FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
Number Data
14572
Y-T graph coordinate change choice (Draw1)
14573
Y-T graph coordinate change choice (Draw2)
14574
Y-T graph coordinate change choice (Draw3)
14575
Y-T graph coordinate change choice (Draw4)
Data type : Byte
Number Data
14576
Y-T graph angle of inclination (Draw1)
14577
Y-T graph angle of inclination (Draw2)
14578
Y-T graph angle of inclination (Draw3)
14579
Y-T graph angle of inclination (Draw4)
Data type : Double word
Number Data
14580
X-Y graph computation (Draw1)
14581
X-Y graph computation (Draw2)
Data type : Byte
Number Data
14582
X-Y graph input 1 (Draw1)
14583
X-Y graph input 1 (Draw2)
Data type : Byte
Number Data
14584
X-Y graph input 2 (Draw1)
14585
X-Y graph input 2 (Draw2)
Data type : Byte
Previous page
Next page

Contents Summary of FS16i/18i/21i-TB/MB Servo Guide Mate Specification (Draft) Additional Manual
