Dual Check Safety Operators manual Page 109

Operators manual
B-64004EN/02 6.PARAMETERS
- 101 -
These parameters specify the control-axes numbers corresponding to
the 1st thorough 64th safe position switch functions. A corresponding
position switch signal is output to “I/O Link#1 or #2” and “I/O Link#3,
#4 or Profibus-DP” when the machine coordinate value of a
corresponding axis is within the range that is set using a parameter.
WARNING
1 Set 0 for those position switch numbers that are
not to be used. (The safe position switch signal of
that number is not output.)
2 The safe position switch signal for the axis whose
parameter No.1904#6 is 1 (Dual Check Safety is
disabled) is not output.
3 After safety position switch parameters No.13880
to No.13911, No.10501 to No.10532 have been
set, the power must be turned off then back on for
the setting to become effective
13920 Maximum operation range of the 1st safe position switch
13921 Maximum operation range of the 2nd safe position switch
:
13950 Maximum operation range of the 31st safe position switch
13951 Maximum operation range of the 32nd safe position switch
10533 Maximum operation range of the 33rd safe position switch
10534 Maximum operation range of the 34th safe position switch
:
10563 Maximum operation range of the 63rd safe position switch
10564 Maximum operation range of the 64th safe position switch
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
[Input type] Parameter input
[Data type] Real
[Unit of data] mm, inch, degree (machine unit)
[Minimum unit of data] Depend on the increment system of the reference axis
[Valid data range] 9 digits of minimum unit of data (Refer to standard parameter setting
table(A). But in case that CMR≥1, data range becomes 1/CMR of 9
digits of minimum unit of data.)
(When the increment system is IS-B and CMR=1, -999999.999 to
+999999.999)
(When the increment system is IS-B and CMR=2, -499999.999 to
+499999.999)
