FL-net Board Operators manual Page 163

Operators manual
Sheet
Title
Draw
No.
Ed. Date Design Description
Date Dec.15.2004 Desig. Y.Honda Apprv.
4/9
FANUC FL-net Board
OPERATOR’S MANUAL
B-63434EN/02-3
The available PMC address is %M and %R.
In case of %M, the available range is from 1 to 63985.
But the following condition has to be satisfied.
Condition) (16*n)+1 [n=from 0 to 3999]
In case of %R, the available range is from 1 to 5000.
AREA2 DO :
ALLOCATION
Examples) “M1”, “M17”, “M63985”,
“R1”, “R2”, “R5000”
The available PMC address is %M and %R.
In case of %M, the available range is from 1 to 63985.
But the following condition has to be satisfied.
Condition) (16*n)+1 [n=from 0 to 3999]
In case of %R, the available range is from 1 to 5000.
AREA2 DI :
ALLOCATION
Examples) “M1”, “M17”, “M63985”,
“R1”, “R2”, “R5000”
The available PMC address is %R.
The available range is from 1 to 5000.
AREA2 DI :
ALLOC PTR
Examples) “R1”, “R2”, “R5000”
The available PMC address is %M.
The available range is from 1 to 63993.
But the following condition has to be satisfied.
Condition) (8*n)+1 [n=from 0 to 7999]
AREA2 DI :
CHANGE FLG
Examples) “M1”, “M9”, “M63993”
The available PMC address is %M and %R.
In case of %M, the available range is from 1 to 63985.
But the following condition has to be satisfied.
Condition) (16*n)+1 [n=from 0 to 3999]
In case of %R, the available range is from 1 to 5000.
MESSAGE :
ADDRESS
Examples) “M1”, “M17”, “M63985”,
“R1”, “R2”, “R5000”
The available PMC address is %M and %R.
In case of %M, the available range is from 1 to 63985.
But the following condition has to be satisfied.
Condition) (16*n)+1 [n=from 0 to 3999]
In case of %R, the available range is from 1 to 5000.
MESSAGE :
RECV MSG
Examples) “M1”, “M17”, “M63985”,
“R1”, “R2”, “R5000”
NOTE
1 When inputting the PMC address, it is not necessary to input “%”.
2 When PMC address setting is invalid, an error message “INPUT
INVALID” is displayed.
