  2. FS16i/18i/21i-TB/MB Servo Guide Mate Specification (Draft)

FS16i/18i/21i-TB/MB Servo Guide Mate Specification (Draft) Additional Manual Page 109

Additional Manual
Ed.
Ed.Ed.
Ed. Date
DateDate
Date Design
DesignDesign
Design Description
DescriptionDescription
Description
Date
DateDate
Date 2003.03.07 Desig.
Desig.Desig.
Desig. Kageyama Apprv.
Apprv.Apprv.
Apprv.
109
/
131
FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
Screen Data type Decimal point Correspondence range
H-CENTER DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
V-CENTER DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
RADIUS DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
DIVISION DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
SCALE (CIRCLE)
ZOOM DWORD The 3rd decimal point
(fixation)
1.0∼99999.999
ORIGIN ( GAIN ) DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
DIVISION ( GAIN ) DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
ORIGIN ( PHASE ) DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
DIVISION ( PHASE ) DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
MIN ( FREQ ) DWORD The 3rd decimal point
(fixation)
0∼99999.999
SCALE (FOURIER)
MAX ( FREQ ) DWORD The 3rd decimal point
(fixation)
0∼99999.999
