FL-net Board Operators manual Page 159

Operators manual
TITLE
Modification of FANUC FL-net Board
OPERATOR’S MANUAL
Other error message
NODE(???) OUT-RING
The node number (???) is dropped from the network.
DROPPED PACKET(???->???)
Because the reception buffer is full, the data of the node number(???->???) can not be
received.
Please set the larger value into Pa16.
TOKEN IS DUPLICATED(???)
Because the node number (???) sent the token though this local node possesses the token,
this local node dropped its own token.
Please set the larger value into Pa15 of the node number (???).
TOKEN HOLDING TIME IS UP
Because token monitoring time expired, this local node dropped its possessing token.
Please set the larger value into Pa15 of this local node.
IP CHECK-SUM ERROR
The checksum of IP layer of the received data is not correct.
FL-net data may be sometimes destroyed by the reason that noise or something influences
the FL-net network.
Please check the ground of the devices etc.
SEND BUFFER IS FULL
Because the transmission buffer is full, data can not be sent.
The transmission error may be often occurring by the reason of noise or something.
Please check the ground of the devices etc.
SEND ERROR(????H)
The error (????H) occurred when data is just sent.
The transmission error may be often occurring by the reason of noise or something.
Please check the electric ground of the devices etc.
RECEIVE ERROR(????H)
The error (????H) occurred when data is just received.
The transmission error may be often occurring by the reason of noise or something.
Please check the electric ground of the devices etc.
Addition of the following note into Page 97
NOTE
The error message can not be displayed in the DPL screen.
SHEET
17/17
DESCRIPTIONDESIGN DATE EDIT
01 Mutai First issue
B-63434EN/02-1
FANUC LTD.
02.05.20
DRAW.NO.
Previous page
Next page
