FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
Number Data
14556
Y-T graph computation (Draw1)
14557
Y-T graph computation (Draw2)
14558
Y-T graph computation (Draw3)
14559
Y-T graph computation (Draw4)
Data type : Byte
Number Data
14560
Y-T graph input 1 (Draw1)
14561
Y-T graph input 1 (Draw2)
14562
Y-T graph input 1 (Draw3)
14563
Y-T graph input 1 (Draw4)
Data type : Byte
Number Data
14564
Y-T graph input 2 (Draw1)
14565
Y-T graph input 2 (Draw2)
14566
Y-T graph input 2 (Draw3)
14567
Y-T graph input 2 (Draw4)
Data type : Byte
Number Data
14568
Y-T graph display unit (Draw1)
14569
Y-T graph display unit (Draw2)
14570
Y-T graph display unit (Draw3)
14571
Y-T graph display unit (Draw4)
Data type : Byte
Previous page
Next page
