FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
170/190
3.15 Optimum Torque Acceleration/Deceleration
#7 #6 #5 #4 #3 #2 #1 #0
19540 FAP
[Data type] Bit
FAP Optimum torque acceleration/deceleration is:
0: Disabled.
1: Enabled.
By setting both FAP, bit 0 of parameter No. 19540, and FRP, bit 5 of parameter
No. 19501, to 1 and setting parameter to determine the reference acceleration
(No. 1420 and No.1773 ) as below, the acceleration/deceleration for rapid
traverse in AI HPCC / AI NANO HPCC mode will be optimum torque
acceleration/deceleration. When Optimum torque acceleration/deceleration is
enabled, linear type positioning for rapid traverse is selected automatically in AI
HPCC / AI NANO HPCC mode even if the parameter LRP, bit 1 of parameter No.
1401, is set to 0 (nonlinear type is selected). If rapid traverse is subject to
optimum torque acceleration/deceleration, after-interpolation
acceleration/deceleration does not apply to rapid traverse.
The optimum torque acceleration/deceleration does the de-and acceleration
according to the acceleration pattern set in the parameter. The acceleration
pattern is set by parameter No.19541-No.19568.
#7 #6 #5 #4 #3 #2 #1 #0
19501 FRP
[Data type] Bit
FRP Acceleration/deceleration for rapid traverse in AI HPCC / AI NANO HPCC mode
is:
0: Acceleration/deceleration after interpolation.
1: Acceleration/deceleration before interpolation.
By setting both parameter bit FRP, bit 5 of parameter No.19501, and FAP, bit 0
of parameter No.19540, to 1 and setting the reference acceleration parameter
(No. 1420 and No.1773) for any one axis to a non-zero value, the
acceleration/deceleration for rapid traverse in AI HPCC / AI NANO HPCC will
be optimum torque acceleration / deceleration. When Optimum torque
acceleration/deceleration is enabled, linear type positioning for rapid traverse is
selected automatically even if the parameter LRP, bit 1 of parameter No. 1401, is
set to 0 (nonlinear type is selected).
Please set ‘1’ in this parameter to use optimum acceleration/deceleration
function.
#7 #6 #5 #4 #3 #2 #1 #0
19504 HRB
[Data type] Bit
HRB Acceleration/deceleration for rapid traverse in AI HPCC / AI NANO HPCC mode
is:
0: Linear acceleration/deceleration.
1: Bell-shaped Acceleration/deceleration.
Bell-shaped acceleration/deceleration is selected by setting this parameter to 1
and the acceleration change time of bell-shaped acceleration/deceleration is set
to parameter No.1774.
