FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
The details of the kind (spindle) is as follows.
Selecting
number
Symbol Contents (the explanation screen display) Remarks
1 SPEED Motor speed
4096pulse is equal to 1(min-1).
2 INORM Motor current
3 TCMD Torque command
16384pulse is equal to 100% current.
4 VCMD Velocity command
4096pulse is equal to 1(min-1).
5 VERR Velocity error
4096pulse is equal to 1(min-1).
7 PERR1 Position error(2~24p/rev)
8 ORERR Position error in orientation(2~24p/rev)
9 PCPOS Position feedback(2~24p/rev)
16384pulse/rev with alpha amplifier
*１
10 MCMD Motion command per 8msec
Cs mode: 360,000pulse/rev
Other : 4096pulse/rev
11 PERR2 Position error
Cs mode: 360,000pulse/rev
Other : 4096pulse/rev
13 CSPOS Position feedback(360,000p/rev)
*１
14 SPCMD Speed command from CNC
16384pulse is equal to maximum speed parameter(No.4020).
15 SPCT1 Spindle axis control signal 1
16 SPCT2 Spindle axis control signal 2
17 SPST1 Spindle axis status signal 1
18 SPST2 Spindle axis status signal 2
19 ORSEQ Sequence data of orientation
20 FREQ Vibration Frequency
21 FRTCM Vibration Torque command
*１ … It can be selected at Spindle old SIC mode.
Input condition
1) The number that is displayed on the candidate can be selected.
