FS 16i/18i Added New Functions (A-62223E) Additional Manual Page 54

Additional Manual
No . #7
#6 #5 #4 #3 #2 #I
#O
EY
5400 D3R
Data type : Bit
D3R
0 : The three-dimensional coordinate conversion mode is canceled when the CNC is
reset by the G69.1 command, a reset, the input signal from the PMC.
1 : The three-dimensional coordinate conversion mode is canceled only by the G69.1
command.
I
Rapid traverse rate for a drilling cycle in the three-dimensional
5412
coordinate conversion mode
Data type : 2-word
Unit of data :
Valid data range :
Increment system
Unit of data
.
Valid data range
IS-B
IS-C
Millimeter machine
I mm/min
30-240000 30- 100000
Inch machine
0.1 inch/min
30-96000 30-48000
L
Specify the rapid traverse rate of the following movement
for a drilling cycle in the three-
dimensional coordinate conversion mode:
(1) Rapid traverse to point R
(2) Retraction to point R
When 0 is specified, a maximum cutting feedrate is used.
TITLEFANUC Series 16/l 8-TC
FANUC Series 16i/3 8i-TA
Three dimentional coordinate convertion
Specifications
DRAKNO. A__6()545-_E
CWT.
<DIT. DATE
DESIG.
DESCRIPTION
F!‘,NUC L@‘D SHEET 12/M
