FANUC Series 16i /18i Additional Manual Page 145

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
145/190
5411 Magnification used when scaling magnification is not specified
[Data type] 2-word
[Unit of data] 0.001 or 0.00001 times (Selected using SCR, #7 of parameter No.5400)
[Valid data range] 1 to 999999
This parameter sets the scaling magnification. This setting value is used when a
scaling magnification (P) is not specified in the program.
Note
Parameter No.5421 becomes valid when scaling for every axis is valid. (XSC,
#6 of parameter No.5400 is “1”.)
5421 Scaling magnification for each axis
[Data type] 2-word axis
[Unit of data] 0.001 or 0.00001 times (Selected using SCR, #7 of parameter No.5400)
[Valid data range] 1 to 999999
This parameter sets the scaling magnification for each axis.
