FANUC Series 16i /18i Additional Manual Page 160

Additional Manual
A-78640E
Sheet
Title
Draw
No.
04 Feb.08.’03 Part of (4) is added or modified. Addition of 2.16.5
03 Jul.02.’02 A. Fukumoto Part of (3) is added or modified. T.Endo
02 May.13.’02 A. Fukumoto Addition of Tool Radius control for 5-axis machining etc T.Endo
Ed. Date Design Description
Date Jan.25.’02 Desig. A.Fukumoto Apprv. T.Endo
FANUC Series 16i /18i -TB
Specifications of AI High-Precision Contour Control /
A
I Nano High-Precision Contour control
160/190
3.12 Cylindrical Interpolation Cutting Point Control
#7 #6 #5 #4 #3 #2 #1 #0
19530 CYS CYA
[Data type] Bit
CYA Specifies whether to perform cylindrical interpolation cutting point
compensation.
0: Perform.
1: Do not perform.
CYS Specifies whether when the cylindrical interpolation cutting point compensation
function is used, cutting point compensation is performed between blocks or
together with a block movement if the cutting point compensation value is less
than the setting of parameter No. 19534.
0: Performed between blocks.
1: Performed together with a block movement if the cutting point compensation
value is less than the setting of parameter No. 19534.
19531 Tool offset axis number for the XY plane
19532 Tool offset axis number for the ZX plane
19533 Tool offset axis number for the YZ plane
[Data type] Word
[Valid data range] 1 - Max axes
Specify a tool offset axis that intersects the cylindrical rotation axis at
perpendicular angle.
