Series 16i/160i - LA Descriptions Page 9

Descriptions
B-63192EN/03 2.SPECIFICATIONS
- 3 -
Item Specifications
C series
Y series
YP series
Overtravel
Stored stroke check 1
Stored stroke limit external setting
Stored stroke check 2
Stored stroke check 3
Stroke limit check before travel
Mirror image Each axis
Follow-up
Servo-off/mechanical handle
Backlash compensation
Separate backlash compensation for rapid
traverse and cutting feed
Stored pitch error compensation
Straightness deviation compensation
Position switch
Abnormal load detection
Fine torque sensing *1
Operation
Item Specifications
C series
Y series
YP series
Automatic operation (memory)
DNC operation Reader/punch interface required * *
MDI operation
Scheduling function *1 * *
Program number search
Sequence number search
Sequence number collation stop
Program restart
Manual interruption and recover
Buffer register
Dry run
Single block
Jog feed
Manual reference position return
Reference position setting without DOG
Butt-type reference position setting
Reference position shift
1 unit
Manual handle feed
2 or 3 units
Manual handle feed rate
×1, ×10, ×m, ×n
m = 0 to 127, n = 0 to 1000
**
Manual handle interruption
Incremental feed ×1, ×10, ×100, ×1000
Jog/handle simultaneous mode
Interpolation
Item Specifications
C series
Y series
YP series
Positioning
G00 (linear interpolation type positioning is
possible)
Unidirectional positioning G60
Exact stop mode G61
