Dual Check Safety Operators manual Page 111

Operators manual
B-64004EN/02 6.PARAMETERS
- 103 -
[Valid data range] 9 digits of minimum unit of data (Refer to standard parameter setting
table(A). But in case that CMR≥1, data range becomes 1/CMR of 9
digits of minimum unit of data.)
(When the increment system is IS-B and CMR=1, -999999.999 to
+999999.999)
(When the increment system is IS-B and CMR=2, -499999.999 to
+499999.999)
NOTE
Whether to specify this parameter by using a
diameter value or radius value depends on whether
the corresponding axis is based on diameter
specification or radius specification.
These parameters set the minimum operation range of the 1st through
64th safe position switches.
CAUTION
1 When the machine position is on the boundary of
the specified ranges (machine position =
parameter setting value), it is considered within the
specified ranges.
2 When the setting of operation range is “maximum
operation range < minimum operation range”, the
safe position switch is not output.
3 If parameter No.13960 to No.13991, No.10565 to
No.10596 are changed, please turn the power of
the machine off once.
