FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
The details of the kind (servo) is as follows.
Selecting
number
Symbol Contents (the explanation screen display) Remarks
1 VCMD Velocity command ( VCMD )
Default physical value is 3750(min-1), but if the axis is using Linear Motor, the value
depends on the resolution of position encoder
2 TCMD Torque command ( TCMD )
Physical value is need to set max. current(Ap) of amplifier. Default value is 100 in
convention which convert measured data to percent by max. torque.
3 SPEED Motor speed ( SPEED )
Default physical value is 3750(min-1), but if the axis is using Linear Motor, the value
depends on the resolution of position encoder.
4 ERR Position error
Physical value is need to set the length per pulse. This data means error for CNC
command without depending on FAD setting.
5 POSF Position feedback integrated value
A conversion coefficient sets up the movement distance of around the 1 pulse.
7 SYNC Synchronize error
Default physical value is 1(pulse). And synchronize error 4096 pulses is equivalent
to 1 rotation of main-axis.
8 ABS PULSECODER position(2^21p/rev)
Physical value is need to set the length per 1 rotation of motor.
15 FREQ Vibration Frequency
16 FRTCM Vibration Torque command
20 ROTOR Rotor position [theta] of the servo motor
21 SIN_T Sine theta (theta is rotor position)
22 DTRQ Disturbance torque
Physical value is need to set max. current (Ap) of amplifier.
23 SFERR Semi-Full error
24 DLTCM TCMD Substraction
Substraction of torque command between master-axis and slave-axis
25 OVCLV OVC level ( % )
48 IR R-phase current(Ir)
Physical value is need to set max. current (Ap) of amplifier. Default value is 100 in
convention which convert measured data to percent by max. current.
49 IS S-phase current(Is)
Physical value is need to set max. current (Ap) of amplifier. Default value is 100 in
convention which convert measured data to percent by max. current
50 IEFF Effective current
Physical value is need to set max. current (Ap) of amplifier. Default value is 100 in
convention which convert measured data to percent by max. current.
