FANUC FL-net Board
OPERATOR’S MANUAL
B-63434EN/02-3
Table 4-2 Parameters of Node No.10
Item Setting Item Setting
IP ADDRESS 192.168.250.10 AREA2 DI:
－
NODE NAME NODE#10 ALLOCATION %M02401
AREA1 ADDR 16 ALLOC PTR %R00001
AREA1 SIZE 4 CHANGE FLG %M02393
AREA2 ADDR 0 AREA2 ADDR 0
AREA2 SIZE 64 AREA2 SIZE 0
TOKEN WATCH 50 MESSAGE:
－
MIN FRAME 10 ADDRESS %M03601
OWN STATUS %M00993 SIZE 20
ENTRY NODE %M01025 RECV MSG %M00001
AREA1 DO/DI:
－
SIZE 0
ALLOCATION %M00801
ADDRESS 16
SIZE 12 %R0001 of PMC 20
AREA2 DO:
－
%R0002 of PMC 0
ALLOCATION %M01281 %R0003 of PMC 64
SIZE 64 %R0004 of PMC 0
Table 4-3 Parameters of Node No.20
Item Setting Item Setting
IP ADDRESS 192.168.250.20 AREA2 DI:
－
NODE NAME NODE#20 ALLOCATION %M02401
AREA1 ADDR 20 ALLOC PTR %R00001
AREA1 SIZE 4 CHANGE FLG %M02393
AREA2 ADDR 80 AREA2 ADDR 0
AREA2 SIZE 64 AREA2 SIZE 0
TOKEN WATCH 50 MESSAGE:
－
MIN FRAME 10 ADDRESS %M03601
OWN STATUS %M00993 SIZE 20
ENTRY NODE %M01025 RECV MSG %M00001
AREA1 DO/DI:
－
SIZE 0
ALLOCATION %M00801
ADDRESS 16
SIZE 12 %R0001 of PMC 30
AREA2 DO:
－
%R0002 of PMC 0
ALLOCATION %M01281 %R0003 of PMC 64
SIZE 64 %R0004 of PMC 0
