FANUC Series 16i /18i Additional Manual Page 148

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
148/190
19685 Angle of hypothetical axis (for 1
st
rotary axis)
[Data type] 2-word
[Unit of data]
Increment system IS-B IS-C Unit
Unit of data 0.001 0.0001 Deg
[Valid data range] -99999999 to 99999999
When the 1
st
rotary axis is hypothetical axis (parameter No.19696#0(IA1)=1), set
the angle of hypothetical axis.
19686 Axis number of 2
nd
rotary axis
[Data type] Byte
[Valid data range] 0 to Maximum controlled axis number
Set the controlled axis number of 2
nd
rotary axis.
19687 The axis around which the 2
nd
rotary axis rotates
[Data type] Byte
[Valid data range] 0 to 3
Set directions of axes of the 2
nd
axes.
1 : X axis around.
2 : Y axis around
3 : Z axis around
19689 Rotation direction of 2
nd
rotary axis
[Data type] Byte
[Valid data range] 0 or 1
Set the direction that the machine rotates when the move command of the plus
direction is instructed to the 2
nd
rotary axis.
0 : Direction of right screw (CCW)
1 : Direction of left screw (CW)
0 is set at the tool pivot, and one is set at the table axes usually.
19690 Angle of hypothetical axis (for 2
nd
rotary axis)
[Data type] 2-word
[Unit of data]
Increment system IS-B IS-C Unit
Unit of data 0.001 0.0001 Deg
[Valid data range] -99999999 to 99999999
When the 2
nd
rotary axis is hypothetical axis (parameter No.19696#1(IA2)=1),
set the angle of hypothetical axis.
