FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
Operation of the graph
The operation is done by the softkey.
[MAGN↑] : The vertical axis of the strength display of all the waveform (upper
display on the screen) is moved upward.
[MAGN↓] : The vertical axis of the strength display of all the waveform (upper
display on the screen) is moved downward.
[MGZMIN] : The vertical axis of the strength display of all the waveform (upper
display on the screen) is expanded.
[MGZMOU] : The vertical axis of the strength display of all the waveform (upper
display on the screen) is reduced.
[AUTSCL] : A scale is adjusted automatically toward all the Draw graphs, and a
graph is made be to put within the display range.
But, each item of scale setting is between 0 - 99999999 (eight digits of 9)
in the range that it is adjusted.
In case that the graph is out of display range, the display unit of
operation & graph setting is need to be adjust.
[PHAS↑] : The vertical axis of the phase display of all the waveform (lower display
on the screen) is moved upward.
[PHAS↓] : The vertical axis of the phase display of all the waveform (lower
display on the screen) is moved downward.
[PHZMIN] : The vertical axis of the phase display of all the waveform (lower
display on the screen) is expanded.
[PHZMOU] : The vertical axis of the phase display of all the waveform (lower
display on the screen) is reduced.
[D1DISP] : The display or nondisplay is changed about the Draw1 waveform.
[D2DISP] : The display or nondisplay is changed about the Draw2 waveform.
[D3DISP] : The display or nondisplay is changed about the Draw3 waveform.
[D4DISP] : The display or nondisplay is changed about the Draw4 waveform.
[COMNT1] : Maximum 32-character comment can be inputted.
(Even an INPUT key can input only comment 1.)
And, input of a comment is displayed in all graphic display.
[COMNT2] : Maximum 32-character comment can be inputted.
And, input of a comment is displayed in all graphic display.
