FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
188/190
7 The Table of Function Available in the AI HPCC / AI NANO HPCC
The function excluding this cannot be used.
Item Specifications Remarks
Controlled axis
Controlled axis 2 axes
Controlled path 1 path
Simultaneously controlled axes 2 axes
Controlled axis expansion(total) Max. 8 axes
Simultaneously controlled axes
expansion(total)
Max. 6 axes
Axis control by PMC The axis of AI HPCC / AI NANO HPCC cannot command by PMC
in AI HPCC / AI NANO HPCC mode
Angular axis control, Arbitrary angular
axis control
Cs contouring control
Simple spindle synchronous control Only for 1 path system
Axis name In case of G code system A,
basic 2 axes are X and Z, additional
axes are optional from Y,A,B and C.
In case of G code system A,
basic 2 axes are X and Z, additional
axes are optional from
Y,U,V,W,A,B and C.
Least input increment 0.001mm,0.001deg,0.0001inch
increment system 1/10 0.0001mm,0.0001deg,0.00001inch
Inch/metric conversion The inch/metric mode cannot be switched in the AI HPCC / AI
NANO HPCC mode.
Interlock All axes, each axis
Machine lock All axes, each axis The each axis machine lock signal cannot be changed in the AI
HPCC / AI NANO HPCC mode.
Emergency stop
Stored stroke check 1
Stored stroke check 2 G22/G23 can not be commanded in the AI HPCC / AI NANO
HPCC mode. (Become P/S alarm 5000) Please instruct them
before the AI HPCC / AI NANO HPCC is turned on.
Mirror image The state cannot be changed in the AI HPCC / AI NANO HPCC
mode.
This function is not available to the angular axis controlled axis.
Backlash compensation for each rapid
traverse and cutting feed
Operation
Automatic operation
Cycle start / feed hold
Program stop / Program end
Reset
Program restart Option is necessary.
It is necessary to set “1” in parameter No.8403#1 (MSU).
Dry run
Single block
Previous page
Next page
