9.1.5 A built-in method to CNC
After combined with C language application, the file “CEX ****” is loaded to the Flash
memory of CNC by BOOT SYSTEM.
9.1.6 Semaphore ID
Semaphore ID = 1 is used with SERVO GUIDE Mate.
Because common data are used between 'the task 1' and 'the task 3'.
9.1.7 Cautions
This library can be used with the following system software, a C language library.
It is used as a capacity 896KB.
(1) This function is available in following CNC ROM series / edition.
B1HA-07(G) or later
B0HA-05(E) or later
BEHA-07(G) or later
BDHA-05(E) or later
BDH5-20(T) or later
DEHA-07(G) or later
DDHA-05(E) or later
(2) This function is available with following C language library editon.
After BY01-2.9K
(3) This function is available with following editon of Xlink386.
After V2.0
