2.SPECIFICATIONS B-63192EN/03
- 2 -
2 SPECIFICATIONS
For functions other than the laser functions, refer to "FANUC Series
16i/18i/21i/20i/160i/180i/210i-MODEL A Descriptions" (B-
63002EN).
Some functions described in manual B-63002EN may not be
supported by the 16i-LA/160i-LA or may differ from those of this
model.
The following table lists the functions supported by the 16i-LA.
Any functions not listed below are not supported by the 16i-LA.
: Standard specifications
: Standard optional specifications
: Not applicable
: Specifications included in other specifications
* : Specifications included in other specifications
*1 : Valid only for the 16i-LA
*2 : Valid only for the 160i-LA
NOTE
Some combinations of optional specifications are
restricted.
Axis control
Item Specifications
C series
Y series
YP series
Controlled axes 3 axes
Controlled axes expansion Max. 8 axes
Simultaneously controlled axes 3 axes
Simultaneously controlled axes expansion Max. 6 axes
Axis control by PMC Max. simultaneous 4 axes
Axis name
3 basic axes: X, Y, Z;
Additional axes: U, V, W, A, B, or C
Simple synchronous control 4 pairs
Tandem control
Torque control PMC axis control required * *
Controlled axes detach
Least input increment 0.001mm, 0.001deg, 0.0001inch
Flexible feed gear Optional DMR
Fine acceleration/deceleration
HRV control
Inch/metric conversion
Interlock
All axes/each axis/each axial direction/start
block/cutting block start
Machine lock All axes/each axis
Emergency stop
