FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
CONV
The list of numerical value to set up is displayed in " the candidate ".
The details of coordinate conversion is as follows.
Selecting number Contents
1Normal
2 Polar
3 Angular
Input condition
1) The selecting number on “the candidate” can be inputted by the following condition.
Operation CONV Condition
YT Normal Input condition no
Polar That each kind of the position (distance/revolution) the system is bound to
channel binding
Angular That the binding of the position system is done to channel binding
Diff1 Normal Input condition no
Polar
Angular
It is not able to select it
Diff2 Normal Input condition no
Polar
Angular
It is not able to select it
Tangent Normal Input condition no
Polar That each kind of the position (distance/revolution) the system is bound to
channel binding
Angular That the binding of the position system is done to channel binding
Tangent N Normal Input condition no
Polar
Angular
It is not able to select it
Smooth Normal Input condition no
Polar
Angular
It is not able to select it
Synchro Normal Input condition no
Polar
Angular
It is not able to select it
Bit Normal Input condition no
Polar
Angular
It is not able to select it
