Servo Motor Beta Series (I/O Link Option) Maintenance manual Page 206

Maintenance manual
B--65245EN/02
B. PARAMETERSAPPENDIXES
185
021 Feedrate command weight N
Size : 1 byte
Unit :
Range :0to8
Standard value :3
Description : Sets up a weight for feedrate parameter Nos. 40, 41,
43 to 50, 54, 59 to 61. Supposing 3 is specified, the
feedrate is assumed to be a parameter--specified
feedrate multiplied by 10
3
(= 1000).
040 Rapid traverse rate
Size : 2 bytes
Unit :10
N
user--specified unit/MIN
Range : 1 to 65535 (7500 user--specified units/MIN or
greater)
Standard value : 4000
Description : Specifies a rapid traverse rate. (N is specified in
parameter No. 21.)
041 Jog feedrate
Size : 2 bytes
Unit :10
N
user--specified units/MIN
Range : 1 to 65535 (4 user--specified units/MIN or greater)
Standard value : 2000
Description : Specifies the feedrate for job feed when the feedrate
override value is 100%. (N is specified in parameter
No. 21.)
043 Feedrate upper limit
Size : 2 bytes
Unit :10
N
user--specified units/MIN
Range : 1 to 65535
Standard value : 4000
Description : Specifies the upper limit for the feedrate to be
specified. If an attempt is made to specify a value
larger than the upper limit, the actual feedrate is
clamped to the upper limit. (N is specified in
parameter No. 21.)
B.3
FEEDRATE
PARAMETERS
