3.5 Tool Length Compensation
#7 #6 #5 #4 #3 #2 #1 #0
5001 EVR TAL TLB TLC
[Data type] Bit
TLC Tool length compensation
0: Tool length compensation A or B (Conforms to parameter TLB)
1: Tool length compensation C.
TLB Tool length compensation axis
0: Always Z axis irrespective of plane specification (Tool length compensation A)
1: Axis perpendicular to plane specification (G17, G18, and G19) (Tool length
compensation B).
TAL Tool length compensation C
0: Generates an alarm when two or more axes are offset
1: Not generate an alarm even if two or more axes are offset
EVR When a tool length compensation value is changed in compensation mode:
0: Enables the change, starting from that block where the next H code is
specified.
1: Enables the change, starting from that block where buffering is next
performed.
#7 #6 #5 #4 #3 #2 #1 #0
5006 TOS
[Data type] Bit
TOS Select type of tool length compensation
0: Tool length compensation by axis movement.
1: Tool length compensation by coordinate shift.
