Series 16i/160i - LA Descriptions Page 15

Descriptions
B-63192EN/03 2.SPECIFICATIONS
- 9 -
Item Specifications
C series
Y series
YP series
Three-dimensional conversion function
Teaching function
Spline interpolation function
Others
Item Specifications
C series
Y series
YP series
Status output signal
NC ready, servo ready, automatic operation,
reset, alarm, etc.
7.2″ monochrome LCD *1
9.5″ monochrome LCD *1
8.4″ color LCD *1
LCD-mounted type display unit
10.4″ color LCD
Without optional slot (60 mm)
With 2 optional slots (110 mm)Control unit optional slots (depth)
With 4 optional slots (170 mm)
Stand-alone type MDI for 7.2″/8.4″ LCD
(small) *1
Stand-alone type MDI for 7.2″/8.4″ LCD
(standard) *1
Stand-alone type MDI for 9.5″/10.4″ LCD
(standard, horizontal type) *1
Stand-alone type MDI for 9.5″/10.4″ LCD
(standard, vertical type) (10.4″ LCD for the
Series 160i/180i)
Stand-alone type MDI for 10.4″ LCD (PC
key, vertical type) *2
MDI unit
Touch panel (only for 10.4″ LCD)
PMC-SB6 (basic instruction : 0.085µsec/step)
Maximum number of ladder steps : 32,000
Step sequence function
PMC-Si (basic instruction : 0.085µsec/step)
Maximum number of ladder steps : 32,000
Conforming to IEC1131-3
Max. 2MB (PMC-SB6 required)
PMC C language
Battery-powered memory expansion
I/O unit A
I/O unit B
Operator’s panel I/O module
Connector panel I/O module
Power magnetics cabinet I/O module
Machine interface (I/O link)
Max. DI/DO points : 1024/1024
User : 768/768
Laser : 256/256
Standard machine operator’s panel (FS0
type)
Manual pulse generator
Pendant manual pulse generator
With axis selection switch and magnification
selection switch
Cordless manual pulse generator Used in Japan only
Applicable servo motor FANUC AC Servo Motor α series
Applicable servo amplifier FANUC Servo Amplifier α series
Separate pulse coder
Position detector interface unit
(for full-closed control)
2-phase pulse interface for linear optical
scale
Linear scale interface with absolute addressing
reference mark
Control unit supply voltage 24VDC ±10%
