2. SIGNAL DESCRIPTIONS

B--65245EN/02

HANDLING

Group Reference

Address

SymbolSignal nameGroup Reference

Direct

command

Peripheral

equipment

SymbolSignal name

Operation completion signal

OPC1,OPC2,

OPC3,OPC4

Xx+0#4 to

Xx+0#7

-- -- 2.3.13

Function code CMD CODEP

Yy+2#4 to

Yy+2#7

-- -- 2.3.13

Command data 1 CMD DATA1

Yy+2#0 to

Yy+2#3

-- -- 2.3.13

Command data 2 CMD DATA2 Yy+3 to Yy+6 -- -- 2.3.13

Response data ANS DATAP Xx+3 to Xx+6 -- -- 2.3.13

Response data check signal DSP1,DSP2

Xx+2#4,

Xx+2#5

-- -- 2.3.13

Response data write completion signal ABSWT Xx+1#0 -- -- 2.3.13

Response data read completion signal ABSRD Yy+1#4 -- -- 2.3.13

Alarm output command signal DSAL Yy+0#3 -- -- 2.3.13

Alarm output state check signal DSALO Xx+2#3 -- -- 2.3.13

Function code command strobe signal EBUF -- -- Yy+4#7 2.3.14

Function code command read completion

signal

EBSY -- -- Xx+4#7 2.3.14

Function code CMD CODE -- -- Yy+5 2.3.14

Command data CMD DATA -- -- Yy+6 to Yy+15 2.3.14

Response data ANS DATA -- -- Xx+7 to Xx+15 2.3.14

Continuously output data signal EOPC -- -- Xx+4#2 2.3.14

Response data readable signal EOSTB -- -- Xx+4#6 2.3.14

Response data read completion signal EOREND -- -- Yy+4#6 2.3.14

Command continuation notification signal ECNT -- -- Yy+4#0 2.3.14

PMM data signal USR1 -- -- Xx+4#3 2.3.14

Response data continuation notification

signal

ECONT -- -- Xx+4#0 2.3.14

Function code command completion

notification signal

ECF -- -- Xx+4#5 2.3.14

Alarm signal DAL -- -- Xx+4#1 2.3.14

Wait signal WA T -- -- Xx+1#0 2.3.14

Wait completion signal WFN -- -- Yy+1#4 2.3.14

Memory registration signal INPF -- -- Yy+3#7 2.3.14

Memory registration in--progress signal INPFO -- -- Xx+3#7 2.3.14

Interface switch signal DRC -- -- Yy+1#5 2.3.14

Interface status notification signal DRCO -- -- Xx1#1 2.3.14

Emergency stop signal *ESP Direct input 2.3.15

Overtravel signal *-- O T, *+OT Direct input 2.3.15

High--speed interlock signal *RILK Direct input 2.3.15

Deceleration signal for reference position

return

*DEC Direct input 2.3.15
