2.14.2 Format
G05 P10000 ; : Starting of AI HPCC / AI NANO HPCC
mode
G06.2 [P_] K_ X_ Y_ Z_ [R_] [F_] ; : Starting of NURBS interpolation mode
K_ X_ Y_ Z_ [R_] ;
K_ X_ Y_ Z_ [R_] ;
K_ X_ Y_ Z_ [R_] ;
...
K_ X_ Y_ Z_ [R_] ;
K_ ;
...
K_ ;
G01 ... ; : Ending of NURBS interpolation mode
G05 P0 ; : Ending of AI HPCC / AI NANO HPCC
mode
Each code has the following meaning.
G06.2 : Start NURBS interpolation mode
P_ : Rank of NURBS curve
X_ Y_ Z_ : Control point
R_ : Weight
K_ : Knot
F_ : Feedrate
2.14.3 Explanations
• G code
NURBS interpolation mode is selected when G06.2 is programmed in the AI
HPCC / AI NANO HPCC mode. G06.2 is a modal G code of group 01. NURBS
interpolation mode ends when a G code of group 01 other than G06.2 (G00, G01,
G02, G03, etc.) is specified. NURBS interpolation mode must end before the
command for ending AI HPCC / AI NANO HPCC mode is programmed.
In the NURBS interpolation mode, any command other than the NURBS
interpolation command (auxiliary function and others) cannot be specified.
• Controlled axes
NURBS interpolation can be performed on up to three axes. The axes of NURBS
interpolation must be specified in the first block. A new axis cannot be specified
before the beginning of the next NURBS curve or before NURBS interpolation
mode ends.
• Rank of NURBS
A rank of NURBS can be specified with address P. The rank setting, if any, must
be specified in the first block. If the rank setting is omitted, a rank of four (degree
of three) is assumed for NURBS. The valid data range for P is 2 to 4. The P
values have the following meanings:
P2: NURBS having a rank of two (degree of one)
P3: NURBS having a rank of three (degree of two)
P4: NURBS having a rank of four (degree of three) (default)
This rank is represented by k in the defining expression indicated in the
description of NURBS curve below. For example, a NURBS curve having a rank
of four has a degree of three. The NURBS curve can be expressed by the
constants t
3
, t
2
, and t
1
.
