Series 16i/160i - LA Descriptions Page 10

Descriptions
2.SPECIFICATIONS B-63192EN/03
- 4 -
Item Specifications
C series
Y series
YP series
Exact stop G09
Linear interpolation
Circular interpolation Supported for multiple quadrants
Exponential interpolation
Dwell
Polar coordinate interpolation
Cylindrical interpolation
Helical interpolation
(Circular interpolation) + (Linear interpolation
for up to 2 axes)
Hypothetical axis interpolation
Skip G31
Reference position return G28
Reference position return check G27
2nd reference position return
3rd/4th reference position return
Floating reference position return
Normal-direction control
High-speed linear interpolation
Feed function
Item Specifications
C series
Y series
YP series
Rapid traverse rate Max. 240 m/min (1µm)
Rapid traverse override F0, 25, 50, 100%
Feed per minute
Tangential speed constant control
Cutting feedrate clamp
Automatic acceleration/deceleration
Rapid traverse : linear
Cutting feed : exponential
Rapid traverse bell-shaped acceleration/
deceleration
Positioning by optimum acceleration
Linear acceleration/deceleration after cutting
feed interpolation
Bell-shaped acceleration/deceleration after
cutting feed interpolation
Linear acceleration/deceleration before cutting
feed interpolation
Feedrate override 0% to 254%
2nd feedrate override 0% to 254%
Jog override 0% to 655.34%
Override cancel
External deceleration
Feed stop
Advanced preview control
High-precision contour control A 64-bit RISC engine is used.
Program input
Item Specifications
C series
Y series
YP series
Tape code EIA RS244/ISO840 automatic recognition
Label skip
Parity check Horizontal parity, vertical parity
