9. TROUBLESHOOTING (SERIAL INTERFACE SPINDLE)

397

Item Cause of trouble Check procedure Remedy

Defective of power

transistor used for

power

Check power transistor. Replace power transistor.

Defective of power

regeneration circuit

Replace PCB.

Item Cause of trouble Check procedure Remedy

Motor constrained Check that nothing is

preventing the motor from

accelerating.

Remove cause.

Defective motor

speed feedback

signal

Check signal waveform.

(Alarm No. 2)

Remove cause.

Defective motor

speed feedback

signal cable

Check that cable is con-

nected securely to con-

nector.

Check that cable is not

broken.

Connect cable securely.

Replace cable.

Item Cause of trouble Check procedure Remedy

Defective LSI used in

serial data transmis-

sion

Replace LSI.

Replace PCB.

Item Cause of trouble Check procedure Remedy

Defective relay used

in DC link rechar-

ging.Disconnection of

resistor used in limit-

ing re-charge current

Check relevant parts. Replace amp.

Item Cause of trouble Check procedure Remedy

Incorrect parameter

setting

Check if specified param-

eter value is beyond al-

lowable range of values.

Specify value within allow-

able range.

and are alternately displayed in the spindle amplifier

indicator section if an AL–34 alarm is raised.

“XXX” indicates the data number internal to the spindle for a parameter

where a value beyond the allowable range is specified.

AL–34

F–XXX

Item Cause of trouble Check procedure Remedy

Parameter data of

gear ratio and posi-

tion gain are too

large.

Check gear ratio and

position gain data.

Change to suitable values.

AL–30 Input circuit

overcurrent

AL–31 Speed detection

signal

disconnection

motor restraint

alarm

AL–32 Abnormality in

RAM internal to

LSI for serial data

transfer

AL–33 Insufficient DC

link section

charging

AL–34 Parameter data

setting beyond

allowable range

of values

AL–35 Excessive gear

ratio data setting
