2. PREPARATORY FUNCTIONS

B–64112EN/01

NC FUNCTION

G code list for M series (2/3)

G code Group Function

G40.1 (G150)

Normal direction control cancel mode

G41.1 (G151)

Normal direction control left side on

G42.1 (G152) Normal direction control right side on

G43

Tool length compensation + direction

G44

Tool length compensation – direction

G45

Tool offset increase

G46

Tool offset decrease

G47

Tool offset double increase

G48 Tool offset double decrease

G49

08 Tool length compensation cancel

G50

Scaling cancel

G51

Scaling

G50.1

Programmable mirror image cancel

G51.1

Programmable mirror image

G52

Local coordinate system setting

G53

Machine coordinate system selection

G54

Workpiece coordinate system 1 selection

G54.1

Additional workpiece coordinate system selection

G55

Workpiece coordinate system 2 selection

G56

Workpiece coordinate system 3 selection

G57 Workpiece coordinate system 4 selection

G58 Workpiece coordinate system 5 selection

G59 Workpiece coordinate system 6 selection

G60 00/01 Single direction positioning

G61

Exact stop mode

G62

Automatic corner override

G63

Tapping mode

G64

Cutting mode

G65 00 Macro call

G66

Macro modal call

G67

Macro modal call cancel

G68

Coordinate rotation

G69

Coordinate rotation cancel

G73

Peck drilling cycle

G74

Counter tapping cycle
