1. DISPLAY AND OPERATION OF CRT/MDI

B–62755EN/01

OVL0200

OVC

HCA

HVA

DCA

FBA

OFA

DGN

#7(OVL): Overload alarm

#6(LV): Insufficient voltage alarm

#5(OVC): Over current alarm

#4(HCA): Abnormal current alarm

#3(HVA): Overvoltage alarm

#2(DCA): Discharge alarm

#1(FBA): Disconnection alarm

#0(OFA): Overflow alarm

ALD0201

#6 #5 #4

EXP

#3 #2 #1 #0

DGN

Overload

0 – – – Motor overheat

alarm

1 – – – Amplifier overheat

Disconnec-

ti l

1 – – 0 Built–in pulse coder (hand)

tion alarm

1 – – 1 Disconnection of separated type pulse

coder (hard)

0 – – 0 Disconnection of pulse coder (software)

RAM0204

OFS

MCC

LDA

PMS

#2 #1 #0

DGN

#6(OFS): Abnormal current value result of A/D conversion of digital

#5(MCC): Contacts of MCC of servo amplifier is melted.

#4(LDA): Serial pulse coder LED is abnormal

#3(PMS): Feedback is not correct due to faulty serial pulse coder C or feedback

cable.

This data indicates the cause of servo alarm No. 417, detected by the NC.

If the alarm is detected by the servo, the PRM bit (bit 4 of DGN No. 0203)

is set to 1.

0280

AXS

#5 #4

DIR

PLS

PLC

#1 #0

MOT

#0 (MOT): The motor type specified in parameter No. 2020 falls outside the

predetermined range.

#2 (PLC): The number of velocity feedback pulses per motor revolution, specified in

parameter No. 2023, is zero or less. The value is invalid.

#3 (PLS): The number of position feedback pulses per motor revolution, specified in

parameter No. 2024, is zero or less. The value is invalid.

#4 (DIR): The wrong direction of rotation for the motor is specified in parameter No.

2022 (the value is other than 111 or –111).

#6 (AXS): In parameter No. 1023 (servo axis number), a value that falls outside the

range of 1 to the number of controlled axes is specified. (For example, 4 is

specified instead of 3.) Alternatively, the values specified in the

parameter are not consecutive.

D Details of digital servo

alarm 414

D Detail of digital servo

alarm 417
