Servo Motor Beta Series (I/O Link Option) Maintenance manual Page 268

Maintenance manual

Page of 317

/ 317

Edit.

5/13

Date Signature Change

FANUC SERVO MOTOR BETA series I/O

Link Option Add function in edition 09

B-65245EN/02-01

2. In-position check in cutting feed

2.1.

2.1.2.1.

2.1.

Outline

Outline Outline

Outline

In the conventional specifications, the in-position check is only valid in rapid traverse. In the

new specifications, it is valid in cutting feed too. The in-position check in cutting feed is only

executed in absolute positioning command or incremental positioning command of direct

commands

2.2.

2.2.2.2.

2.2.

Detail

Detail Detail

Detail

The signal “SMZX” is added to the instruction command Yy+7#5 of absolute positioning

command (function code 0x61) or incremental positioning command (function code 0x62) of

direct commands. But the signal “SMZX” is valid when the parameter No.002#7 (CSMZ) is set

to “1”. When execution of in-position check is specified in the direct command, the in-position

check width can be selected by the parameter CIPC (No.002#3) in no relation to whether the

mode in next block is rapid traverse or cutting feed.

The format of the instruction command is as follows.



#7 #6 #5 #4 #3 #2 #1 #0

+4 Control flag 1

+5 01100001

+6 0000NMOD001

+7 0RPDSMZX00001

+8 FEED RATE

+9 FEED RATE

+10 DISTANCE

+11 DISTANCE

+12 DISTANCE

+13 DISTANCE



0x61


