0i/0i Mate - Model C Descriptions Page 326

Descriptions
B–64112EN/01
NC FUNCTION34. FUNCTIONS FOR PUNCH PRESS
300
G code list (2/2)
System A MeaningGroupSystem B
G54 G54
14
Workpiece coordinates system 1 selection
G55 G55
14
Workpiece coordinates system 2 selection
G56 G56
14
Workpiece coordinates system 3 selection
G57 G57
14
Workpiece coordinates system 4 selection
G58 G58 Workpiece coordinates system 5 selection
G59 G59 Workpiece coordinates system 6 selection
G61 G61
15
Exact stop mode
G62 G62
15
Automatic corner override
G64 G64
15
Continuous cutting mode
G65 G95 00 Custom macro simple call
G66 G96
12
Custom macro modal call
G67 G97
12
Custom macro modal call cancel
G68 G68
00
Circular nibbling
G69 G69
00
Linear nibbling
G70 G70
00
Positioning & press off
G72 G72
00
Standard point command
G73 G75
00
Multi-piece machining command X
G74 G76
00
Multi-piece machining command Y
G75 G27
00
Automatic repositioning
G76 G28 Line at angle
G77 G29 Arc
G78 G36 Grid I
G79 G37 Grid II
G84 G84
16
Coordinate system rotating on
G85 G85
16
Coordinate system rotating off
G86 G86
00
Share proof
G87 G87
00
Square
G88 G78
00
Radius
G89 G79 Cut at angle
G90 G90
03
Absolute command
G91 G91
03
Incremental command
G92 G92
00
Coordinate system setting
G98 G98
00
Coordinate system setting (Multi-piece machining)
