FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
UNIT
The unit which can be set up is different by the unit.
The list of numerical value to set up is displayed in "the candidate".
The detail of unit is as follows.
Selecting
number
Contents Selecting
number
Contents
1 Sec 21 mm/sec/sec (mm/sec^2)
2 Msec 22 mm/min/min (mm/min^2)
3 µsec 23 m/sec/sec (m/sec^2)
4 Mm 24 m/min/min (m/min^2)
5 M 25 inch/sec/sec (inch/sec^2)
6 µm 26 inch/min/min (inch/min^2)
7 Nm 27 deg/sec/sec (deg/sec^2)
8 Inch 28 deg/min/min (deg/min^2)
9 Deg 29 1/sec/sec (1/sec^2)
10 Mdeg 30 1/min/min (1/min^2)
11 mm/sec 31 A(p)
12 mm/min 32 Hz
13 m/sec 33 %
14 m/min 34 pulse
15 inch/sec 35 bit
16 inch/min 36 --
17 Deg/sec 37 unknown
18 Deg/min
19 1/sec
20 1/min
* () It is displyed on screens of 7 soft key type.
Previous page
Next page

Contents Summary of FS16i/18i/21i-TB/MB Servo Guide Mate Specification (Draft) Additional Manual
