FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
6.2 Data that is set with input from the setting screen
Screen Data type Decimal point Correspondence range
DATA POINTS DWORD No decimal point
2∼10000
MEASURE SETTING
TRIGGER SEQ.NO DWORD No decimal point
0∼99999
CONV. COEF DWORD The 3rd decimal point
(fixation)
-99999.999∼99999.999
(But, it can't be inputted by 0.)
CONV. BASE DWORD The 3rd decimal point
(fixation)
-99999.999∼99999.999
(But, it can't be inputted by 0.)
SET CHANNEL
ORIGIN VALUE DWORD The 3rd decimal point
(fixation)
-99999.999∼99999.999
OPERATION & GRAPH (Y-Time)
Setup screen
( deg ) DWORD The 3rd decimal point
(fixation)
-99999.999∼99999.999
OPERATION & GRAPH (XY)
Setup screen
( deg ) DWORD The 3rd decimal point
(fixation)
-99999.999∼99999.999
OPERATION & GRAPH (CIRCLE)
Setup screen
( deg ) DWORD The 3rd decimal point
(fixation)
-99999.999∼99999.999
ORIGIN (Draw) DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
DIVISION(Draw) DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
ORIGIN(Time) DWORD The 3rd decimal point
(fixation)
-99999.999∼99999.999
SCALE ( Y-Time )
DIVISION(Time) DWORD The 3rd decimal point
(fixation)
0∼99999.999
ORIGIN (HORIZ) DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
DIVISION (HORIZ) DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
ORIGIN (VERTI) DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
SCALE ( XY )
DIVISION (VERTI) DWORD Dependent on 2000#0
(PLC)
By 8 digits of maximum 9,
decimal point position variability
Previous page
Next page
