B–64112EN/01

14. TOOL COMPENSATION FUNCTION

NC FUNCTION

169

G10 P_ X_ Z_ R_ Q_ ;

G10 P_ U_ W_ C_ Q_ ;

P : Offset number

1–64 :Tool wear offset number

10000+(1–64) : Tool geometry offset number+10000

X : Offset value on X axis (absolute)

Z : Offset value on Z axis (absolute)

U : Offset value on X axis (incremental)

W : Offset value on Z axis (incremental)

R : Tool nose radius offset value (absolute)

R : Tool nose radius offset value (incremental)

Q : Imaginary tool nose number

In an absolute command, the values specified in addresses X, Z, and R are

set as the offset value corresponding to the offset number specified by

address P. In an incremental command, the value specified in addresses

U, W, and C is added to the current offset value corresponding to the offset

number.

NOTE

1 Addresses X, Z, U, and W can be specified in the same

block.

2 Use of this command in a program allows the tool to

advance little by little. This command can also be used input

offset values one at a time from a tape by specifying this

command successively instead of inputting these values

one at a time from the MDI unit.

Format (T series)
