FANUC Series 16i /18i Additional Manual Page 174

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
174/190
19557
Optimum torque acceleration/deceleration (acceleration at P0 during
movement in + direction and deceleration)
19558
Optimum torque acceleration/deceleration (acceleration at P1 during
movement in + direction and deceleration)
19559
Optimum torque acceleration/deceleration (acceleration at P2 during
movement in + direction and deceleration)
19560
Optimum torque acceleration/deceleration (acceleration at P3 during
movement in + direction and deceleration)
19561
Optimum torque acceleration/deceleration (acceleration at P4 during
movement in + direction and deceleration)
19562
Optimum torque acceleration/deceleration (acceleration at P5 during
movement in + direction and deceleration)
19563
Optimum torque acceleration/deceleration (acceleration at P0 during
movement in - direction and deceleration)
19564
Optimum torque acceleration/deceleration (acceleration at P1 during
movement in - direction and deceleration)
19565
Optimum torque acceleration/deceleration (acceleration at P2 during
movement in - direction and deceleration)
19566
Optimum torque acceleration/deceleration (acceleration at P3 during
movement in - direction and deceleration)
19567
Optimum torque acceleration/deceleration (acceleration at P4 during
movement in - direction and deceleration)
19568
Optimum torque acceleration/deceleration (acceleration at P5 during
movement in - direction and deceleration)
[Data type] Word axis
[Unit of data] 0.01 %
[Valid data range] 0 to 32767
The accelerations at P0 to P5 are to be set with acceleration parameters Nos.
19545 to 19568 as ratios to the reference acceleration. If any of the acceleration
parameters Nos. 19545 to 19568 is set to 0, the acceleration is assumed 100%.
Acceleration parameters should be set to 0 at the acceleration setting point
whose speed parameter is set to 0.
If this function is enabled and both parameter No.1773 and No. 1620 for an axis
are set to 0, the following values are assumed as the reference acceleration for
that axis:
1000.0 mm/sec
2
, 100.0 inch/sec
2
, 100.0 degrees/sec
2
