FL-net Board Operators manual Page 99

Operators manual
2.MAINTENANCE SCREEN OPERATION B-63434EN/02
- 92 -
2.4 Power Mate i-MODEL D/H
Procedure
When the CRT/MDI or FANUC touch panel is used as the LCD,
reference maintenance information in the same way as for the Series
16i/18i/21i-A.
When the DPL/MDI Operation Package is used as the LCD,
maintenance information can be referenced with diagnosis numbers
8000 and after.
For how to display diagnostic data using the DPL/MDI Operation
Package, refer to "Power Mate i Operator’s Manual."
The diagnosis numbers and corresponding reference items are listed
below.
Participating node management table
The number of the node on which maintenance information is
displayed is set using parameter No. 30045.
8000 AREA1 ADDR
[Data type] Word
Start address of common memory area 1 of the node
8001 AREA1 SIZE
[Data type] Word
Size of common memory area 1 of the node
8002 AREA2 ADDR
[Data type] Word
Start address of common memory area 2 of the node
8003 AREA2 SIZE
[Data type] Word
Size of common memory area 2 of the node
8004 LKS
[Data type] Byte
State of the FA link of the node
8005 ULS
[Data type] Word
State of the upper layer of the node
8006 TOKEN WATCH
[Data type] Byte
[Unit of data] 1 msec
Token monitoring time of the node
