal 1 in diagnostic data No.200 (servo alarm No. 416 is being generated):
Page 899GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 514 INTERFERENCE : +n The rotation area interference check function found interference on the plus side of the n axis. 515 INTERFERENCE : –n The rotation area interference check function found interference on the minus side of the n axis. N
Page 900A. ALARM LIST APPENDIX GFKE-0222-EN (11)Serial spindle alarms Number Message Contents 749 S–SPINDLE LSI ERROR It is serial communication error while system is executing after power supply on. Following reasons can be considered. 1) Optical cable connection is fault or cable is not connected or cable
Page 901GFKE-0222-EN APPENDIX A. ALARM LIST D The details of spindle alarm No.750 D 1st and 2nd spindles #7 #6 #5 #4 #3 #2 #1 #0 409 SPE S2E S1E SHE #3 (SPE) 0 : In the spindle serial control, the serial spindle parameters fulfill the spindle unit startup conditions. 1 : In the spindle serial control, the s
Page 902A. ALARM LIST APPENDIX GFKE-0222-EN (12)Safety zone alarms Number Message Contents 4800 ZONE : PUNCHING INHIBITED 1 When a safety zone check was executed, a punch command was specified in area 1 where punching is inhibited. 4801 ZONE : PUNCHING INHIBITED 2 When a safety zone check was executed, a pu
Page 903GFKE-0222-EN APPENDIX A. ALARM LIST Number Message Contents 4871 AUTO SETTING PIECES ERROR In safety zone auto setting, the safety zone pieces are not correct. Or the position detector has gone wrong, please tell your machine tool builder. 4872 AUTO SETTING COMMAND M code, S code or T code is specif
Page 904A. ALARM LIST APPENDIX GFKE-0222-EN Number Message Description 972 NMI OCCURRED IN OTHER MOD- An NMI occurred on a board other than the motherboard. ULE The option board may be faulty. 973 NON MASK INTERRUPT An NMI occurred as a result of an unknown cause. 974 F–BUS ERROR A bus error occurred on the
Page 905GFKE-0222-EN APPENDIX A. ALARM LIST A.2 LIST OF ALARMS (PMC) (1) PMC ALARMS/SYSTEM ALARMS (PMC–SB7) Alarm number Faulty location/corrective action Contents ER01 PROGRAM DATA ERROR 1) Re–input the sequence program. The sequence program is invalid. 2) Replace the master printed circuit board. ER02 PRO
Page 906A. ALARM LIST APPENDIX GFKE-0222-EN Alarm number Faulty location/corrective action Contents ER12 OPTION AREA ERROR Contact FANUC to reconfigure the PMC The PMC management software is inval- (xxxx) management software. id. (The series of BASIC and OPTION do not match.) ER13 OPTION AREA ERROR Contact
Page 907GFKE-0222-EN APPENDIX A. ALARM LIST Alarm number Faulty location/corrective action Contents ER27 LADDER FUNC. PRM IS Modify the sequence program. Change An out–of–range parameter number is OUT OF RANGE the parameter number of the function specified with function instruction TMR, instruction to a val
Page 908A. ALARM LIST APPENDIX GFKE-0222-EN Alarm number Faulty location/corrective action Contents ER98 ILLEGAL LASER CON- Modify the allocation of the I/O module. When an I/O device for a laser is used, NECTION the allocation of the I/O module does not match the actual I/O device configura- tion. ER99 X,Y
Page 909GFKE-0222-EN APPENDIX A. ALARM LIST Alarm number Faulty location/corrective action Contents WN21 COMMON MEM. ENTRY Modify the ENTRY in the shared memory When a PMC C board is used, the ERROR GDT in the link control statement. ENTRY in the shared memory GDT is out of range. WN22 LADDER 3 PRIORITY ER-
Page 910A. ALARM LIST APPENDIX GFKE-0222-EN Alarm number Faulty location/corrective action Contents WN32 LNK CONTROL DATA ER- 1) Check that the address of When a PMC C board is used, link con- ROR RC_CTLNB_INIT is set for the PMC trol statement (program control) data is system parameter, LANGUAGE ORI- inval
Page 911GFKE-0222-EN APPENDIX A. ALARM LIST (2) Alarm messages (PMC–SA1) Message Contents and solution ALARM NOTHING Normal status ER00 PROGRAM DATA The sequence program in the ROM is not written correctly. ERROR(ROM) (solution) Please exchange ROM for the sequence program. ER01 PROGRAM DATA The sequence pr
Page 912A. ALARM LIST APPENDIX GFKE-0222-EN Message Contents and solution ER18 PROGRAM DATA ERROR Transferring the sequence program from offline programmer was interrupted by the BY I/O power off etc. (solution) Please clear the sequence program and transfer the sequence program again. ER19 LADDER DATA ERRO
Page 913GFKE-0222-EN APPENDIX A. ALARM LIST Message Contents and solution ER35 TOO MUCH OUTPUT The number of the output data in the xx group exceeded the max. The data, which DATA IN GROUP(xx) exceed 32 bytes, become ineffective. (solution) Please refer to the following for the number of the data for each g
Page 914A. ALARM LIST APPENDIX GFKE-0222-EN Message Contents and solution WN19 GDT ERROR The value of BASE, LIMIT or ENTRY of user defined GDT is illegal. (BASE,LIMIT) (solution) Please correct the address in link control statement and build file. WN20 COMMON MEM. COUNT The number of common memories exceeds
Page 915GFKE-0222-EN APPENDIX A. ALARM LIST Message Contents and solution WN32 LNK CONTROL DATA ER- Link control statement data is illegal. ROR (solution) Please confirm whether the address of symbol RC_ CTLB_INIT in map file is set to LANGUAGE ORIGIN of the system parameter. Or, please make the link contro
Page 916A. ALARM LIST APPENDIX GFKE-0222-EN (3) System alarm messages (PMC–SB7) Message Contents and solution 1 PC004 CPU ERR A CPU error occurred in the PMC. xxxxxxxx:yyyyyyyy xxxxxxxx and yyyyyyyy indicate internal error code. PC006 CPU ERR xxxxxxxx:yyyyyyyy If this error occurs, the motherboard may be fa
Page 917GFKE-0222-EN APPENDIX A. ALARM LIST Message Contents and solution 5 PC070 SUB65 CALL (STACK) A stack error occurred during execution of ladder function instruction CALL/CALLU. Solution) Check the correspondence between the CALL/CALLU instruction and SPE instruction. If the error cannot be located, r
Page 918A. ALARM LIST APPENDIX GFKE-0222-EN (4) System alarm messages (for the C language board) Message Contents and solution 1 PC1nn CPU INTERRT CPU error (abnormal interrupt) xxxxyyyyyy nn : Exception code Exception code of the i80486. For details, refer to the relevant manual that describes the CPU. 00
Page 919GFKE-0222-EN APPENDIX A. ALARM LIST (5) Alarm messages (For EDIT: PMC–SB7) Messages displayed during update of the PMC ladder diagram editing Alarm number Faulty location/corrective action Contents OVERLAPPED COM If COME is missing, add it in proper posi- There is no COME that corresponds to tion. I
Page 920A. ALARM LIST APPENDIX GFKE-0222-EN Alarm number Faulty location/corrective action Contents DUPLICATE END1 Remove extra END1, END2 or END3. Multiple END1, END2 or END3 are DUPLICATE END2 found. DUPLICATE END3 GARBAGE AFTER END Remove unnecessary nets, and move There are some nets after END, END2 or
Page 921GFKE-0222-EN APPENDIX A. ALARM LIST Alarm number Faulty location/corrective action Contents LBL FOR JMPC IN BAD LEVEL JMPC is used to jump from a subprogram Destination of JMPC is not level 2. to level 2. If the JMPC is unnecessary, re- move it. If another LBL of same L–address that the JMPC is inte
Page 922A. ALARM LIST APPENDIX GFKE-0222-EN Alarm number Faulty location/corrective action Contents DUPLICATE TMR NUMBER If some of them are unnecessary, remove Plural TMRs have the same number as (WARNING) them. If all of them are necessary, assign their parameter. other number to parameter of them to (Thi
Page 923GFKE-0222-EN APPENDIX A. ALARM LIST Messages that may be displayed during net editing on PMC program editor screen Alarm number Faulty location/corrective action Contents TOO MANY FUNCTIONAL Only one functional instruction is allowed Too many functional instructions are in INSTRUCTIONS IN ONE NET to
Page 924A. ALARM LIST APPENDIX GFKE-0222-EN (6) Alarm messages (For EDIT) Message Contents and solution ADDRESS BIT NOTHING The address of the relay/coil is not set. FUNCTION NOT FOUND There is no functional instruction of the input number. COM FUNCTION MISSING The funcitonal instruction COM (SUB29) is not
Page 925GFKE-0222-EN APPENDIX A. ALARM LIST Message Contents and solution PLEASE KEY IN SUB NO. Please input the number of the functional instruction. (solution) If you do not input the functional instruction, please push soft key “FUNC” again. PROGRAM MODULE NOTHING You tried to edit though there was neith
Page 926A. ALARM LIST APPENDIX GFKE-0222-EN (7) Error Messages (at Automatic Write to Flash ROM after Ladder Editing) Error message Contents and solution PROGRAM ALREADY EXISTS A program already exists on flash ROM. (At BLANK) PROGRAM ALREADY EXISTS A program already exists on flash ROM. (EXEC?) (Remedy) Wh
Page 927GFKE-0222-EN APPENDIX A. ALARM LIST (8) Error Messages (at Assignment Data Editing) Message Contents and solution ERR: GROUP NO. (0—15) The group number must be 0 to 15. ERR: BASE NO. (0—1) The base number must be 0 or 1. WARN: BASE NO. MUST BE 0 For I/O Unit–B, the base number must be 0. The base n
Page 928A. ALARM LIST APPENDIX GFKE-0222-EN (9) Alarm messages (For I/O) Error message Contents and solution PROGRAM ALREADY EXISTS A program already exists on flash ROM. (At BLANK) PROGRAM ALREADY EXISTS A program already exists on flash ROM. (EXEC ?) Remedy) When the message is displayed, pressing the EXE
Page 929GFKE-0222-EN APPENDIX A. ALARM LIST Error message Contents and solution CREATE ERROR The specified file name is illegal. Remedy) Specify a file name in the MS–DOS form. (See 7.2 (5)) NO MORE SPACE or WRITE ERROR There is not enough free space on the memory card. Remedy) Delete files to create free s
Page 930A. ALARM LIST APPENDIX GFKE-0222-EN A.3 ALARM LIST When a serial spindle alarm occurs, the following number is displayed on (SERIAL SPINDLE) the CNC. n is a number corresponding to the spindle on which an alarm occurs. (n = 1: First spindle; n = 2: Second spindle; etc.) NOTE*1 Note that the meanings
Page 931GFKE-0222-EN APPENDIX A. ALARM LIST SPM in- No. Message dica- Faulty location and remedy Description tion(*1) 7n06 SPN_n_ : THERMAL 06 1 Check and correct the parameter. The temperature sensor of the motor SENSOR DIS- 2 Replace the feedback cable. is disconnected. CONNECT 7n07 SPN_n_ : OVERSPEED 07
Page 932A. ALARM LIST APPENDIX GFKE-0222-EN SPM in- No. Message dica- Faulty location and remedy Description tion(*1) 7n24 SPN_n_ : SERIAL 24 1 Place the CNC–to–spindle cable The CNC power is turned off (normal TRANSFER away from the power cable. power–off or broken cable). ERROR 2 Replace the cable. An err
Page 933GFKE-0222-EN APPENDIX A. ALARM LIST SPM in- No. Message dica- Faulty location and remedy Description tion(*1) 7n34 SPN_n_ : PARAMETER 34 Correct a parameter value according Parameter data exceeding the allow- SETTING ER- to the manual. able limit is set. ROR If the parameter number is unknown, conne
Page 934A. ALARM LIST APPENDIX GFKE-0222-EN SPM in- No. Message dica- Faulty location and remedy Description tion(*1) 7n47 SPN_n_ : POS–CODER 47 1 Replace the cable. 1 The A/B phase signal of the SIGNAL AB- 2 Re–adjust the BZ sensor signal. spindle position coder (connector NORMAL 3 Correct the cable layout
Page 935GFKE-0222-EN APPENDIX A. ALARM LIST SPM in- No. Message dica- Faulty location and remedy Description tion(*1) 7n58 SPN_n_ : OVERLOAD IN 58 1 Check the PSM cooling status. The temperature of the radiator of the PSM 2 Replace the PSM unit. PSM has increased abnormally. (PSM alarm indication: 3) 7n59 S
Page 936A. ALARM LIST APPENDIX GFKE-0222-EN SPM in- No. Message dica- Faulty location and remedy Description tion(*1) 7n88 SPN_n_ : COOLING RA- 88 Replace the SPM external cooling The external cooling fan stopped. DIFAN FAIL- fan. URE 7n97 SPN_n_ : OTHER 97 Replace the SPM. Another irregularity was detected
Page 937GFKE-0222-EN APPENDIX A. ALARM LIST SPM in- No. Message dica- Faulty location and remedy Description tion(*1) 9011 SPN_n_ : OVERVOLT 11 1 Check the selected PSM. Overvoltage of the DC link section of POW CIRCUIT 2 Check the input power voltage and the PSM was detected. (PSM alarm change in power dur
Page 938A. ALARM LIST APPENDIX GFKE-0222-EN SPM in- No. Message dica- Faulty location and remedy Description tion(*1) 9029 SPN_n_ : SHORTTIME 29 Check and correct the load status. Excessive load has been applied OVERLOAD continuously for a certain period of time. (This alarm is issued also when the motor sh
Page 939GFKE-0222-EN APPENDIX A. ALARM LIST SPM in- No. Message dica- Faulty location and remedy Description tion(*1) 9042 SPN_n_ : NO 1–ROT. 42 1 Replace the cable. 1 The 1–rotation signal of the POS–CODER 2 Re–adjust the BZ sensor signal. spindle position coder (connector DETECT JY4) is disconnected. 2 Th
Page 940A. ALARM LIST APPENDIX GFKE-0222-EN SPM in- No. Message dica- Faulty location and remedy Description tion(*1) 9056 SPN_n_ : INNER COOL- 56 Replace the SPM unit. The cooling fan in the SPM control cir- ING FAN STOP cuit stopped. 9057 SPN_n_ : EX DECEL- 57 1 Decrease the acceleration/decel- An overloa
Page 941GFKE-0222-EN APPENDIX A. ALARM LIST SPM in- No. Message dica- Faulty location and remedy Description tion(*1) 9086 SPN_n_ : NO 1–ROT 86 1 Replace the feedback cable. The one–rotation signal of the spindle SPNDL SEN- 2 Adjust the sensor. sensor cannot be correctly detected. SOR ERROR 9087 SPN_n_ : SP
Page 942A. ALARM LIST APPENDIX GFKE-0222-EN A.4 ERROR CODES (SERIAL SPINDLE) NOTE*1 Note that the meanings of the SPM indications differ depending on which LED, the red or yellow LED, is on. When the yellow LED is on, an error code is indicated with a 2–digit number. The error code is not displayed on the C
Page 943GFKE-0222-EN APPENDIX A. ALARM LIST SPM indica- Faulty location and remedy Description tion(*1) 12 During execution of the spindle synchronization com- Although spindle synchronization is being performed, mand, do not specify another operation mode. Before another operation mode (Cs contour control,
Page 944B. LIST OF MAINTENANCE PARTS APPENDIX GFKE-0222-EN B LIST OF MAINTENANCE PARTS Item Ordering information Remarks Fuse LCD–mounted type control unit (without PC) A02B–0236–K100 CNC display unit for is series CNC LCD–mounted type is series control unit A02B–0236–K101 Stand–alone type is series control
Page 945GFKE-0222-EN APPENDIX C. BOOT SYSTEM C BOOT SYSTEM C.1 OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 916 C.2 SCREEN CONFIGURATION AND OPERATING PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 918 C.3 ERROR MESSAGES AND REQUIRED ACTIONS . . . . . . . .
Page 946C. BOOT SYSTEM APPENDIX GFKE-0222-EN C.1 The boot system load the CNC system software (flash RAM→DRAM), then starts it so that software can be executed. OVERVIEW The boot system provides the following maintenance functions for the CNC: (1) Registering a file in flash ROM ⋅ Reads a file from a memory
Page 947GFKE-0222-EN APPENDIX C. BOOT SYSTEM 2 When the flash memory does not contain a file required to start the CNC Immediately after the CNC is turned on, the boot system starts transferring files from flash ROM to DRAM. If, for some reason, a file required to start the CNC (NC basic) is not in flash RO
Page 948C. BOOT SYSTEM APPENDIX GFKE-0222-EN C.2 When the boot system is first started, the MAIN MENU screen is displayed. This screen is described below : SCREEN CONFIGURATION AND OPERATING PROCEDURE D MAIN MENU screen (1) SYSTEM MONITOR MAIN MENU 60M5-01 (2) 1. SYSTEM DATA LOADING (3) 2. SYSTEM DATA CHECK
Page 949GFKE-0222-EN APPENDIX C. BOOT SYSTEM C.2.1 System Data Loading Screen D Description This screen is used to read a system or user file from a memory card into flash ROM. D Screen configuration (1) SYSTEM DATA LOADING 1/1 FILE DIRECTORY (2) B1H1A_B1.MEM B1H1A_AI.MEM (3) END *** MESSAGE *** (4) SELECT
Page 950C. BOOT SYSTEM APPENDIX GFKE-0222-EN 3 To start loading, press the [YES] soft key. To cancel, press the [NO] key. *** MESSAGE *** LOADING FROM MEMORY CARD. 4 When loading terminates normally, the system displays the following message. Press the [SELECT] soft key. If an error occurs, see C.3 *** MESS
Page 951GFKE-0222-EN APPENDIX C. BOOT SYSTEM C.2.2 System Data Check Screen D Description This screen is used to list files in flash ROM, together with the corresponding numbers of 128–KB management units in each file and the series and edition of the software. D Screen configuration (1) SYSTEM DATA CHECK 1
Page 952C. BOOT SYSTEM APPENDIX GFKE-0222-EN D Operating procedure 1 Select the file whose details are required. For example, select “1 NC BASIC (10).” 2 The numbers of management units in the selected file are listed, together with the series and edition of the software in each management unit. After check
Page 953GFKE-0222-EN APPENDIX C. BOOT SYSTEM C.2.3 System Data Delete Screen D Description This screen is used to delete a user file from flash ROM. D Screen configuration (1) SYSTEM DATA CHECK 1/1 (2) [BOARD:MAIN] FILE DIRECTORY (FLASH ROM : 16MB) (3) 1 NC BASIC ( 10) 2 NC2 BSIC ( 8) 3 DGB0SRVO ( 2) 4 PS0B
Page 954C. BOOT SYSTEM APPENDIX GFKE-0222-EN 4 When deletion terminates normally, the system displays the following message. Press the [SELECT] key. *** MESSAGE *** DELETING COMPLETE. HIT SELECT KEY. D Others 1 System files and user files on SYSTEM DATA DELETE screen The system files are protected from acci
Page 955GFKE-0222-EN APPENDIX C. BOOT SYSTEM D Operating procedure 1 Position the cursor to the name of the file to be deleted. Press the [SELECT] soft key. 2 The system displays the following confirmation message : *** MESSAGE *** SAVE OK ? HIT YES OR NO. 3 To start saving, press the [YES] key. To cancel,
Page 956C. BOOT SYSTEM APPENDIX GFKE-0222-EN C.2.5 SRAM DATA BACKUP Screen D Description This screen is used to collectively save and restore parameters, programs, and other data, retained after the CNC power in SRAM is turned off, to and from a memory card. D Screen configuration Select “4 SRAM DATA BACKUP
Page 957GFKE-0222-EN APPENDIX C. BOOT SYSTEM D Operating procedure [Backing up data] 1 Select “1. SRAM BACKUP.” The following confirmation message is displayed. The backup file name may be displayed according to the SRAM capacity. 2 Press [YES] to start backup. *** MESSAGE *** BACKUP SRAM DATA OK ? HIT YES
Page 958C. BOOT SYSTEM APPENDIX GFKE-0222-EN D Others 1 Name of backup file The name of the backup file written to the memory card by the SRAM backup function depends on the size of the SRAM installed in the CNC. When the size of SRAM is 1MB or larger, backup files are created in units of 512 KB. Number of
Page 959GFKE-0222-EN APPENDIX C. BOOT SYSTEM C.2.6 MEMORY CARD FILE DELETE Screen D Description This screen is used to delete a file from a memory card. D Screen configuration (1) SRAM DATA LOADING 1/1 FILE DIRECTORY (2) B1H1A_B1.MEM B1H1A_A1.MEM (3) END *** MESSAGE *** (4) SELECT FILE AND HIT SELECT KEY. [
Page 960C. BOOT SYSTEM APPENDIX GFKE-0222-EN C.2.7 MEMORY CARD FORMAT Function D Description This function is used to format a memory card. Memory cards must be formatted before they can be used for the first time or before they can be re–used after their data has been destroyed or lost because of, for exam
Page 961GFKE-0222-EN APPENDIX C. BOOT SYSTEM C.2.8 LOAD BASIC SYSTEM Function D Description The function is used to terminate the boot system and activate the CNC. D Operating procedure From the MAIN MENU screen, select “9. END.” The system displays the “ARE YOU SURE? HIT YES OR NO” message. To terminate th
Page 962C. BOOT SYSTEM APPENDIX GFKE-0222-EN 2 If the [NO] soft key is pressed, the system returns to the processing selection state as shown below : SYSTEM MONITOR MAIN MENU 60M5-01 1. SYSTEM DATA LOADING 2. SYSTEM DATA CHECK 3. SYSTEM DATA DELETE 4. SYSTEM DATA SAVE 5. SRAM DATA BACKUP 6. MEMORY CARD FILE
Page 963GFKE-0222-EN APPENDIX C. BOOT SYSTEM C.3 The following table lists and explains error messages in alphabetical order. ERROR MESSAGES AND REQUIRED ACTIONS Message Description and required action B BOOT ROM PARITY. The contents of flash memory containing boot software was de- PLEASE POWER OFF. stroyed
Page 964C. BOOT SYSTEM APPENDIX GFKE-0222-EN Message Description and required action M MAX EXTENSION OVER. The extension number added to a file name exceeds 031. Delete any HIT SELECT KEY. unnecessary backup files from the memory card. MEMORY CARD BATTERY ALARM. The memory card’s battery is exhausted. Repla
Page 965GFKE-0222-EN APPENDIX C. BOOT SYSTEM CAUTION 1 Action to be taken when an SRAM parity error is detected during backup of SRAM in the boot system The SRAM area of each CNC shipped from the factory is cleared and is free of parity errors. However, shock applied to the CNC during transportation may cau
Page 966D. MEMORY CARD SLOT APPENDIX GFKE-0222-EN D MEMRY CARD SLOT D.1 OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 937 D.2 MEMORY CARD TYPES (FUNCTIONS) . . . . . . . . 938 D.3 HARDWARE CONFIGURATION . . . . . . . . . . . . . . 939 936
Page 967GFKE-0222-EN APPENDIX D. MEMORY CARD SLOT D.1 Whether a memory card slot is provided or not depends on the hardware configuration. See the following table: OVERVIEW Hardware Card slot on LCD unit Card slot on control unit configuration Type 1 Provided No card slot Type 2 Provided Provided Type 6 (Th
Page 968D. MEMORY CARD SLOT APPENDIX GFKE-0222-EN D.2 SRAM memory card FROM memory card Data I/O MEMORY CARD Flash ATA card TYPES (FUNCTIONS) Modem card (for remote diagnosis) NOTE For details of the types of usable memory cards, see the ordering list. 938
Page 969GFKE-0222-EN APPENDIX D. MEMORY CARD SLOT D.3 HARDWARE CONFIGURATION D Type 1 LCD–mounted type LCD MDI Card slot on LCD unit Control unit (LCD–mounted type) D Type 2 Stand–alone type (with an LCD unit) Card slot on Optical cable LCD control unit LCD MDI link card Card slot on LCD unit LCD unit for s
Page 970D. MEMORY CARD SLOT APPENDIX GFKE-0222-EN D Type 4 Stand–alone type (with CNC display unit with PC functions or an PANEL i and FA keyboard or PC) Card slot on control unit PC Optical cable FA keyboard HSSB board CNC display unit with PC functions, PANEL i, or Control unit personal computer D Type 5
Page 971E. LED DISPLAY AND MAINTENANCE GFKE-0222-EN APPENDIX OF STAND–ALONE TYPE UNIT E LED DISPLAY AND MAINTENANCE OF STAND–ALONE TYPE UNIT E.1 OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 942 E.2 LAYOUT OF THE 7–SEGMENT LED AND SWITCHES . . . . . . . . . . . . . . . . . . . . .
Page 972E. LED DISPLAY AND MAINTENANCE OF STAND–ALONE TYPE UNIT APPENDIX GFKE-0222-EN E.1 FANUC Series 16i/18i/21i (referred to as FS16i hereinafter) of stand–alone type is equipped with a 7–segment LED, rotary switch, and OVERVIEW push switch. When no MDI is included in the system configuration or when the
Page 973E. LED DISPLAY AND MAINTENANCE GFKE-0222-EN APPENDIX OF STAND–ALONE TYPE UNIT E.2 The 7–segment LED, rotary switch, and push switch are located as shown below. LAYOUT OF THE 7–SEGMENT LED AND SWITCHES 7–segment LED (STATUS) Rotary switch (MTSW) Push switch (PSW) 943
Page 974E. LED DISPLAY AND MAINTENANCE OF STAND–ALONE TYPE UNIT APPENDIX GFKE-0222-EN E.3 OPERATION E.3.1 Before turning on the power, select a function number by using the rotary Operation Before switch. When the power is turned on after the selection with the rotary switch, the number corresponding to the
Page 975E. LED DISPLAY AND MAINTENANCE GFKE-0222-EN APPENDIX OF STAND–ALONE TYPE UNIT E.3.3 Seven–Segment LED Display E.3.3.1 NC status display Number displayed on LED Blink/not blink Description Not blink Automatic operation is paused, stopped, or reset. (Rotation of character ) Not blink Automatic operati
Page 976E. LED DISPLAY AND MAINTENANCE OF STAND–ALONE TYPE UNIT APPENDIX GFKE-0222-EN E.3.3.4 When a system alarm is issued, a number blinks on the 7–segment LED. LED display when a Number on LED System alarm Type of system alarm system alarm is issued (blinking) number In the 900’s ROM PARITY In the 910’s
Page 977E. LED DISPLAY AND MAINTENANCE GFKE-0222-EN APPENDIX OF STAND–ALONE TYPE UNIT E.3.3.5 Display on the Number displayed On/off status of Meaning 7–segment LED at on LED 4 LEDs power–on jjjj Power is not on. JJJJ Power is turned on, but the CPU does not yet start. JJJJ NC system loading is started by t
Page 978E. LED DISPLAY AND MAINTENANCE OF STAND–ALONE TYPE UNIT APPENDIX GFKE-0222-EN E.3.4 Operation of Each Function D Function number 2 This function sets a device number for the display link function. (1) Check that number 2 blinks on the LED, and press the push switch. (2) Number 2 is displayed on the
Page 979E. LED DISPLAY AND MAINTENANCE GFKE-0222-EN APPENDIX OF STAND–ALONE TYPE UNIT D Function number 8 This function saves battery backed–up main board data in a memory card at a time. The data saved using this function can be restored at a time by performing the operation for function number A or by usi
Page 980F. MAINTENANCE OF OPEN CNC (BOOT–UP AND IPL) APPENDIX GFKE-0222-EN F MAINTENANCE OF OPEN CNC (BOOT–UP AND IPL) F.1 OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 951 F.2 CHANGING START SEQUENCES . . . . . . . . . . . . . 952 F.3 EXPLANATION OF SCREENS . . . . . . . . . . .
Page 981F. MAINTENANCE OF OPEN CNC GFKE-0222-EN APPENDIX (BOOT–UP AND IPL) F.1 When the 160i/180i/210i is used or the CNC is connected to the PC over HSSB, Ncboot32.exe can be used for the maintenance of the CNC. When OVERVIEW the 160is/180is/210is is used, Ncbootis.exe can be used for the maintenance of th
Page 982F. MAINTENANCE OF OPEN CNC (BOOT–UP AND IPL) APPENDIX GFKE-0222-EN F.2 With the rotary switch on the HSSB board on the CNC side (when the CNC does not have the PC function) or on the motherboard of the CNC CHANGING START (when the CNC has the PC function), the start sequence can be changed. SEQUENCE
Page 983F. MAINTENANCE OF OPEN CNC GFKE-0222-EN APPENDIX (BOOT–UP AND IPL) D HSSB interface board of 16i/18i/21i of LCD–mounted type Rotary switch D HSSB interface board of 16i/18i/21i/160i/180i/210i/160is/180is/ 210is of stand–alone type Rotary switch D Stand–alone type 160is/180is/210is Rear of unit Rotar
Page 984F. MAINTENANCE OF OPEN CNC (BOOT–UP AND IPL) APPENDIX GFKE-0222-EN F.3 EXPLANATION OF NOTE SCREENS A mouse is required to display Ncboot32.exe screens. F.3.1 Boot Screen When the sub–board is provided, select a board in the [Board] list. The area where the file is to be placed can be changed by usin
Page 985F. MAINTENANCE OF OPEN CNC GFKE-0222-EN APPENDIX (BOOT–UP AND IPL) F.3.1.1 The following screen is used for manipulating system data (including System data control software and ladder programs) on the NC. manipulation [Load...] opens the file selection screen. Specify a file to be loaded. [Save] sav
Page 986F. MAINTENANCE OF OPEN CNC (BOOT–UP AND IPL) APPENDIX GFKE-0222-EN F.3.1.2 This screen is used to store and restore NC SRAM data. SRAM operation [Backup] stores SRAM data, and [Restore] restores SRAM data. In the center of the screen, the progress status is displayed. As with the NC, the backup file
Page 987F. MAINTENANCE OF OPEN CNC GFKE-0222-EN APPENDIX (BOOT–UP AND IPL) F.3.1.3 The following screen is used for operating files on a memory card in the File operation CNC or in a folder of the PC. [Delete] deletes a selected file. [Format] formats the memory card. This button is valid when the memory ca
Page 988F. MAINTENANCE OF OPEN CNC (BOOT–UP AND IPL) APPENDIX GFKE-0222-EN F.3.2 IPL Screen NOTE The contents of the IPL screen vary depending on the CNC model. Follow the instructions displayed in the menu. The CNC allows functions to be performed according to the key status set at power–on. The open CNC d
Page 989F. MAINTENANCE OF OPEN CNC GFKE-0222-EN APPENDIX (BOOT–UP AND IPL) F.3.2.1 Functions on the IPL Corresponding MDI screen key operation at Title on IPL screen power–on (Operation with a standard CNC) 0. EXIT 1. 0. CANCEL MEMORY CLEAR 1. ALL MEMORY 0. CANCEL 1. ALL + 2. SUB + <2
Page 990F. MAINTENANCE OF OPEN CNC (BOOT–UP AND IPL) APPENDIX GFKE-0222-EN Corresponding MDI key operation at Title on IPL screen power–on (Operation with a standard CNC) 2. 0. CANCEL SETTING 1. IGNORE OVER 0. CANCEL TRAVEL ALARM 1. CNC +
2. LOADER + 2. START WITHOUT 0. CANCEL LADDER 1.
Page 991F. MAINTENANCE OF OPEN CNC GFKE-0222-EN APPENDIX (BOOT–UP AND IPL) F.4 OTHER SCREENS F.4.1 CNC Alarm Screen This screen appears when a system alarm is issued in the CNC. (The above screen is an example. The displayed information varies depending on the system alarm issued in the CNC.) 961
Page 992F. MAINTENANCE OF OPEN CNC (BOOT–UP AND IPL) APPENDIX GFKE-0222-EN F.4.2 To open the status screen, double–click the icon in the system tray. Status Screen Alternatively, in the menu popped up by right–clicking, click OPEN. (160i/180i/210i) Node: Node number Name: Node name. (Define the node name in
Page 993F. MAINTENANCE OF OPEN CNC GFKE-0222-EN APPENDIX (BOOT–UP AND IPL) Status screen The status screen appears when the system tray icon is double–clicked or (160is/180is/210is) NCBOOTis is restarted. This screen can be used to change the list of files to save, restore, or start as well as to check the
Page 994F. MAINTENANCE OF OPEN CNC (BOOT–UP AND IPL) APPENDIX GFKE-0222-EN [Backup unit Enable] When this check box is checked, the registry and files are automatically saved during power–down. After power–down, the special battery is used to supply the power during saving. [High Priority] This check box is
Page 995G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS G FSSB START–UP PROCEDURE/MATERIALS G.1 OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 966 G.2 SLAVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 967 G.3 AUTOMATIC SETTING . . . . . . . .
Page 996G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN G.1 With a system that uses the FSSB, the parameters below need to be set for axis setting. (Set other parameters as usually done.) OVERVIEW D No. 1023 D No. 1905 D No. 1910 to 1919 D No. 1936, 1937 For setting of these parameters, three me
Page 997G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS G.2 In a system using the FSSB, the CNC, servo amplifiers, and separate detector interface units are connected with each other via optical cables. SLAVE These amplifiers and pulse modules are referred to as slaves. Assume that a 2–axis ampl
Page 998G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN G.3 When the following parameters are set, automatic setting can be performed using the FSSB setting screen: AUTOMATIC Bit 0 of No. 1902 = 0 SETTING Bit 1 of No. 1902 = 0 For automatic setting on the FSSB setting screen, use the procedure b
Page 999G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS 11 Pressing the continuous menu key several times displays [FSSB]. 12 Pressing soft key [FSSB] switches the screen display to the amplifier setting screen, and displays the following soft keys: [ AMP ][ AXIS ][ MAINT ][ ][ (OPRT) ] 13 Press
Page 1000G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN G.3.1 [Sample Setting 1] General Configuration (Semi–Closed Loop) Z–axis A–axis X–axis Y–axis Step 1 Set the following with parameter No. 1023: X:1 Y:2 Z:3 A:4 Step 2 Initialize the servo parameters for each axis. Step 3 Turn on then off th
Page 1001G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS Step 7 Pressing the continuous menu key several times displays [FSSB]. Step 8 Pressing soft key [FSSB] switches the screen display to the amplifier setting screen, and displays the following soft keys: [ AMP ][ AXIS ][ MAINT ][ ][ (OPRT) ]
Page 1002G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN (Amplifier setting) No. AMP SERIES UNIT CUR. [AXIS] NAME 1 A1–L α SVM 40A [ 2 ] Y 2 A2–L α SVM 40A [ 1 ] X 3 A3–L α SVM 40A [ 4 ] A 4 A3–M α SVM 80A [ 3 ] Z NO. EXTRA TYPE PCB ID 5 M1 A 0008 DETECTOR(4AXES) > MDI **** *** *** 13:11:56 [ AMP
Page 1003G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS G.3.3 [Sample Setting 3] When the C–Axis is a Cs Axis Z–axis A–axis X–axis Y–axis C–axis 1 Spindle Amplifiers Cs contour control axis Step 1 Set the following with parameter No. 1023: X:1 Z:2 C : –1 Y:3 A:4 Step 2 Initialize the servo param
Page 1004G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN Step 5 Enter the axis numbers on the amplifier setting screen. (AMPLIFIER SETTING) No. AMP SERIES UNIT CUR. [AXIS] NAME 1 A1–L α SVM 40A [ 2 ] Z 2 A2–L α SVM 40A [ 1 ] X 3 A3–L α SVM 40A [ 4 ] A 4 A3–M α SVM 80A [ 3 ] Y NO. EXTRA TYPE PCB I
Page 1005G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS G.3.4 The following two pairs of axes are tandem axes: [Sample Setting 4] [The X–axis is a master axis, and the A–axis is a slave axis.] Tandem Control [The Y–axis is a master axis, and the B–axis is a slave axis.] Configuration 4 servo amp
Page 1006G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN Step 4 Enter the axis numbers on the amplifier setting screen. (AMPLIFIER SETTING) No. AMP SERIES UNIT CUR. [AXIS] NAME 1 A1–L α SVM 40A [ 2 ] Y 2 A2–L α SVM 40A [ 1 ] X 3 A3–L α SVM 40A [ 4 ] A 4 A3–M α SVM 80A [ 3 ] Z 5 A4–L α SVM 40A [ 5
Page 1007G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS G.3.5 [EGB workpiece axis: A–axis, EGB dummy axis: B–axis (No. 7771 = [Sample Setting 5] 5)] When the Simple Electronic Gear Box (EGB) Function is Used Connector 1 (CN1) 3 Servo Amplifiers B–axis scale Z–axis A–axis X–axis Y–axis Machine si
Page 1008G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN Step 4 Enter the axis numbers on the amplifier setting screen. (AMPLIFIER SETTING) No. AMP SERIES UNIT CUR. [AXIS] NAME 1 A1–L α SVM 40A [ 2 ] Y 2 A2–L α SVM 40A [ 1 ] X 3 A3–L α SVM 40A [ 4 ] A 4 A3–M α SVM 80A [ 3 ] Z NO. EXTRA TYPE PCB I
Page 1009G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS G.4 When the following parameters are set, each axis can be set manually: MANUAL SETTING 2 No.1902#0=1 No.1902#1=0 When performing manual setting, set parameter Nos. 1023, 1905, 1910 through 1919, 1936, and 1937, fully understanding their f
Page 1010G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN Con- Program Servo Interface trolled axis name axis No. type axis No. No.1020 No.1023 Fast/Slow 2–axis AMP 1–axis AMP 2–axis AMP 1–axis AMP #6 (PM1) The first separate detector interface unit is: 0 : Not used. 1 : Used. #7 (PM2) The second
Page 1011G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS The slave is the generic name of a servo amplifier or separate detector interface unit connected to the CNC via an FSSB optical cable. The numbers from 1 to 10 are assigned to the slaves in ascending order; a younger number is assigned to a
Page 1012G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN ` Axis configuration and example of parameter setting Slave ATR No. No.1910 AXIS Control Axis Name Servo to 1919 No. No.1020 Axis No. No.1023 1 axis AMP L–axis 2 axis AMP M–axis L–axis 2 axis AMP M–axis M1 1 axis AMP M2 M1/M2 : Separate det
Page 1013G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS ` Axis configuration and example of parameter setting when the simple electronic gear box (EGB) function is used (EGB workpiece axis: A–axis, EGB axis: B–axis (parameter No. 7771 = 5)) Slave ATR No. No.1910 AXIS Control Axis Name Servo to 1
Page 1014G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN Example: Con- First con- Second No.1936 No.1937 No.1905 trolled nector connector (#7,#6) axis number number X 1 Not used 0 0 0,1 Y Not used 2 0 1 1,0 Z Not used 1 0 0 1,0 A Not used Not used 0 0 0,0 B 2 Not used 1 0 0,1 C Not used 3 0 2 1,0
Page 1015G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS No. 1910 1911 1912 1913 1914 1915 1916 1917 1918 1919 0 1 2 3 4 16 5 48 40 40 No. 1023 1905#0 1905#6 1905#7 1936 1937 FSBSL FSBM1 FSBM2 X 1 0 1 0 0 0 Y 3 0 0 1 0 1 Z 4 1 0 1 0 0 A 2 1 0 0 0 0 B 5 0 1 0 1 0 C 6 1 0 1 0 2 985
Page 1016G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN G.5 When the following parameters are set, manual setting 1 is enabled: MANUAL SETTING 1 Bit 0 of No. 1092 = 0 Bit 1 of No. 1902 = 0 Nos. 1910 through 1919 = 0 (all set to 0) In manual setting 1, a setting is made at power–on so that the va
Page 1017G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS G.6 Alarms related to pulse coders ALARMS NC alarm Message Description No. 360 n AXIS : ABNORMAL A checksum error occurred in the built–in CHECKSUM (INT) pulse coder. 361 n AXIS : ABNORMAL PHASE A phase data error occurred in the built–in D
Page 1018G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN Alarms related to servo amplifiers NC alarm Message Description No. 430 n AXIS : SV. MOTOR OVER- A servo motor overheat occurred. HEAT 431 n AXIS : CNV. OVERLOAD 1) PSM: Overheat occurred. 2) β series SVU: Overheat occurred. 432 n AXIS : CN
Page 1019G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS NC alarm Message Description No. 443 n AXIS : CNV. COOLING FAN 1) PSM: The internal stirring fan failed. FAILURE 2) PSMR: The internal stirring fan failed. 3) β series SVU: The internal stirring fan failed. 444 n AXIS : INV. COOLING FAN SVM
Page 1020G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN Alarms related to servo amplifiers NC alarm Message Description No. 460 n AXIS : FSSB DISCON- FSSB communication was disconnected NECT suddenly. The possible causes are as fol- lows: 1) The FSSB communication cable is dis- connected or brok
Page 1021G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS P/S alarms NC alarm Message Description No. 5134 FSSB : OPEN READY TIME The FSSB did not become ready to open OUT duringinitialization. 5135 FSSB : ERROR MODE The FSSB entered an error mode. 5136 FSSB : NUMBER OF AMPS The number of amplifie
Page 1022G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN G.7 D MDI input is abnormal (each time data is entered, the power needs to be turned off). ACTIONS FOR First, disconnect the optical cable of the NC, then turn off then on the TROUBLE power. Next, check the items below. ENCOUNTERED AT (A) C
Page 1023G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS Action: When automatic setting on the FSSB screen is not performed, set all of parameter Nos. 1902, 1905, 1910 through 1919, 1936, and 1937 to 0 before starting manual setting. D The invalid amplifier/motor combination alarm (466) is issued
Page 1024G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN G.8 EXAMPLES OF SETTINGS USING OTHER CONNECTIONS G.8.1 Example 1: Learning Control D Conceptual diagram of When learning control is used, one NC controlled axis uses one DSP (two FSSB parameter setting axes of the servo axis card) exclusive
Page 1025G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS G.8.2 Example: FSSB setting for the following: Example 2: When a Hardware connection 2–Axis Amplifier is Mother board – 2–axis amplifier (LX/LZ) – 2–axis amplifier Shared by Two Paths (LA/RA) – 2–axis amplifier (LC/RC) Sub–board – 2–axis am
Page 1026G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN Path 1 Axis Name Axis card Amplifi- er/motor Path 2 Axis Name Axis card Amplifi- er/motor (3) Set an axis card number (DSP number) in parameter No. 1023 to connect an NC controlled axis with a motor. (4) For an axis for which an even number
Page 1027G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS Path 1 Axis Name Axis card Amplifi- er/motor Path 2 Axis Name Axis card Amplifi- er/motor 997
Page 1028G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN G.9 The FSSB setting screen displays FSSB–based amplifier and axis information, and allows amplifier and axis information to be set. FSSB DATA DISPLAY 1 Press function key SYSTEM . 2 Pressing the continuous menu key several times displays [
Page 1029G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS D AXIS NO: Controlled axis number The controlled axis numbers set in parameter Nos. 1920 through 1929 are displayed. When a value outside the range 1 to the maximum number of controlled axes is set, 0 is displayed. D NAME: Controlled axis n
Page 1030G. FSSB START–UP PROCEDURE/ MATERIALS APPENDIX GFKE-0222-EN The axis setting screen displays the items below. D AXIS NO: Controlled axis number The NC controlled axis numbers are displayed sequentially. D NAME: Controlled axis name D AMP: Type of amplifier connected to each axis D M1: Connector numb
Page 1031G. FSSB START–UP PROCEDURE/ GFKE-0222-EN APPENDIX MATERIALS (AMPLIFIER MAINTENANCE) O1000 N00001 NO. 1 X 01A 970123 01 2 Y 01A 970123 01 3 Z 01A 970123 01 4 A 02B 970123 01 5 B 02B 970123 01 6 C 02B 970123 01 MDI **** *** *** 13:11:56 [ AMP ][ AXIS ][ MAINT ][ ][ (OPRT) ] The amplifier maintenance s
Page 1032H. NOTATION OF MDI KEYS APPENDIX GFKE-0222-EN H NOTATION OF MDI KEYS i series CNC have two types of MDI keypads : English type and Symbolic type. The table below shows correspondence between English keys and Symbolic keys. This manual uses English type in the text. Therefore when a user uses Symboli
Page 1033GFKE-0222-EN APPENDIX H. NOTATION OF MDI KEYS Name English key Symbolic key ALTER key ALTER INSERT key INSERT DELETE key DELETE PAGE UP key PAGE PAGE PAGE DOWN key HELP key HELP RESET key RESET CUSTOM CUSTOM/GRAPH key GRAPH 1003
Page 1034
Page 1035GFKE-0222-EN Index ƠSymbolsơ Alarms 910 and 911 (Sram Parity), 796 Alarms 912 to 919 (Dram Parity), 799 [Sample setting 1] general configuration (semi–closed loop), 970 Alarms 920 and 921 (Servo Alarms), 801 [Sample setting 2] general configuration (closed loop), 971 Amplifier maintenance screen, 10
Page 1036INDEX GFKE-0222-EN Confirming the parameters required for data output, 402 Error messages and required actions, 933 Connector and card configurations of printed circuit boards, Ethernet Board, 215 280 Example 1: learning control, 994 Contents displayed, 66 Example 2: when a 2–axis amplifier is share
Page 1037GFKE-0222-EN INDEX Help function, 63 ƠJơ Help screen, 20 Jog Operation Cannot be Done, 731 Host file deletion, 641 Host file list display, 638 Host file search, 641 ƠKơ HSSB interface board, 208, 303 Kind of data in sub memory, 419 ƠIơ ƠLơ I/O, 227 Layout of the 7–segment LED and switches, 943 I/O L
Page 1038INDEX GFKE-0222-EN Method B of gear change for machining center (PRM Outputting CNC parameters, 403 3705#2=1), 701 Outputting custom macro common variables, 431 Module configuration screen, 27 Outputting custom macro variable values, 405 Mother Board of CNC Display Unit for is Series, 319 Outputting
Page 1039GFKE-0222-EN INDEX Replacing the Fuse, 389 OFFSET Soft key transition triggered by the function key SETTING , 13, Replacing the fuse of the control unit, 342 15 Replacing the fuse of the LCD unit, 348 Replacing the Fuse on the Units, 265 Soft key transition triggered by the function key POS ,3 Repla
Page 1040INDEX GFKE-0222-EN System reserve area of internal relay, 451 Using the DNC1/Ethernet function on a small network, 620 System screen, 17 Using the FACTOLINK function on a small network, 613 Using the FOCAS1/Ethernet function on a small network, 619 Using the FTP file transfer function on a small net
Page 1041Revision Record FANUCĄSeries 16i/160i/160is/18i/180i/180is/21i/210i/210is-MODEL B MAINTENANCE MANUAL (B–63525EN) D Addition of following models: – Series 160is/180is/210is–MODEL B 02 Nov., 2001 – Series 18i/180i/180is–MB5 D Addition of functions D Addition of alarms 01 Jun., 2001 Edition Date Conten
