FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
137/190
3 Parameter
3.1 Introduction
It is indispensable to set the following parameters to use AI HPCC / AI NANO
HPCC function.
Content Parameter number Reference item
Control axes number 7510 3.2
Setting of RISC board 8485 3.2
Setting of
acceleration/deceleration
before interpolation
8402#5,#4 3.13
Setting of automatic
feedrate control function
8459#1,#0 3.14
3.2 Axis control / Incremental System
1031 Standard axis
[Data type] Byte
[Valid data range] 1, 2, 3, …to the maximum number of control axes
Some of parameters for AI contour control / AI NANO contour control are
specified to all axes in common. Some of their parameters change the unit
according to increment system.
The unit of the above-mentioned parameters is tuned to the axis set in this
parameter.
7510 Maximum number of axes in AI HPCC / AI NANO HPCC
[Data type] Byte
[Valid data range] 1, 2, 3, …to the maximum number of control axes
This parameter specifies the maximum number of axes to controlled by AI HPCC
/ AI NANO HPCC.
Example)
Axis configuration is X, Z, C, Y, and A from the 1st axis in this order and to make
AI HPCC / AI NANO HPCC valid to the 4th axis (Y), set this parameter to 4. In
this case, AI HPCC / AI NANO HPCC is also effective for the X, Z, C axes.
X, Z, C, Y axis : AI HPCC / AI NANO HPCC is available
A axis : AI HPCC / AI NANO HPCC is not available.
#7 #6 #5 #4 #3 #2 #1 #0
8480 RI2 RI1 RI0
[Data type] Bit
These parameters have to be set to “1”.
#7 #6 #5 #4 #3 #2 #1 #0
1602 G8S
[Data type] Bit
(4)
