2. HARDWARE

B–62755EN/01

182

The LCD backlight must be replaced periodically. Replace the unit in

which the LCD backlight is mounted.

The LCD backlight has a life of about 10,000 hours (5,000 hours

guaranteed). (During its lifetime, the backlight should maintain a

brightness exceeding 50% of that when new.)

Upon reaching the end of its service life, the LCD backlight unit must be

replaced. The unit can be replaced either by the user or by a FANUC

service engineer.

Remark) When the screen display is not required, the display and

backlight can be turned off by pressing a key.

Doing so will increase the useful life of the backlight.

Suppressing the screen display

While holding down the

CAN

key, press any function key

(for example, the

POS

key).

Restoring the screen display

Press any function key (for example, the

POS

key).

2.14

REPLACING THE LCD

BACKLIGHT
