3.6 Helical Interpolation
#7 #6 #5 #4 #3 #2 #1 #0
8485 G02
[Data type] Bit
G02 In AI HPCC / AI NANO HPCC mode, the helical interpolation is:
0: Disabled.
1: Enabled. (Option is necessary)
3.7 Smooth Interpolation
#7 #6 #5 #4 #3 #2 #1 #0
8485 CDS
[Data type] Bit
ICK In AI HPCC / AI NANO HPCC mode, the smooth interpolation is:
0: Disabled
1: Enabled
8486 Maximum travel distance of a block where smooth interpolation is applied
[Data type] 2-word
[Unit of data]
Increment system IS-B IS-C Unit of data
mm input 0.001 0.0001 mm
inch input 0.0001 0.00001 inch
[Valid data range] 0 to 99999999
This parameter specifies a block length used as a reference to decide whether to
apply smooth interpolation. If the line specified in a block is longer than the
value set in the parameter, smooth interpolation will not be applied to that block.
This parameter can be used, for example, to specify the maximum line length of
a folded line to which a metal die workpiece is approximated with some
tolerance.
8487 Angle by which smooth interpolation is turned off
[Data type] Word
[Unit of data] 0.1
°
[Valid data range] 0 to 32767
This parameter specifies an angle to judge whether to smooth interpolation
should be executed. When the block with larger angle difference than this value
appears, a smooth interpolation is turned off once.
When 0 is set, it is considered 10 degrees.
