17. MEASUREMENT FUNCTIONS

B–64112EN/01

NC FUNCTION

186

By installing the touch sensor and by manually making the tool contact

the touch sensor, it is possible to set the offset amount of that tool

automatically in the tool offset amount memory. It is also possible to set

the work coordinate system shift amount automatically.

In addition, a tool compensation value measured value direct input B

function for two–spindle lathes is provided so that the tool compensation

value measured value direct input B function can be used for both spindles

of a one–turret two–spindle lathe.

As the touch sensor detection mode, either four–contact input mode or

single–contact input mode can be selected.

1) Four–contact input (when bit 3 (TS1) of parameter No. 5004 is set to 0)

The touch sensor has contact faces in two directions along each axis,

and outputs four signals when a touch is detected. These signals are

input to the CNC as tool compensation value writing signals (+MIT1,

+MIT2, –MIT1, and –MIT2).

When any of these input signals is input, the CNC stops feed in the

corresponding direction along the corresponding axis.

2) Single–contact input (when bit 3 (TS1) of parameter No. 5004 is set

to 1)

The touch sensor outputs one signal when a touch by a single–contact

input is detected. This signal is input to the CNC as the tool

compensation value writing signal (+MIT1).

Then, the CNC determines the two directions along each axis

automatically and stops feed in the corresponding direction along the

corresponding axis.

Signal

Parameter

Signal

TS1=0 TS1=1

+MIT1 Contact the (+) contact face of the

X–axis (Contact in the X+ direction)

The two directions

along each axis is de-

termined automatically.

–MIT1 Contact the (–) contact face of the

X–axis (Contact in the X– direction)

Not used

+MIT2 Contact the (+) contact face of the

Z–axis (Contact in the Z+ direction)

Not used

–MIT2 Contact the (–) contact face of the

Z–axis (Contact in the Z– direction)

Not used

17.9

DIRECT INPUT OF

TOOL OFFSET

VALUE MEASURED B

(T series)

T series

Explanations

D Touch sensor
