FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
57/190
In case of commanding G18 (Z-X plane) or G19 (Y-Z plane)
− After commanding G43.4, Z-X plane is chosen by G18 command or Y-Z plane is
chosen by G19 command, and the circular interpolation is performed while C
axis is not rotated.
( Including the case of C axis moving before commanding G43.4 )
→ The circular interpolation is available since this comes under the above-
mentioned (2).
− After commanding G43.4, Z-X plane is chosen by G18 command or Y-Z plane is
chosen by G19 command, and C axis is rotated while the circular interpolation
is performed.
→ P/S alarm 5421 occurs since this is against the above-mentioned (2).
− After commanding G43.4, Z-X plane is chosen by G18 command or Y-Z plane is
chosen by G19 command, and the circular interpolation is performed after C
axis is rotated.
→ P/S alarm 5421 occurs since this is against the above-mentioned (2).
:
(G01 C90. ;)
G43.4 H1 ;
G18 G02 IP IR B10. ;
:
:
G43.4 H1 ;
G18 G02 IP IR C20. ;
:
:
G43.4 H1 ;
G01 C10.
G18 G02 IP IR ;
:
