SERIES 15-150 MODEL B Programming manual Page 96

Programming manual

B–62073E–2/03
4.CONVERSATIONAL MACRO FUNCTION
93
OT axis type alarm flag 1
I.D No.
(#8997)
Bit name Information contents
Error
code
OTSP1 (01H) Entered prohibited areas of stored
stroke limit 1 during shift in + direc-
tion.
OT 001
OTSM1 (02H) Entered prohibited areas of stored
stroke limit 1 during shift in – direc-
tion.
OT 002
OTSP2 (04H) Entered prohibited areas of stored
stroke limit 2 during shift in + direc-
tion. Entered prohibited areas of
check tailstock barrierduring shift in
+ direction.
OT 003
11
OTSM2 (08H) Entered prohibited areas of stored
stroke limit 2 during shift in – direc-
tion. Entered prohibited areas of
check tailstock barrier during shift in
– direction.
OT 004
OTSP3 (10H) Entered prohibited areas of stored
stroke limit 3 during shift in + direc-
tion.
OT 005
OTSM3 (20H) Entered prohibited areas of stored
stroke limit 3 during shift in – direc-
tion.
OT 006
OTHP (40H) Exceeded + side stroke limit switch. OT 007
OTHM (80M) Exceeded – side stroke limit switch. OT 008
OT axis type alarm flag 2
I.D No.
(#8997)
Bit name Information contents
Error
code
OTPSP (01H) Entered prohibited area in + direc-
tion by preprocess stroke check.
OT 021
OTPSM (02H) Entered prohibited area in – direc-
tion by preprocess stroke check.
OT 022
– (04H) Undetermined
12
– (08H) Undetermined
– (10H) Undetermined
– (20H) Undetermined
– (40H) Undetermined
– (80H) Undetermined
