FL-net Board Operators manual Page 167

Operators manual
Sheet
Title
Draw
No.
Ed. Date Design Description
Date Dec.15.2004 Desig. Y.Honda Apprv.
8/9
FANUC FL-net Board
OPERATOR’S MANUAL
B-63434EN/02-3
Table 4-4 Parameters of Node No.30
Item Setting Item Setting
IP ADDRESS 192.168.250.30 AREA2 DI:
－
NODE NAME NODE#30 ALLOCATION %M02401
AREA1 ADDR 24 ALLOC PTR %R00001
AREA1 SIZE 4 CHANGE FLG %M02393
AREA2 ADDR 160 AREA2 ADDR 0
AREA2 SIZE 64 AREA2 SIZE 0
TOKEN WATCH 50 MESSAGE:
－
MIN FRAME 10 ADDRESS %M03601
OWN STATUS %M00993 SIZE 20
ENTRY NODE %M01025 RECV MSG %M00001
AREA1 DO/DI:
－
SIZE 0
ALLOCATION %M00801
ADDRESS 16
SIZE 12 %R0001 of PMC 10
AREA2 DO:
－
%R0002 of PMC 0
ALLOCATION %M01281 %R0003 of PMC 64
SIZE 64 %R0004 of PMC 0
