15
/
131
FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
SAMPLING CYCLE (SERVO)
SAMPLING CYCLE (SPINDLE)
The sampling cycle of the meassurement is set.
It sets individually with the servo axis and the spindle axis. In the case that the sampling
cycle is different between the servo and spindle, the long setting data of sampling cycle
interpolated the straight line.
Accordingly, the sampling cycle without becoming the integral multiple like 2msec and
5msec can not measure the data.
And, in case of setting less than 1msec or 8msec, the data is set up by integral multiple,
and the integral multiple data is set to measurement score.
In other words, when data is set like 1msec and 250µsec, the setting value must be
multiple of 4.
Attention)
When a different sampling cycles with servo axis and spindle axis are set up, a
measurement data score means a data score in the short sampling cycle, and data
scores in the long sampling cycle decrease in accordance with the ratio of the sampling
cycle.
Previous page
Next page

Contents Summary of FS16i/18i/21i-TB/MB Servo Guide Mate Specification (Draft) Additional Manual

  • Page 1FANUC Series 16i /18i /21i – TB / MB SERVO GUIDE Mate Specification 1 OUTLINE ...................................................................................................................................................................4 1.1 MEASUREMENT AND DRAWING .............................
