Series 16i/160i - LA Descriptions Page 11

Descriptions
B-63192EN/03 2.SPECIFICATIONS
- 5 -
Item Specifications
C series
Y series
YP series
Control in/out
1 block
Optional block skip
9 blocks
Maximum value ± with 8 digits
O with 4 digits
Program number
O with 8 digits *1
Sequence number N with 5 digits
Absolute/incremental programming
Combined programming in a single block
allowed
Decimal point input/pocket calculator type
decimal point input
*1
Input unit (10 times)
Plane selection G17, G18, G19
Rotary axis designation
Rotary axis roll-over
Polar coordinate command
Coordinate system setting
Automatic coordinate system setting
Workpiece coordinate system G52 to G59
Workpiece coordinate system preset
48 sets
Addition of workpiece coordinate systems
300 sets
Manual absolute on/off
Optional-angle chamfering/corner rounding
Programmable data input G10
Subprogram call Four levels of nesting
Custom macro B
Addition of custom macro common variables #100 to #199, #500 to #999
Pattern data input *1
Interrupt-type custom macro
Radius designation on arc
Radius designation on arc with 9 digits
Automatic corner override
Automatic corner deceleration
Feedrate clamp by arc radius
Scaling
Coordinate system rotation
Programmable mirror image
Figure copy
Retrace
Tape format for FS15
Macro executor Max. 4MB *1
C language executor Max. 4MB *1
Auxiliary function
Item Specifications
C series
Y series
YP series
Auxiliary function M with 8 digits
2nd auxiliary function B with 8 digits
Auxiliary function lock
High-speed M/T/B interface
Multiple commands of auxiliary function 3
