SERIES 15-150 MODEL B Programming manual Page 25

Programming manual

2. MACRO COMPILER
B–62073E–2/03
22
F–ROM ERASE & BLANK CHECK
ADDRESS 00000000 (Note 6)
ALARM NO. 0000 (Note 4)
DIAGNOSIS 140 (Note 5)
Fig.2.3.3 (f) Status Indication (ERASE)
(3) F–ROM WRITE
Writing of F–ROM can be suspended while it is in progress by
pressing the reset key. However, avoid suspending this operation
while it is in progress since doing so will shorten the life of the
F–ROM unit.
F–ROM WRITE
ADDRESS 00027A00 (Note 6)
ALARM NO. 0000 (Note 4)
DIAGNOSIS 150 (Note 5)
Fig.2.3.3 (g) Status Indication (WRITE)
(4) F–ROM VERIFY
Verification of F–ROM can be suspended while it is in progress by
pressing the reset key suspending this processing does not affect the
life of the F–ROM unit.
F–ROM VERIFY
ADDRESS 00027A00 (Note 6)
ALARM NO. 0000 (Note 4)
DIAGNOSIS 160 (Note 5)
Fig.2.3.3 (h) Status Indication (VERIFY)
